BK 1249B NTSC Color Generator, US $4300 – Picture 0
BK 1249B NTSC Color Generator, US $4300 – Picture 0

Bk 1249b Ntsc Color Generator

US $4300

  • Groveland, Massachusetts, United States
  • May 24th
Open on mobile:
QR code
 Color Bars White (75% or 100% switch selectable) Yellow, Cyan, Green, Magenta, Red, Blue, Black (7.5% set-up) Chroma Switch Selectable Accuracy ±5 and ±5 IEEE Staircase COLOR OFF obtains staircase from color bars Rasters Black Convergence Center dot 7 x 11 dots 7 x 11 crosshatch Center Cross RF Output Channels: CH 3, CH 4, 1F. 61.25, 67.25, 45.75 MHz ± 0.008MHz Level 10 mV rms minimum into 75 Impedance 75 Ohms Composite Video 1V p-p into 75 Negative or positive polarity sync available Amplitude Variable 0 to ±1.2V p-p into 75 Calibrated 1V p-p position with negative sync Impedance 75 Ohms Patterns BNC and D-Type Sub-Miniature Connectors, convergence and color bars Level TTL level and low level, (0.8 ± 0.2V), switch selectable Impedance 75 Ohms Sound 4.5 MHz ± 0.2% modulated by approximately 1 kHz audio tone, switch selectable Composite NTSC-M TTL level; interlace for NTSC color bars and switch selectable interlace or progressive for convergence patterns (negative polarity sync) Horizontal TTL level (Positive polarity sync.) Vertical TTL level (Positive polarity sync.) Impedance 75 Ohms Color Subcarrier NTSC signal: 3.579545 MHz (+50 Hz) Power Source 105 to 130 VAC, 60Hz, 8W Operating Temperature 32° to 122°F (0° to +50°C) Dimensions 3.39" x 10.39" x 11.42" (86 x 264 x 290 mm) Weight 2.8 lbs. (1.3 kg)
