Bobrick B-4998.99 Swing Up Fold Up Wall-mounted Grab Bar Satin Ada Handicapped

US $50.00

Victor, Montana, United States
Jan 29th

Open on mobile:
QR code

Bobrick 4998.99 SwingUp Wall-Mounted Grab Bar, Satin Finish Features Satin-finish 18-gauge type 304 stainless steel tubing 1-1/4" (32mm) diameter. Flange has exposed mounting screw holes. Grab bar supports loads in excess of 250 pounds (113-kg) when properly installed. Meets ICC/ANSI A117.1-2003 Accessibility Standards in U.S.A. Mandrel bending process ensures uniform bar diameter around curves. All joints and supports are contour cut and welded. Concealed anchors and fasteners available as an optional accessory. Peened nonslip gripping surface available. Patented (B-4998, B-4998.99) MATERIALS: Grab Bar — 18-8 S, type-304, 18-gauge (1.2mm) stainless steel tubing with satin finish. 1–1/4 (32mm) outside diameter. Ends are heliarc welded to flanges. Backplate — 18-8 S, type-304, 3/16" (5mm) thick, satin-finish stainless steel with four screw holes for attachment to wall. OPERATION: Swing-up grab bar is manually raised for approach or departure and lowered to horizontal position for support; once grab bar is raised more than 45° from horizontal position, counterweighted design prevents grab bar from falling back down to full horizontal position. Meets ICC/ANSI 117.1-2003 Accessibility Standards in U. S. A. STRENGTH: Swing-up grab bar can support loads in excess of 250 pounds (113kg) if properly installed, complying with barrier-free accessibility guidelines (including ADAAG in the U.S.A.) for structural strength. Caution: Grabs bars are no stronger than the anchors and walls to which they are attached and, therefore, must be firmly secured in order to sustain the loads for which they are intended. INSTALLATION: Provide concealed anchor device or backing as specified or required in accordance with local building codes before wall is finished. Fasten grab bar to anchor device or backing. Concealed anchor devices and mounted screws are not included with Bobrick grab bars and must be specified as an optional accessory. SPECIFICATION: Grab bar shall be type-304 stainless steel with satin finish. Grab bar shall have 18-gauge (1.2mm) wall thickness and 1–1/4" (32mm) outside diameter. Flanges shall be 3/16" (5mm) thick stainless steel plate, 3" (75mm) diameter, and equipped with three screw holes for attachment to wall or floor. Swing-up grab bar shall be manually raised for approach or departure and lowered to horizontal position for support; counterweighted design shall prevent grab bar from falling back down to full horizontal position once grab bar is raised more than 45° from horizontal position. Grab bar shall comply with ICC/ANSI A117.1-2003 Accessibility Standards in U. S. A.. Manufacturer's service and parts manual shall be provided to the building owner/manager upon completion of project. The mounting plate dimensions are 6 1/8" width, 8 3/4" height. The bar is 28 3/4" length and 7 1/2" tall. I have more than one of these, please let me know if you're interested in more than one. Thanks for your interest!

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Bobrick
Product Type	Grab Bar
MPN	B-4998.99
