Bird 8860 Series Rf Load 1.5 Kw - N(f) Qc Connector

US $575.00

  • Mount Pearl, Newfoundland And Labrador, Canada
  • Jan 29th
Open on mobile:
QR code
Bird Termaline RF Load - 8860  (Clean Used Condition)   The 8860 Series 1500W  are self-contained high-power 50 ohm coaxial transmission line terminations requiring no outside power source or additional equipment. They provide accurate, dependable, and practically non-reflective termination for testing and adjusting transmitters under non-radiating conditions. The load consists essentially of a cylindrical film type resistor immersed in a dielectric coolant. The resistor, individually selected for its accuracy, is enclosed in a special tapered housing which provides a linear reduction in surge impedance directly proportional to the distance along the resistor.     Specifications Item No 8860 Series Item Name 1.5 kW, Oil-Cooled Terminations Power Rating 1500 W continuous Frequency Range and VSWR  VSWR: DC to 1 GHz 1.1 max., 1 GHz to 2 GHz 1.25 max., 2 GHz to 2.4 GHz 1.3 max Temperture Range Impedance -40 to +45 °C 50 ohms nominal  Coolant 1.5 gal. (5.68 liters) Silicone Oil Product Type Digital, Oil-Cooled Operating Position Horizontal Only Connectors N - Female QC Finish Gray Powder Coat Dimensions 18-5/8" x 7-1/2" x 13-1/8" (L x W x H) 473 x 184 x 333 mm Weight 31 lbs. (14.1 kg)
