Bjt Transistor Curve Tracer Plus Ac/dc Regulator Power Dual Supply "double Pack"

US $30.84

Bangkok, Thailand
Jan 29th

Open on mobile:
QR code

[Double Pack] BJT Transistor Curve Tracer Plus AC/DC Regulator Power Dual Supply Technical information "BJT Transistor Curve Tracer" - Require Power supply +15VDC/-15VDC (1A ) - Capable to check IV curve both NPN / PNP Power Transistor / Small Transistor - 8 step Ib 0uA,24uA,48uA,72uA,96uA,120uA,144uA,168uA for small transistor - 8 step Ib 0.0mA,0.32mA,0.64mA,0.96mA,1.28mA,1.6mA,1.92mA,2.24mA, - Vce = +10V for NPN and -10V for PNP - Switching frequency 642Hz - 2 Jumper to select ranges of Ib and type of transistor { NPN / PNP } - hole PCB for wiring to external 2 way switches to select ranges of ib and type of transistor - Require 2 CH Analog or Digital Oscilloscope in x-y mode to connect both CH to this adapter board ( CH1 is X-Axis and CH2 is Y-Axis ) - Comes with the schematic diagram - Comes with 2 x free RCA to female BNC jack - PCB size 9.0cm x 10.0cm. - Please Note: Don't include the AC transformer and the cables ++++++++++++++++Double Pack+++++++++++++++++ Technical information "+15V/-15V 1A AC / DC Regulator Power Dual Supply" - This circuit is AC/DC +-15V Regulator Power Dual Supply, AC input 15-18V, output 15V. - This is suitable for any circuit which require fix voltage +-15V/ Max at 1A - PCB size 4.4cm x 9.2cm / Comes with the schematic diagram - Please Note: Don't include the AC transformer and the cables Payment - PayPal only please. - All major credit cards are accepted through our secure payment processor PayPal. - Payment must be made within 5 days upon auction end. Shipment - Usually products will be shipped to your PayPal address. In case, you prefer to send to other address, please inform us by Ebay message or PayPal’s note. - All products are shipped by Thailand Post Service within 48 hours by air mail after payment is clear. Except the weekend, shipping will be postponed to Monday. - We ship to worldwide by Economy Air mail ( 2-3 weeks ) as gift for customs declaration. Please let us know if you prefer expedite shipping, extra shipping cost is required. - Due to shipping cost is low, tracking number is not included, in case, you prefer the tracking number, you can send additional cost $2.5 to us via PayPal. - We are not responsible for any custom duty or import tax. Return Policy - We offer 30days money back. You can purchased with more confident. - Full refund if within 45days buyer doesn't receive our product. - After you receive our products, If it is defective or missing part, please take the photo to be an evidence and contact us within 30 days. You can return product back for replacement or refund. But shipping costs and custom tax are not refundable. Feedback and Support - We leave positive feedback after receiving the payment. - Please contact us before to leave negative feedback or open the case. We will do the best to resolve any problems. - We always support our customer after sale. - If you have any problems or any questions with our products, please feel free to contact us. We have engineer to support you. Don't worry if you are new in electronic. - Due to timing difference, we may delay to response but it should be within 24 hours. Our working hours are from (GMT+7:00) 08:00AM to 20:00PM. Example : To connect to analog oscilloscope FreeAuctionDesigns Free eBay Templates, Image Hosting and Ad Design Tools!

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Thailandkit
Country/Region of Manufacture	Thailand
Model	CH012+OH001
Country of Manufacture	Thailand
