Ble4.0 2.4ghz Bluetooth Wireless Module Nrf51822 Board Core51822 (b)

US $9.97

ShenZhen, China
Jun 9th

Open on mobile:
QR code

Description This auction is for Core51822 BLE4.0 Bluetooth 2.4G Wireless Module, nRF51822 Onboard Overview Core51822 is a wireless module based on nRF51822 - the Multiprotocol Bluetooth® 4.0 low energy/2.4 GHz RF SoC designed for ULP (ultra low power) wirelesss applications. Core51822 Specifications Onboard chip: nRF51822 Communication distance (open outdoor@1M data rate): 30m Frequency range: 2.4GHz Operating voltage: 2.0V ~ 3.6V Operating temperature: -40℃ ~ 85℃ Dimension (PCB): 24.5mm x 32.26mm Expansion pinheader: all the I/Os except P0.26 and P0.27 Pinheader pitch: 2.00mm Spacing between pinheaders on the left side and the right side: 18.00mm Antenna: onboard antenna nRF51822 Features 2.4 GHz multiprotocol RF transceiver ARM® Cortex™-M0 32 bit processor 128 bit AES HW encryption 256kB flash & 32kB RAM Programmable Peripheral Interconnect (PPI) Digital interfaces: SPI, I2C, UART 10 bit ADC Programmable output power: -20 to +4 dBm Independent application development and protocol stack Fully compatible with NRF24L series Pinout compatible with NRF51xxx series Global separate power management Operating voltage: 1.8 V ~ 3.6 V Applications Wearable devices Bluetooth intelligent application Mobile phone accessories RFID labels Smart home appliances Industry control Data acquisition system Revision History 2015.06, Core51822 upgrades the onboard chip to Rev3, features 32kB RAM, supports higher version SDK, and all the demo codes are still compatible with the Rev2 ones. Package included: 1PCS x BLE4.0 2.4GHz Bluetooth Wireless Module nRF51822 Board Core51822 (B) Shipping Terms 1. WORLDWIDE Free SHIPPING. (Except China) 2. Orders processed within 24 hours of payment verification. 3. We only ship to confirmed eBay addresses. Your eBay address MUST MATCH your Shipping address. 4. The images shown are not the actual item and are for your reference only. 5. SERVICE TRANSIT TIME is provided by the carrier and excludes weekends and holidays. Transit times may vary, particularly during the holiday season. 6. If you have not received your shipment within 30 days from payment, please contact us. We will track the shipment and get back to you as soon as possible with a reply. Our goal is customer satisfaction! 7. Due to stock status and time differences, we will choose to ship your item from our first available warehouse for fast delivery. No Tracking Number The shipping cost is very low,we are not responsible for any loss in the mail if the item not insured(no-registered mail). Registered Post Shipping cost: Would better to Add 3 USD to Upgrade---- Registered Post(Choose "Standard Int'l Shipping" for one item,and others choose free shipping.we can send all your items in one box with tracking number.) Express Courier Need URGENT? We offer a varienty of shipping methods (Expedited Int'l Shipping) to meet your needs.If you need it Urgent, please contact us to Upgrade the shipping to Express. Payment Terms 1.We accept payment via PAYPAL ONLY. 2. Payment must be made within 4 days of auction closing. (Non-payment may result in a UPI (Unpaid Item) being put on your account. eBay will automatically close your account if you accumulate 4 UPI's total.) 3. TOTAL AMOUNT DUE includes the final auction price plus S&H(Shipping and Handling). 4. S&H will be determined based upon the SHIP TO address. PLEASE NOTE: S&H DOES NOT INCLUDE DUTIES, LOCATL TAXES OR ANY OTHER IMPORTATION FEES. 5. Please list your special requests (color, packages, etc.) in the PAYPAL NOTES SECTION when you make payment. Feedback We maintain high standards of excellence and strive for 100% customer satisfaction! Feedback is very important to us. We request that you contact us immediately BEFORE you give us neutral or negative feedback, so that we can satisfactorily address your concerns. Links for related products

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Unbranded/Generic
Model	NRF51822
Country/Region of Manufacture	China
MPN	NRF51822
UPC	Does not apply
