Bourns 3400s-1-102 1k Potentiometer Nos / New

US $48

Ottawa, Ontario, Canada
Jun 14th

Open on mobile:
QR code

Resistance 1 k Bourns 3400S-1-102 1k Potentiometer BOURNS 3400 PERCISION POTENTIOMETER 1K Electrical Characteristics Standard Resistance Range - 100 to 500 K ohms Total Resistance Tolerance - ±3 % Independent Linearity - ±0.15 % Effective Electrical Angle - 3600 ° +4 °, -0 ° Absolute Minimum Resistance - 1 ohm or 0.15 % maximum (whichever is greater) Noise- 100 ohms ENR maximum Dielectric Withstanding Voltage - MIL-STD-202, Method 301 Sea Level - 1,000 VAC minimum 80,000 Feet - 300 VAC minimum Power Rating (Voltage Limited By Power Dissipation, or - (40 °C) 5 watts 1,000 VAC, Whichever Is Less) - (125 °C) 0 watt Insulation Resistance (500 VDC) - 1,000 megohms minimum Resolution - See recommended part number Environmental Characteristics Operating Temperature Range +1 °C to +125 °C Storage Temperature Range -65 °C to +125 °C Temperature Coefficient Over Storage Temperature Range2 --- ±20 ppm/°C maximum/unit Vibration - 10 G Wiper Bounce - 0.1 millisecond maximum Total Resistance Shift - ±2 % maximum Voltage Ratio Shift - ±0.1 % maximum Shock - 50 G Wiper Bounce - 0.1 millisecond maximum Total Resistance Shift - ±2 % maximum Voltage Ratio Shift - ±0.1 % maximum Load Life - 1,000 hours, 5 watts Total Resistance Shift - ±2 % maximum Rotational Life (No Load) - 2,000,000 shaft revolutions2 Total Resistance Shift - ±5 % maximum Moisture Resistance (MIL-STD-202, Method 103, Condition B) Total Resistance Shift - ±2 % maximum IP Rating - IP 40 Mechanical Characteristics Stop Strength - 388 N-cm (550 oz.-in.) minimum Mechanical Angle - 3600 ° +4 °, -0 ° Torque (Starting & Running) - 1.4 N-cm (2.0 oz.-in.) maximum Mounting - 170-200 N-cm (15-18 lb.-in.) maximum Shaft Runout - 0.05 mm (0.002 in.) T.I.R. Lateral Runout - 0.13 mm (0.005 in.) T.I.R. Shaft End Play - 0.13 mm (0.005 in.) T.I.R. Shaft Radial Play - 0.06 mm (0.0025 in.) T.I.R. Pilot Diameter Runout - 0.05 mm (0.002 in.) T.I.R. Backlash - 1.0 ° maximum Weight - Approximately 110 gm Terminals - Gold-plated solder lugs Soldering Condition - Recommended hand soldering using Sn95/Ag5 no clean solder, 0.025 ” wire diameter. Maximum temperature 399 °C (750 °F) for 3 seconds. No wash process to be used with no clean flux. Markings Manufacturer’s name and part number, resistance value and tolerance, linearity tolerance, wiring diagram, date code Ganging (Multiple Section Potentiometers)- 2 cups maximum PRICE IS FOR 1.
