Broekx 3 Axis Cnc Maxi Router Table Plans Milling, Drilling And Engraver Machine

US $42.50

Crystal Brook, SA, Australia
Jan 30th

Open on mobile:
QR code

CNC Maxi Router Plans This is not a kit, plans only Why not build your own CNC router/engraver with easy to follow comprehensive Scaled Drawings at a fraction of the cost of a bought machine? As the builder of this machine you will understand how it works and take pride in the completed project. Drilling and cutting dimension of all components are supplied, with a comprehensive material list with exploded views on how to assemble. A full set of electrical drawings are included Key Features Dual Motors and Ball screw on Y Axis. 1605 Anti backlash Ball screw on all axis. SBR20mm Linear Rail on axis X and Y. Two linear rails either side on Y Axis. 16mm Linear Rail on Z Axis. Ball screw and linear rails on Y axis are below work surface to reduce the ingress of dust and shavings. The machine uses NEMA-34 (8.7N.m 1232 oz/in. Holding torque) stepper motors. This unit can be scaled up if required. Specifications Size of work piece X Axis 750mm (29-1/2”) Y Axis 1040mm (41”) Z Axis 140mm (5-1/2”) Work surface size Width 900mm (29-1/4”) Table size . . . . . . . . . . . . . . . . .1200 x 900mm (48 1/2" x 35 1/4") Height . . . . . . . . . . . . . . . . . . . . 1465mm (57 1/2") Width . . . . . . . . . . . . . . . . . . . . 1035mm (40 1/2") Depth . . . . . . . . . . . . . . . . . . . . 1300mm (51") These easy to follow plans will be sent to you electronically via email as soon as confirmation of payment is received. You will receive the detailed plans, material list and electrical drawings to construct your own CNC Router. This is not a Kit, Plans Only License to build one CNC-Maxi Router.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	BROEKX
Country/Region of Manufacture	Australia
Model	CNC-MAXI
