RIGOL DG1022U Signal Generator 2 Channel 25 MHz Function Waveform Signal Generator DG1022U DG1000 series function/arbitrary waveform generators use Direct Digital Synthesis (DDS) technology. They could generate accurate, stable, clean, low distortion signals. Features: Adopt advanced DDS technology; dual channel output; 100 MSa/s maximum sampling rate; 14 bits vertical accuracy Output 5 standard waveforms; built-in 48 arbitrary waveforms Abundant modulation functions: AM, FM, PM, FSK, linear/logarithm sweep and burst Abundant output and input: waveform output;synchronous signal output; external modulation source, external 10 MHz reference clock input,external trigger input Unique channel coupling and channel copy Built-in high precision and wide band counter, the measurement range: 100 mHz ~ 200 MHz (single channel) Standard configuration interfaces: USB Device & USB Host, and support U-disc storage Seamlessly interconnect with DS1000 series digital oscilloscope Powerful arbitrary waveform editing software "UltraWave" Support remote control by commands A variety of display modes Clear graphical interface Support Chinese and English menu and input Button-help makes information getting easier File management (support for USB flash device and local storage) Specifications: General: Display Display Type Black and White LCD Screen Display Resolution 256 Horizontal x 64 Vertical Grey Degree 4 Level Grey Display Contrast (typical) 150 : 1 Backlight Brightness 300 nit (typical) Power Supply Supply Voltage 100 ~ 240 VACRMS, 45 ~ 440 Hz, CAT II Power Consumption Less than 40 W Fuse 2 A, T Level, 250 V Environment Operation: 10C ~ +40C Ambient Temperature Non-operation: -20 ~ +60C Cooling Method Natural cooling Below +35C:=<90% relative humidity Humidity Range +35C~+40C:=<60%relative humidity Operation: below 3,000m Height above sea level Non-operation: below 15,000m Mechanism Dimension Width 232 mm Height 108 mm Depth 288 mm Weight Net Weight 2.65 kg Gross Weight 4 kg Frequency Waveforms Sine, Square, Ramp, Pulse, Noise, Arb DG1022 DG1022U Sine 1uHz ~ 20 MHz 1uHz ~ 25MHz Square 1uHz ~ 5 MHz 1uHz ~ 5MHz Pulse 500uHz ~ 3 MHz 500uHz ~ 5MHz Ramp/Triangle 1uHz ~ 150 kHz 1uHz ~ 500kHz White Noise 5 MHz bandwidth (-3 dB) 5MHz bandwidth (-3dB) Arb. 1uHz ~ 5 MHz 1uHz ~ 5MHz Resolution 1uHz +-50 ppm in 90 days Accuracy +-100 ppm in 1 year 18C ~ 28C Temperature Coefficient < 5 ppm/C Sine Wave Spectrum Purity CH1 CH2 Harmonic Distortion =<1 Vpp >1 Vpp =<1 Vpp >1 Vpp DC-1 MHz -45 dBc -45 dBc -45 dBc -45 dBc 1 MHz - 5 MHz -45 dBc -40 dBc -45 dBc -40 dBc 5 MHz - 20 MHz -45 dBc -35 dBc -45 dBc -35 dBc Total Harmonic Distortion DC ~ 20 kHz, 1 Vpp <0.2% Spurious Signal DC ~ 1 MHz < -70 dBc (non-harmonic) 1 MHz ~ 10 MHz < -70 dBc + 6 dB/octave Phase Noise 10kHz Offset, -108 dBc / Hz (typical) Square Wave Rise/Fall Time < 20 ns (10% ~ 90%), (typical, 1 kHz, 1 Vpp) Overshoot < 5% (Typical, 1 kHz, 1 Vpp) 1uHz ~ 3 MHz: 20% ~ 80% Duty Cycle 3 MHz (not contain) ~ 4 MHz: 40% ~ 60% 4 MHz (not contain) ~ 5 MHz: 50% Asymmetry 1% of period + 20 ns (typical, 1 kHz, 1 Vpp) (below 50% Duty Cycle) Jitter 6 ns + 0.1% of period (typical, 1 kHz, 1 Vpp) Ramp Wave Linearity < 0.1% of peak output (typical, 1 kHz, 1 Vpp, 100% Symmetry) Symmetry 0% to 100% Pulse Wave Pulse Width 2000 s max period; 20 ns min period; 1 ns resolution Overshoot < 5% Jitter 6 ns + 100 ppm of period Arb Wave CH1 CH2 Waveform Length 4k points 1k points Vertical Resolution 14 bits (including sign) 10 bits (including sign) Sampling Rate 100 MSa/s 100 MSa/s Minimum Rising /Falling 35 ns (Typical) 35 ns (typical) Time Jitter (RMS) 6 ns + 30 ppm (typical) 6 ns + 30 ppm (typical) Nonvolatile Storage 10 waveforms 10 waveforms (Total:10 Waveforms) Output Characteristics DG1022 DG1022U Amplitude (50ohm) CH1 CH2 CH1 CH2 2 mVpp ~ 10 2 mVpp ~ 3 =<20MHz: 2 mVpp ~ 3 Vpp Vpp Vpp 2 mVpp~10 Vpp; >20MHz: 2 mVpp~5 Vpp; Vertical Accuracy (1 kHz ±(2% of setting +2 mVpp) Sine) [1] Amplitude Flatness <100 kHz: 0.1 dB <100 kHz: 0.1 dB (relative to 1 kHz, 5 Vpp 100 kHz ~ 5 MHz: 0.15 dB 100 kHz ~ 5 MHz: 0.15 dB Sine wave) [1] 5 MHz ~ 20 MHz: 0.3 dB 5 MHz ~ 25 MHz: 0.3 dB DC Offset CH1 CH2 5 V (50ohm) 1.5 V (50ohm) Range (DC) 10 V (High Z) 3 V (High