Bldc 3 Phase Dc Brushless Hallless Motor Driver Board Pwm 10/60/200/380w 6.5-50v

US $5.90

ShenZhen, China
Jul 22nd

Open on mobile:
QR code

BLDC 3 Phase DC Brushless Hallless Motor Driver Board PWM 10/60/200/380W 6.5-50V DC3.8-15V 10W Feature Mini BLDC sine wave three-phase brushless DC motor speed control board, this mini three-phase sensorless (no need To Hall) BLDC brushless DC motor speed controller adopts customized chip, internal integrated over-current protection, phase loss protection, locked rotor protection, sine wave, low bath noise, small size, embedded design, easy to use and easy to use. DC brushless sensorless speed controller, suitable for small three-phase brushless DC motors Instructions for use: This driver is custom-made with a single chip, and the integration level is quite high. All parameters are universally set and have been solidified. There is no peripheral parameter adjustment. The working voltage is DC 3.8-16V and the maximum power is within 10W when working. Because it is a universal parameter, it is available in the market. There are many types of upper motors, and some motors may not start or work normally. Please do not connect motors with very different parameters from the drive board. Please buy a sample and test it. Whether it can start and work normally depends on the test. Technical index: Model: SZ-B2 Name: 10W three-phase sensorless (no Hall required) brushless DC motor driver (1) Working voltage: DC3.8V-15V (up to 16V) (2) Working current: continuous 600-800MA (peak 1A) (3) Control power: within 10W (4) Quiescent current: 7-10MA (standby state) (5) Speed regulation control voltage: 0-3.3V (6) Maximum speed: about 15000 rpm (different types of motors are different) PCB size: length 19MMx width 15MM total height 10MM Package include 1x BLDC threephase DC brushless Hallless motor controller DC6-20V 60W This drive is a DC three-phase brushless and Hallless control board, and the motor can work normally without Hall. Mini BLDC wide voltage 5-24V 3A small size embedded brushless and Hallless controller, on-board potentiometer speed control support PLC 0-5V analog signal speed control Special instructions for front-end control interface: 1. DIR Forward and Reverse BRAKE brake Active low (grounded to GND) 2. SC speed output signal Only the interface is left without technical support. If you are interested, you can use the oscilloscope to find the method and law of the waveform 3. If you need an external potentiometer to adjust the speed, please remove the original potentiometer, and use a wire to lead out one-to-one external potentiometer. The size of the potentiometer is not required, and the resistance value is 1-100K. The picture above is a non-inductive (no Hall) model Instructions for use of non-inductive models: Non-inductive model No Hall required, on-board speed regulating potentiometer Connected to three phase wires of the motor, connected to two power wires, it can work when power is supplied, it can be used when you send the cable Interface Description: 1. U V W phase line output is connected to the motor 2. VCC GND main power supply (external DC power supply) To Product parameters: Product name: Three-phase DC brushless and Hallless drive Model: X10 (no sense) Working voltage: 6-20V (limit 5-24V) Drive current: maximum 3A Maximum speed: 224000 RPM (2 pole motor), 74000 RPM (6 pole motor), 40000 RPM (12 pole motor), 35000 RPM (14 pole motor). Product size: length 34MM*width 27MM*height 11MM Weight: X10 8 grams (including wire) Features: This driver is a low-power fan brushless drive, and can also be embedded in other systems. It is specially used for air pumps, water pumps, oil pumps, fans, etc., industrial control electric gadgets, etc., for small space and low-power DC three-phase brushless motors. Medium timing is not suitable for high-power motors, such as long-term full-load current operation, Jianyi plus fan cooling Precautions: 1. There is no use in the power supply circuit on the motherboard. Jianyi has added it himself. Reverse connection of the positive and negative poles of the power supply will cause permanent damage to some of the chips on the board (even if it does not work for 1 second) 2. There is motor blocking protection during normal operation. Please do not artificially short-circuit when the module is not working normally. Once short-circuiting may cause the line to burst, please use small current and low voltage test for the first wiring test. Matching use of three-phase DC brushless motors with equivalent current and power 3. Do not connect the motor that is obviously inconsistent with the drive module voltage, current, or power, to avoid inexplicable "nonsensical" damage Package include: 1x BLDC threephase DC brushless Hallless motor controller DC7-24V 200W BLDC wide voltage 7-24V high-power small-volume potentiometer speed control Brushless and Hallless controller, single-button version supports single-button free switching acceleration and deceleration with power-off memory function potentiometer speed control version supports PLC 0-5V simulation Signal speed control Instructions for use of potentiometer models: The standard power distribution positioner directly regulates the speed without external control signals. It increases clockwise and decreases counterclockwise. It is also suitable for external PLC 0-5 analog quantity control. Unplug the potentiometer cable, and the external 0-5 analog quantity control signal and ground wire are respectively connected to the input signal terminal of the brushless driver board, as long as two wires are OK Interface Description: 1. U V W phase line output is connected to the motor 2. VCC GND main power supply (external DC power supply) To Product parameters: Product name: Potentiometer three-phase DC brushless and Hallless drive Model: X30A (potentiometer) Working voltage: 7-24V Drive current: rated 15A plus fan cooling 20A Maximum speed: 224000 RPM (2 pole motor), 