Bird Termaline 8862 Rf Load 1500 Watts 1-5/8" Eia Flanged Coaxial Resister 50ohm

US $999.99

  • Van Nuys, California, United States
  • Jan 30th
Open on mobile:
QR code
 Bird Electronic Termaline RF Load 8862 1.5 kW, Oil-Cooled, 1-5/8" EIA Flanged Connector  Rugged load for high power base station RF testing up to 2.4 GHz Oil-assisted (vented) convection cooling for safe, continuous operation up to 1500W full rated power   Simple but rugged design minimizes maintenance requirements The Model 8862 TERMALINE® Load Resistor is a self-contained high-power 50 ohm coaxial transmission line termination requiring no outside power source or additional equipment. It provides accurate, dependable, and practically non-reflective termination for testing and adjusting transmitters under non-radiating conditions. The load consists essentially of a cylindrical film type resistor immersed in a dielectric coolant. The resistor, individually selected for its accuracy, is enclosed in a special tapered housing which provides a linear reduction in surge impedance directly proportional to the distance along the resistor. This produces the uniform, practically reflectionless line termination from dc to 2.4 GHz. Product Specifications: Ambient Temperature Range: -40°C to +45°C Connector: 1-5/8" EIA Flanged Connector Finish: Gray powder coat Frequency Range VSWR: DC to 1 GHz 1.1 max., 1 GHz to 2 GHz 1.25 max., 2 GHz to 2.4 GHz 1.3 max Impedance: 50 ohms nominal Load Coolant: 1.5 gal. (5.68 liters) silcone oil  Nominal Size: 17 1/8" L x 7 1/2" W x 13 1/8" H, (445 mm x 184 mm x 333 mm)  Operating Position: Horizontal Only Power Rating: 1500 W continuous Weight: 30 lbs. (12.6 kg)
