$Black Mini Electric Linear Actuator CE Rohs UL High-Speed 6\\\'\\\'/s IP54, US $35.34 – Picture 0$

Black Mini Electric Linear Actuator Ce Rohs Ul High-speed 6\\\'\\\'/s Ip54

US $35.34

suzhou, China
Jul 6th

Open on mobile:
QR code

Product Description Black Mini Electric Linear Actuator CE Rohs UL High-Speed 6\\\'\\\'/s IP54 Product description: 100% brand new and high quality Made of high-quality materials, durable Mini electric linear actuator stroke 4" force 6.4N-188N 12V high speed 150mm/s Product name: Mini electric push rod Model: LA-T8 Voltage: 6V / 12V DC Limit switch Frequency of use: 10% Outer tube material: iron Inner tube material: aluminum Stroke: 10, 17.5, 21, 30, 50, 100mm (optional) Noise: 55 decibels Color options: black Maximum waterproof rating: IP54 Certification: CE Rohs UL Stroke = 10mm Minimum installation distance (the distance between the centers of the two installation holes after fully retracted): Stroke +54.5mm=10+54.5=64.5mm Fully retracted length: 73.5mm Maximum length (the maximum length after fully pushed out): Stroke*2 + 63.5mm = 10*2+63.5=83.5mm Stroke = 21mm Minimum installation distance (the distance between the centers of the two installation holes after fully retracted): Stroke +54.5mm=21+54.5=75.5mm Fully retracted length: 84.5mm Maximum length (the maximum length after being fully pushed out): Stroke*2 + 63.5mm = 21*2+63.5=105.5mm Stroke = 30mm Minimum installation distance (the distance between the centers of the two installation holes after fully retracted): Stroke +54.5mm = 30+54.5=83.5mm Fully retracted length: 93.5mm Maximum length (the maximum length after fully pushed out): Stroke*2 + 63.5mm = 30*2+63.5=123.5mm Stroke = 50mm Minimum installation distance (the distance between the centers of the two installation holes after fully retracted): Stroke +54.5mm=50+54.5=104.5mm Fully retracted length: 113.5mm Maximum length (the maximum length after being fully pushed out): Stroke*2 + 63.5mm = Stroke = 100mm Minimum installation distance (the distance between the centers of the two installation holes after fully retracted): Stroke +54.5mm=100+54.5=154.5mm Fully retracted length: 163.5mm Maximum length (the maximum length after fully pushed out): Stroke*2 + 63.5mm = 100*2+63.5=263.5mm Package list: 1 *Mini linear actuator 2 *Mounting bracket Note: 1.The real color of the item may be slightly different from the pictures shown on website caused by many factors such as brightness of your monitor and light brightness. 2.Please allow slight manual measurement deviation for the data. Payment We accept payment via Paypal only. Payment must be completed within 5 days. If you have any problems about payment, please contact us via ebay message. Delivery details We only ship to confirmed Paypal addresses. Please comfirm that your paypal address is in line with your shipping address. Please kindly note that the combined shipping is not provided because the shipping fee is calculated by weight. Also, the each additional item means exactly the the same color and size.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	MPN	Does Not Apply
Package Contents	1 Mini linear actuator 2 Mounting bracket
Brand	Unbranded
Model	LA-T8
Voltage	6V / 12V DC
