Blue Aluminum Case 12864 Lcd Transistor Tester Capacitance Esr Lcr Meter New

US $42.98

Shen Zhen, China
Jan 29th

Open on mobile:
QR code

Blue Aluminum Case 12864 LCD Transistor Tester Capacitance ESR LCR Meter New HOME DESCRIPTION PAYMENT SHIPPING TERMS OF SALE ABOUT US DESCRIPTION Description: Aluminum Case M328 version of the software ,more functions.Chip: Atmega328 128*64 big Backlight LCD display,only 2mA when stand by. Using 9V battery (Not inlcuded) NEW Function: 1:Automatic detection of NPN and PNP transistors, n-channel and p-channel MOSFET, diode (including double diode), thyristor, transistor, resistor and capacitor and other components 2: Automatic test the pin of a component, and display on the LCD 3:Can detect the transistor, MOSFET protection diode amplification coefficient and the base to determine the emitter transistor forward biased voltage 4: Measure the gate and gate capacitance of the MOSFET threshold voltage 5:Use 12864 liquid crystal display with blue backlight Size:140*90*55MM Specifications: 1,One -button operation, automatic shutdown . 2,Only 20nA shutdown current. 3,Automatically detect NPN, PNP bipolar transistors , N -channel and P -channel MOS FET, JFET , diodes , two diodes, thyristors small power unidirectional and bidirectional thyristor. 4,Automatic identification components pin arrangement . 5,Measuring bipolar transistor current amplification factor and base - emitter threshold voltage. 6,Via the base - emitter threshold voltage and high current amplification factor to identify Darlington transistors. 7,Can detect bipolar transistors and MOS transistors protection diodes. 8,Measuring the gate MOS FET threshold voltage and the gate capacitance. 9,Can simultaneously measure two resistors and resistor symbol is displayed. Displayed on the right with a decimal value of 4 . Resistance symbol on both sides shows the pin number. So you can measure the potentiometer. If the potentiometer wiper is not transferred to an extreme position , we can distinguish the middle and both ends of the pin. 10,Resistance measurement resolution is 0.1 ohms , 50M ohms can be measured . 11,Can measure capacitanceCan measure capacitance of 30pF-100mF , resolution 1pF. 12.2uF more capacitors can simultaneously measure the equivalent series resistance ESR values. The two can be displayed with a decimal value , resolution 0.01 ohms. 13,Can be in the correct order and the diode symbol display two diodes , and gives the diode forward voltage. 14.LED is detected as a diode forward voltage higher . Combo of the LED is identified as two diodes. 15,Eeverse breakdown voltage is less than 4.5V Zener diode can be identified. 16,Can measure a single diode reverse capacitance. If the bipolar transistor connected to the base and collector or emitter of a pin , it can measure the collector or emitter junction reverse capacitance . 18 can be obtained with a single measurement rectifier bridge connection. Notice: Before measuring capacitance , the capacitor must be discharged , otherwise very likely damage the meter . Package Include: 1 x New Blue Aluminum Case 12864 LCD Transistor Tester Capacitance ESR LCR Meter(not include the battery) PAYMENT We accept PayPal only. SHIPPING 1.Items are shipped from china.we will send out within 1 bussiness day after receive the payment. 2.We only ship to ebay confirmed address. So before bidding, please kindly verify your ebay address. 3.Shipping to USA takes 8-18 days in normal condition by E-packet with tracking number. Shipping to most other countries takes about 12-30 days via Economy Int'l Airmail. Less than $40, without tracking number,if you request tracking number,please pay $3 more and let me know. Over $40,with tracking number free.The shipping time depends on your location and local postal service,as well as the weather condition along the shipping,sometimes may take longer,.please contact us to confirm before leave feedback or open case. 4.Express shipping: Extra $20 --$25 will be charged for the first 500 grams for most countries. Contact us if you need this service. TERMS OF SALE 1.If you are not satisfied when you receive your item, please return it within 30 days for a replacement or money back. Please contact us before you return it. 2.If item is defective in 30 days, We will send you a replacement without extra charger, or offer refund after we receive the defective item. 3.If item is defective after 30 days, you can still send it back to us. We will send you a new one after receiving the defective item. But you have to pay the extra shipping fee. ABOUT US We are honest seller and do our best to serve you. So if you have any concerns,please don’t hesitate to contact us by ebay message. We will do your best to help you out.please don’t leave negative/ neutral feedback or open case before contact us.
