BOE Hydis15" HT15X23-110 TFT LCD Module w/CCFL backlight 3.3V power, US $79.00 – Picture 0
BOE Hydis15" HT15X23-110 TFT LCD Module w/CCFL backlight 3.3V power, US $79.00 – Picture 0

Boe Hydis15" Ht15x23-110 Tft Lcd Module W/ccfl Backlight 3.3v Power

US $79.00

  • Troy, New York, United States
  • Jan 29th
Open on mobile:
QR code
This is a new, from the manufacturer, BOE Hydis15" HT15X23-110 TFT LCD Module w/CCFL backlight 3.3V power Active area 304.128 (H) x 228.096(V) mm Number of pixels 1024(H) x 768(V) pixels Pixel pitch 0.297(H) x 0.297(V) mm Pixel arrangement RGB Vertical stripe Display colors 16,194,277 colors Display mode Normally Black Dimensional outline 331.6 x 254.7 x 17.3 mm - Weight 1,550 gram Back-light Bottom & Bottom side 4-CCFL type Surface treatment Haze 25, Anti-glare & hard-coating (3H) Power Supply Voltage: 3.0V to 3.6V (3.3V nominal) Features: LVDS Interface with 1pixel / clock High-speed response 6-bit FRC color depth, Display 16,194,277 colors Incorporated edge type back-light (4 lamp) High luminance and contrast ratio, low reflection and wide viewing angle DE (Data Enable) & H-Sync & V-Sync mode
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
Brand BOE Hydis
MPN HT15X23-110
Model HT15X23-110
Country/Region of Manufacture Korea, Republic of