74000 RPM (6 pole motor), 40000 RPM (12 pole motor), 35000 RPM (14 pole motor). Product size: length 45MM*width 26MM*height 12MM (excluding wires and protruding capacitors) Weight: X30A 29 grams Features: ESC is specially developed and designed for industrial control electric tools such as air pumps, water pumps, oil pumps, fans, etc. that use DC three-phase brushless motors. The default is medium timing and long-time high current operation. Jianyi plus fan cooling does have overheat protection , When the ESC's external heat dissipation conditions are poor and the temperature exceeds 100 degrees, the power will be automatically reduced, and the temperature will return to normal when it drops to 100 degrees. To Precautions: 1. There is no fuse in the power supply circuit on the motherboard. Jianyi has added it himself. Reverse connection of the positive and negative poles of the power supply will cause permanent damage to some of the chips on the board (even if it does not work for 1 second) 2. There is motor blocking protection during normal operation. Because the power and current of the module are large, please do not artificially short-circuit when the module is not working normally. Once the short-circuit may burn the line and the tube may burst, please use the small for the first wiring test. Current low voltage test, after ok, then pass high current and high voltage to work 3. Do not connect the motor that is obviously inconsistent with the drive module voltage, current, or power, to avoid inexplicable "nonsensical" damage Package include: 1x BLDC threephase DC brushless Hallless motor controller DC6-20V 380W Main specifications: Product Name: 380W brushless DC motor controller without Hall Model: zs-x11f Working voltage: 6.5-50v Driving current: rated 16A plus air cooling cooling 30A Maximum power: 380W Overcurrent protection: no (external fuse required) Locked rotor protection: Yes (current drops automatically after locked rotor) Over temperature protection: Yes (over temperature exceeds 100 and power drops by half) Maximum speed: 224000 RPM (2-pole motor), 74000 RPM (6-pole motor), 40000 RPM (12 pole motor), 35000 RPM (14 pole motor). Product size: 63mm L * 45mm w * 31mm H Weight: about 76g Interface Description: 1. U V W phase line output connected to motor 2. 5V GND main board with its own power supply (current not more than 300mA) 3. VCC GND motor main power supply (external DC power supply) 4. SC speed pulse signal output 5. Dir positive and reverse control (leadable external switch) 6. Brake brake control (leadable external switch) 6.0-5v PWM speed regulation control signal input (speed regulation of on-board potentiometer can also be adjusted by jumper switching and external 0-5V analog PWM duty ratio signal input) Package Include: 1x BLDC threephase DC brushless Hallless motor controller PWM motor drive board PLC DC 5V-12V 15W Specifications: Working Voltage: DC 5V-12V (MAX. 15V) Working Current: 1.5A (MAX. 2A) Maximum Rated Power: 15W Static Current: 0.005A (Stand by) PWM Duty Cycle: 10000 RPM Board Size: 30x25mm/1.18x0.98" Quantity: 1 Pc Note: Please allow 1-3mm error due to manual measurement. pls make sure you do not mind before you bid Due to the difference between different monitors, the picture may not reflect the actual color of the item. Thank you! Package Includes: 1 x DC Motor Drive Board Shipping Feedback Contact us Return Policy Shipping Domestic We believe you need to get your purchases as quick as possible. As a general rule your item will be shipped within 24 hours of you purchasing it. We pack and post from Tuesday to Sunday (Mondays we are closed) but definitely get all our mail off to the post office first thing Monday morning for you. Mail gets picked up at 12pm so chances are if you buy before lunchtime your item will leave the same day. International Same as above but understand that depending on what part of the world you are from it does take a little longer to send, delivery can be from 7-15 working days. Also other factors to take into consideration are quarantine and customs regulations in your country. It is also a consideration that customs duties and GST/VAT may be payable at the buyers expense. Combined Postage (for items with shipping charges): We are more than happy to combine postage, just use the Buy it Now function in eBay (but DO NOT PAY after purchasing each item) to buy all the products you need, when you have finished request a combined invoice, we will base the shipping cost on the size, weight and your location. Feedback * When you satisfied with our product and services please leave us positive feedback. * If you have got the package, please confirm "Delivery on time" For us. * If a problem occurs, contact us immediately with any email request. * Just contact us using the " Ask the seller a question" link on eBay. Your Satisfaction is our Priority. Our goal is to make all our customers as happy as possible while shopping with us. Contact us For anything problem about product, price, shipping or order status, pleasecontact us via eBay message.Just contact us using the " Ask the seller a question" link on eBay. We expect positive feedback and 5 scores DSR from you. Return Policy We believe our items are so outstanding. We are convinced you will be happy with your Purchase. If you do not satisfy with our items. Please simply return to us within 30 Days in original condition. Just pay for the returned postage. Then we can issue full refund to you after the returned item arrived at our warehouse. Please include your eBay ID and item number with any email requests.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Unbranded
select	6-20V 60W
MPN	Does not apply
UPC	Does not apply
Input Voltage	DC6.5-20W
EAN	Does not apply
Application	3 Phase
Type	3 Phase PWM Hall Motor Control Brushless
Model	PWM Hall Motor
Features	BLDC
Custom Bundle	No
Voltage	6 V
Modified Item	No
Marke	Markenlos
Country/Region of Manufacture	China
