Here's another great offer from MP-TRADINGS !! take a look !! I'm listing this time this BOSCH PTZ CCTV system analog surveillance camera. It has been removed from a working environment because of a system upgrade. Look the images what you see is what you will get. Here is the list of items and some manufacturer features: - BOSCH PTZ camera - metal pendant for camera - metal base to mount the camera Camera Signal System NTSC Image Sensor 1/4" Exview HAD CCD Number of Pixels 768 x 494 Lens 18x Zoom (4.1-73.8 mm) F1.4 to F3.0 Focus Automatic with manual override Iris Operation Automatic with manual override Field of View 2.7 to 48° Video Output 1.0 Vp-p, 75 Ohm Gain Control Off/Auto (with adjustable limit) Synchronization Line-Lock (-120° to 120° vertical phase adjust) or internal crystal Aperture Correction Horizontal and vertical Digital Zoom 12x Horizontal Resolution 470TVL Sensitivity Day Mode: SensUp Off 30 IRE: 0.4 lux 50 IRE: 0.7 lux SensUp On (15x) 30 IRE: 0.0041 lux 50 IRE: 0.0082 lux Night Mode SensUp Off 30 IRE: 0.05 lux 50 IRE: 0.17 lux SensUp On (15x) 30 IRE: 0.0007 lux 50 IRE: 0.0013 lux Electronic Shutter Speed 1 to 1/10,000 Signal-to-Noise Ratio >50dB White Balance 2000 K to 10,000 K Surge Suppression Protection on Video: Peak current 10 kA (Gas Tube Arrester), peak power 1000 W (10/1000 ?) Protection on RS-232/485, Biphase: Peak current 10 A, peak power 300 W (8/20 ?) Protection on Alarm Inputs: Peak current 17 A, peak power 300 W (8/20 ?) Protection on Alarm Outputs: Peak current 2 A, peak power 300 W (8/20 ?) Protection on Relay Outputs: Peak current 7.3 A, peak power 600 W (10/1000 ?) Protection on Power Input (Dome): Peak current 7.3 A, peak power 600 W (10/1000 ?) Protection on Power Output (Arm Power Supply): Peak current 21.4 A, peak power 1500 W (10/1000 ?) Miscellaneous Sectors/Titling 16 independent sectors with 20-character titles/sector Camera Setup/Control Biphase, RS-232, RS-485, Bilinx Communication Protocol Biphase, Bilinx, Pelco P, and Pelco D Pre-positions 99, each with 20-character titles Guard Tours 2 types of tours Recorded tours - 2 total duration 15 minutes Preset tour - 1 consisting of up to 99 scenes, consecutively and 1 customized up to 99 scenes Supported Languages Czech, Dutch, English, French, German, Italian, Polish, Portuguese, Russian and Spanish Cable Compensation Max Distance with Pre-comp OFF RG-59/U: 1000' (300m) RG-6/U: 1500'(450m) RG-11/U: 2000' (600m) Cat 5/UTP (Passive receiver): 750'(225m) Max Distance with Pre-comp ON RG-59/U: 2000' (600m) RG-6/U: 3000'(900m) RG-11/U: 4000' (1200m) Cat 5/UTP (Passive receiver): 1500'(450m) User Connections Power (Camera): 21-30 VAC, 50/60 Hz Power (Heater): 21-30 VAC, 50/60 Hz Biphase ±: Control Data Audio Line In: 9 K Ohm typ, 5.5 Vp-p max EOLR Alarm Inputs (2): Programmable for "normally open", "normally closed", "normally open-supervised", "normally closed-supervised" Alarm Inputs (5): Programmable for "normally open" or "normally closed" Relay Out (1): Dry contact output rating - 2 A @ 30 VAC Open Collector Outputs (3): 32 VDC @1 50 ma max Video: BNC Indoor Pendant IP Rating IP66 Pan Range 360° cont. Tilt Angle 18° above horizon Variable Speed 0.1-120°/s Pre-position speed Pan: 360°/s Tilt: 100°/s Preset Accuracy ± 0.1° typ. Power 21-30 VAC; 50/60 Hz Power Draw 15W Operating Temperature 14 to 104°F (-10 to 40°C) Storage Temperature -40 to 140°F (-40 to 60°C) Humidity 0 to 90% relative, condensing Weight 6.3 lb (2.88 kg) The Bosch AutoDome 500i Intelligent PTZ Camera System (Tinted, 24VAC, Pipe) includes an 18x day/night PTZ camera with a 4.1-73.8 mm lens, an indoor pendant enclosure, a tinted bubble, and a pipe mount. With a 1/4” Exview HAD CCD image sensor, the PTZ camera delivers clear images at resolutions up to 470TVL. With WDR function, the PTZ camera corrects extreme lighting environments marked by high-contrast and harsh backlit scenes. Integrated Autoscaling (proportional zoom) and Autopivot features allow the camera to automatically rotate and flip, ensuring optimal control. A removable IR cut filter enables the PTZ camera to switch between color and B&W as per the changes in ambient lighting. SensUp Control enhances the sensitivity by automatically reducing the shutter speed to 1 second. Coupled with advanced DSP, the camera provides smooth tracking of images, enabling real-time video processing. Supporting up to 10 individual regions of interest, Video Motion Detection triggers