Brand New Arduino Uno R3 Board With Dip Atmega328p

US $23.00

Beverly Hills, California, United States
Jan 29th

Open on mobile:
QR code

Hi, Up for sale is new Arduino UNO R3 board with DIP ATmega328P. Retails for $40 and more. Buy now and Save. Item Description: The Arduino Uno is a microcontroller board based on the ATmega328 (http://www.atmel.com/dyn/resources/prod_documents/doc8161.pdf). It has 14 digital input/output pins (of which 6 can be used as PWM outputs), 6 analog inputs, a 16 MHz crystal oscillator, a USB connection, a power jack, an ICSP header, and a reset button. It contains everything needed to support the microcontroller; simply connect it to a computer with a USB cable or power it with a AC-to-DC adapter or battery to get started. The Uno differs from all preceding boards in that it does not use the FTDI USB-to-serial driver chip. Instead, it features the Atmega16U2 (Atmega8U2 up to version R2) programmed as a USB-to-serial converter. Revision 2 of the Uno board has a resistor pulling the 8U2 HWB line to ground, making it easier to put into DFU mode (http://arduino.cc/en/Hacking/DFUProgramming8U2). Revision 3 of the board has the following new features: 1.0 pinout: added SDA and SCL pins that are near to the AREF pin and two other new pins placed near to the RESET pin, the IOREF that allow the shields to adapt to the voltage provided from the board. In future, shields will be compatible both with the board that use the AVR, which operate with 5V and with the Arduino Due that operate with 3.3V. The second one is a not connected pin, that is reserved for future purposes. Stronger RESET circuit. Atmega 16U2 replace the 8U2. "Uno" means one in Italian and is named to mark the upcoming release of Arduino 1.0. The Uno and version 1.0 will be the reference versions of Arduino, moving forward. The Uno is the latest in a series of USB Arduino boards, and the reference model for the Arduino platform; for a comparison with previous versions, see the index of Arduino boards (http://arduino.cc/en/Main/Boards). Summary MicrocontrollerATmega328 Operating Voltage5V Input Voltage (recommended)7-12V Input Voltage (limits)6-20V Digital I/O Pins14 (of which 6 provide PWM output) Analog Input Pins6 DC Current per I/O Pin40 mA DC Current for 3.3V Pin50 mA Flash Memory32 KB (ATmega328) of which 0.5 KB used by bootloader SRAM2 KB (ATmega328) EEPROM1 KB (ATmega328) Clock Speed16 MHz
