Boonton 72b 1mhz 1-3000 Pf Full Scale Analog Capacitance Meter

US $160

  • East Providence, Rhode Island, United States
  • Nov 7th
Description BOONTON 72B 1MHz 1-3000 pF F.S. Analog Capacitance Meter The Model 72B Capacitance Meter provides instant, direct reading, three terminal and differential capacitance measurements from 0.01 to 3000 pF. This coverage is divided into eight ranges, selected either by the front panel switch or remotely, arranged in a 1 - 3 - 10 sequence. The solid state design and crystal-controlled signal source contribute to the high stability and excellent reliability of the instrument. The 1 MHz test signal is held to a level of 15 mV r.m.s., allowing the measurement of capacitance of semiconductor devices. The provision for application of d.c. bias to either or both sides of the specimen makes it possible to measure these devices under normal operating conditions. The bias voltages can be applied either to the rear-panel terminals provided, or to the appropriate pins on the edge connector. Instruction Manual available here. Datasheet available here. The item is in good physical condition, but not working. It looks clean and undamaged inside and out, but no further testing was performed. Sold as-is for parts or repair. Shipping Weight (lbs.): 10 Click Here for Terms and Conditions of Sale