an alarm when motion is detected in a designated portion of the video display. Besides, the camera supports virtual masking to ignore areas of unwanted motion. Image Stabilization technique reduces blurring of images where the camera is subject to high frequency vibrations. The AutoDome PTZ camera uses rules-based logic to manage alarms wherein the rule defines which input activates which output. In addition, inputs and outputs with pre-defined and user-specified keyboard commands can be combined for performing advanced dome functions, and ensure that the standard software is ready to use for any application. Besides, the camera can handle 7 alarm inputs including 2 analog inputs that are programmed for EOLR (End-of-Line Resistor) supervision for real-time security applications. The system also supports 3 outputs where 1 relay is rated at 2A, and 3 additional open collectors are for driving external devices. Supporting 2 recording tours with up to 15 minutes recording duration, the camera can record the operator’s movements such as PTZ activities, which can be played back continuously. The preset tour feature is capable of handling 99 pre-positions with a configurable dwell time between pre-positions as well as customizing the order and frequency of each preset. The AutoDome has 360° per second pan/tilt speeds, and supports 99 pre-positions and 2 styles of guard tours - preset and record/playback. Privacy Masking is used to mask specific portions of a scene for security reasons and up to 8 masks can be displayed on the same scene where each masked area can be programmed with 3, 4, or 5 corners to hide more complex shapes. Besides, the camera gives you a choice of colors including black and white as well as allows you to blur the image that is required to be covered. The optional hybrid/IP configuration allows the camera to simultaneously stream IP video via LAN or WAN, and CVBS video via coaxial cabling. It also enables you to send network video streams over IP network, which can be viewed on the DiBos Digital Video Recorder, or on a PC running VIDOS video management software. Equipped with a tri-streaming feature, the camera provides independent streams simultaneously. It allows you to stream high-quality images for live viewing and recording at a reduced frame rate, and can simultaneously stream images to a remote PDA device. With the innovative CTFID (Configuration Tool for Imaging Devices), you can remotely change the camera’s settings as well as update firmware. The advanced built-in diagnostics ensures easy servicing and minimize downtime. You can use the OSD to quickly check the critical parameters such as internal temperature and input voltage level and verify if the dome is functioning within acceptable operating limits. With standard communication (Coax, UTP), the camera supports various standard video and data transmission methods such as Bilinx (over coax and UTP) remote control, configuration, and firmware updates. Equipped with an IP66-rated indoor pendant enclosure, the camera is suitable for operating in temperatures ranging from 14 to 104°F (-10 to 40° C). The camera system includes a rugged tinted bubble for enhanced image clarity with a recessed bubble latch to prevent vandalism. Allowing ample light, the tinted bubble offers maximum sensitivity. The AutoDome camera operates on 24VAC and includes a pipe mount for easy mounting. 1/4" Exview HAD CCD imager 18x zoom (4.1-73.8 mm) lens Provides high-quality imagery at resolutions up to 470TVL Fully interchangeable CPUs, cameras, housings, communications, and mounts WDR function - corrects extreme lighting environments marked by high-contrast and harsh backlit scenes Autoscaling automatically sets up the camera in a default position to view the object at the correct size AutoPivot feature automatically rotates and flips the camera to ensure optimal control Day/night ICR (Infrared Cut Filter Removal) function - switches between color and B&W as per changes in ambient lighting, ensuring accurate color reproduction in daylight and enhanced B&W images at night SensUp Control - enhances the sensitivity by automatically reducing the shutter speed to 1 second 360° per second pan/tilt speeds and supports 99 pre-positions and 2 styles of guard tours - preset and record/playback Preset tour can support up to 99 pre-positions with a configurable dwell time between pre-positions Customize the order and frequency of each preset