Bluetooth 4.0 BLE Serial Transceiver Communication Board Module CC2540 RF-BM-S02, US $4.89 – Picture 0

Bluetooth 4.0 BLE Serial Transceiver Communication Board Module CC2540 RF-BM-S02, US $4.89 – Picture 1

Bluetooth 4.0 BLE Serial Transceiver Communication Board Module CC2540 RF-BM-S02, US $4.89 – Picture 2

Bluetooth 4.0 BLE Serial Transceiver Communication Board Module CC2540 RF-BM-S02, US $4.89 – Picture 3

Bluetooth 4.0 BLE Serial Transceiver Communication Board Module CC2540 RF-BM-S02, US $4.89 – Picture 4

Bluetooth 4.0 Ble Serial Transceiver Communication Board Module Cc2540 Rf-bm-s02

US $4.89

Shenzhen, China
Jun 9th

Open on mobile:
QR code

Click to Enlarge Click to Enlarge Click to Enlarge Click to Enlarge Click to Enlarge Feature: -Support bridging mode (transmission) and direct drive mode (no MCU) -Open distance transmission distance up to 130m -High speed transmission speed of up to 6Kbps/S -Ultra low power communication TX Current RX Current 0.5mA 0.5mA -Models of communication support and apple iPhone4S, iPad3, iPod4 later -Support and a Bluetooth 4 Android android 4.3 mobile phone communication -Provide IOS module testing APP source code and module driver routines Specifications: Open transmission distance: 80m High-speed transfer rate up to: 6Kbps / S Ultra-low power communication TX Current≤0.5mA ,RX Current≤0.5mA Ultra-low standby power consumption 0.3-0.4uA Support for iphone4S, ipd3 , ipd4 communication Support for over android 4.3 version mobile phone communication with Bluetooth 4.0 features Main functions: -At the same time support bridge mode (serial transmission), or direct drive mode (without CPU); -The default 20ms connection interval, quick connection; -Support AT instruction software reset module, to obtain MAC address; -Support the AT command adjusted Bluetooth connection interval, control the forwarding rate of different; -Support AT instruction to adjust transmit power, modify radio broadcast data interval, custom, custom equipment identification code, set the data delay; -Serial data packet length, can be 200byte the following (including 200) of arbitrary length. -Stable operation in the 2.5K-2.8K (IO5, IO6); -Support mobile devices APP to modify the module name, power down save, modify the serial baud rate, product identification code, custom broadcast content, broadcast cycle; -Support mobile devices APP for remote reset module, set the transmit power; -Support mobile devices connected to APP interval regulating Bluetooth, power down is not preserved. -IO expands to include debug port; -Support the connection state, broadcasting state prompt foot / IO flexible configuration; -6 bidirectional programmable IO, external interrupt trigger input detection, low power operation. -2 programmable timing single / loop reversal output port (Intelligent appointment timing application); -Two ADC input (14 bit), enable / disable, sampling period of free allocation. (temperature and humidity, photometric applications); -Four programmable PWM (120Hz) output. (light, speed and other applications); -Continuous data acquisition module RSSI, readable can automatically notify APP, enable / disable, sampling frequency set free. (anti lost alarm application objects); -Support module power tips, electric quantity reading, can report. (equipment power remind); -Support anti hijack password settings, modify and recovery, prevent malicious third party; -Support single pin down (press) 5S restore factory settings, APP remote restore factory settings; -Support PWM output initialization state custom (full high, low, power down before PWM output value); -Support custom PWM frequency (61.036 Hz <=f 8 kHz, the default 120Hz); -Broadcast content presentation module real-time system status, including the battery, custom equipment identification code, four PWM current output or two ADC collection value, the IO status; (for broadcast applications); -Two level width count, 0 ~ 0xFFFFFFFF MS (about 49.7 days); -Support internal real-time clock RTC, APP terminal can be synchronous calibration; -Timing control support 6 IO and four PWM, do not open the default this function; -Four PWM support the gradual mode (for dimming control); -Support IO configuration and output state of preservation of function, can customize the default initialization state; -Support shallow recovery and depth recovery mode, flexible and retrieve user data, while retaining the products must be configured; -Support for Bluetooth from the TX serial connection state (normal connection, disconnection and timeout break) string tips; -Support the low level enable mode and pulse width enabled mode, support remote shutdown; -The pulse enable mode support for 30 seconds without connecting the automatic shutdown; -The pulse enable mode support square wave alarm connection timeout. Package Content: 1 x RF-BM-S02 Bluetooth 4.0 BLE serial communication module Payment TermsWe only accept PayPal, Payment must be received in 3 business days of auction closing. Any special request cannot be accepted after 24 hours of payment, because most of orders will be processed instantly and same day dispatched. Shipping Terms1. Orders processed within 24-48 hours of payment clear. 2. We only ship to confirmed PAYPAL addresses. Your PAYPAL address MUST MATCH your Shipping address. 3. SERVICE TRANSIT TIME is provided by the carrier and excludes weekends and holidays. Transit times may vary, particularly during the holiday season. 4. As an international buyer, it is your responsibility to pay for duty and custom fees. Our price dose not include taxes, VAT, or other hidden custom charges. 5. Items are shipped by China post international airmail. General will take over 14-25 business days to delivery. European country may take up more days due to strict Custom Inspection.(It may take even longer time due to less frequen of airline and inspection across the border). inkfrog terapeak inkFrog Analytics On Jul-22-15 at 06:13:00 PDT, seller added the following information:

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Padgene
Country/Region of Manufacture	China
Model	07BR0006
UPC	Does Not Apply
MPN	Does Not Apply