Z) Offset Accuracy +-(2% of the |Offset Setting | + 2 mV) Waveform Output CH1 CH2 Impedance 50ohm (typical) 50ohm (typical) Protection [2] Short-circuit protected, Short-circuit protected overload relay automatically disables main output AM (CH1) Carrier Waveforms Sine, Square, Ramp, Arb (except DC) Source Internal/ External Modulation Waveforms Sine, Square, UpRamp, DnRamp, Triangle, Noise, Arb (2 mHz to 20 kHz) Depth 0% ~ 120% FM (CH1) Carrier Waveforms Sine, Square, Ramp, Arb (except DC) Source Internal/ External Modulation Waveforms Sine, Square, UpRamp, DnRamp, Triangle, Noise, Arb (2 mHz to 20 kHz) Frequency Deviation DC ~ 10 MHz PM (CH1) Carrier Waveforms Sine, Square, Ramp, Arb (except DC) Source Internal/ External Modulation waveforms Sine, Square, UpRamp, DnRamp, Triangle, Noise, Arb (2 mHz to 20 kHz) Phase Deviation 0 ~ 360degree FSK (CH1) Carrier Waveforms Sine, Square, Ramp, Arb (except DC) Source Internal/ External Modulating Waveforms 50% duty cycle square (2 mHz to 50 kHz) Sweep (CH1) Carrier Waveforms Sine, Square, Ramp, Arb (except DC) Type Linear or Logarithmic Direction Up or Down Sweep Time 1 ms to 500 s +- 0.1% Trigger Source Internal/External/Manual Burst (CH1) Waveforms Sine, Square, Ramp, Pulse, Noise, Arb (except DC) Types Count (1 to 50,000 periods), infinite, gated Start Phase -180 degree to +180 Internal Period 1 us - 500 s ± 1% Gate Source External Trigger Trigger Source Internal/External/Manual Rear Panel Connector[3] +- 5 Vpk = 100% modulation External Modulation 5kohm input impedance External Trigger TTL compatible Trigger Input Input Level TTL compatible Slope Rising or falling (selectable) Pulse Width > 100 ns Input Impedance > 10kohm, DC coupled Sweep: < 500 us (typical) Latency Burst: < 500 ns (typical) Trigger Output Electrical Level TTL compatible Pulse Width > 400 ns (typical) Output Impedance 50ohm(typical) Maximum Rate 1 MHz Sync Output (CH1) Electrical Level TTL compatible Pulse Width > 50 ns (typical) Output Impedance 50ohm (typical) Maximum Frequency 2 MHz Counter Specification Function Frequency, period, positive/negative Pulse width, Duty cycle Frequency Range Single channel: 100 mHz ~ 200 MHz Frequency Resolution 6 digits/second Voltage Range and Sensitivity (non-modulation signal) Auto mode 1 Hz ~ 200 MHz 200 mVpp ~ 5 Vpp DC offset range +-1.5 VDC DC 100 mHz ~ 100 MHz 20 mVRMS ~ +-5 Vac+dc coupled Manual mode 100 MHz ~ 200 MHz 40 mVRMS ~ +-5 Vac+dc AC 1 Hz ~ 100 MHz 50 mVpp ~ +-5 Vpp coupled 100 MHz ~ 200 MHz 100 mVpp ~ +-5 Vpp Pulse width and Duty cycle 1 Hz ~ 10 MHz (100 mVpp ~ 10 Vpp) Measure Input impedance 1 M? Coupling mode AC, DC Input adjust High frequency restrain High frequency noise restrain (HFR) On or Off sensitivity Low, Medium, High The trigger level can adjust manually/ automatically Trigger mode Trigger level range: +-3 V (0.1% to 100 %) Resolution: 6 mV Accessories: Power cord, BNC cable, software PAYMENT INFORMATION: 1.We can accept Credit Cards,Paypal,T/T,Escrow and so on. 2.The buyer is responsible for any tax and/or duty charged by their country. INTERNATIONAL SHIPPING: The package will be shipped by DHL, FEDEX or EMS. After we shipped the parcel,we'll fill in the tracking number and inform you by e-mail.Please write the correct address and telephone number when you make orders,so the courier can contact you when they deliver the parcel to you. thanks WARRANTY INFORMATION: 1.All the products have been checked and packed in good condition before dispatch. 2.All the products with one year warranty. 3.If you find any quality problems,please send it back within 3 days,and we'll send you a new one or refund you the payment after we get the returned one. 4.Buyers have to pay for the return cost and we will pay the cost for resend 5.All products returned should be in new conditions. CONTACT US: Office Tel: 008675527541660 Cellphone: 008615967476818 1.A good feedback is very important for our store,if you feel satisfied with our products,please give us positive feedbacks. 2.Please contact us before leaving any negative or neutral feedback,We will work with you to solve any problems.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Rigol
Country of Manufacture	China
Model	DG1022U