Supports 2 recording tours with up to 15 minutes recording duration Supports menu languages such as English, French, German, Spanish, Portuguese, Italian, Dutch, and Polish Advanced DSP - provides smooth tracking of images, enabling real-time video processing Video Motion Detection - triggers an alarm when motion is detected in a designated portion of the video display Supports up to 10 individual regions of interest Innovative CTFID (Configuration Tool for Imaging Devices) for remotely changing the camera's settings as well as updating firmware Camera uses rules-based logic to manage alarms Inputs and outputs with pre-defined and user-specified keyboard commands can be combined for performing advanced dome functions Handles 7 alarm inputs including 2 analog inputs that are programmed for EOLR for real-time security applications Supports 3 outputs where 1 relay is rated at 2A, and 3 additional open collectors are for driving external devices Privacy Masking is used to mask specific portions of a scene for security reasons Up to 8 masks can be displayed on the same scene Each masked area can be programmed with 3, 4, or 5 corners to hide more complex shapes Optional hybrid/IP configuration allows the camera to simultaneously stream IP video via LAN or WAN and CVBS video via coaxial cabling IP66-rated indoor pendant enclosure Includes a rugged polycarbonate tinted bubble for enhanced image clarity Operates on 24VAC Includes a pipe mount for easy mounting Built-in diagnostics ensure easy servicing and minimize downtime Use the OSD to quickly check the critical parameters such as internal temperature and input voltage level and verify if the dome is functioning within acceptable operating limits Standard Communication for standard video and data transmission methods such as Bilinx (over coax and UTP) remote control, configuration, and firmware updates Cable compensation extends cabling distances Ease of installation and servicing Look at the pictures, what you see is what you will receive, all my items are been kept in a dust, humidity and smoke free environment. If need further details, do not hesitate to ask !! Take a look at my other listed items !! I can combine shipping costs. Bid with confidence on a 10+ years experienced ebayer with a 100% positive feedback !!! Terms and Conditions Please be sure to read Terms and Conditions before you bid on the item. If you have any questions, please contact me first. TERMS: Note that all items are used, unless otherwise stated, and are being sold in "as-is" condition with no warranties. Pictures below are of the actual item. Full payment is due within 48 hours after auction/listing's end with PayPal. If there will be any delay in payment, please let us know, it is just common courtesy. Your item(s) will be shipped 1-3 business days after receipt of a cleared payment. We are willing to combine shipping on items that can physically be shipped together to save our customers money. Free shipping (when offered) only apply to continental US.Warranty: No warranty or DOA return offered on this. When a warranty apply, the following is also not included on the guarantee: *. I do not pay return shipping. *. I do not reimburse shipping costs. *. I do not guarantee the following: a. Consider buyers inability to or lack or experience and knowledge to install and/or use the equipment purchased. b. Inability of a hardware item to function with a specific software application. c. I do not warranty toner/ink. If something is not included on the listing don't assume that is included. International sales Please email me for a shipping quote to your country prior to purchasing Import duties, taxes, and charges are not included in the item price or shipping cost. These charges are the buyer's responsibility. According the ebay buyer protection policies, I have to provide tracking number that on international transactions can't be provided as USPS does not offer the service to all the countries, then if this could be the case for your country, by reading this you accept that your item will be shipped without this service and also that certain international rules apply to specific countries, that means that I'm not responsible if your item can be retained at your customs Please check with your country's customs office to determine what these additional costs will be prior to bidding or buying. I will ship the item(s) well packaged and from a smoke / pet free environment.
