Bronze-fitted Turbine Pump

US $595.00

Skokie, Illinois, United States
Jan 30th

Open on mobile:
QR code

Warehouse Closing Down Sale! Retail Price: $1,150 Turbine Pump, Bronze-Fitted, 1 HP, 1 Phase, Voltage 115/230, Inlet 1 1/4 In., Outlet 1 In., Max. Pressure 300 PSI, Length 16 1/4 In., Height 8 1/16 In., Width 6 3/4 In. Turbine Pumps Feature Type 21 mechanical seals and an easily accessible drain plug. Ball bearings on shaft for longer life. Suitable for industrial and commercial applications, boiler feed, condensation return, pressure service, water treatment, reverse osmosis filtration, spray equipment, and liquid transfer. Liquid temp. range: -20 to 230 F 3450 rpm motors Bronze impellers Max. specific gravity: 1.0 Cast Iron Impellers have balancing holes to help eliminate side wear and reduce the need for external adjustments. Include cast-iron motor bracket with replacement bronze sleeve. Wetted materials are cast iron, bronze, carbon, ceramic, and Buna. 4P913, 4P915, 4P916, 4UP52, 4UP53, 4UP60, 4UP61, and 4UP66 handle vapors up to 20% by volume, to minimize vapor lock. NEMA 56C Specs Item Turbine Pump Type Bronze-Fitted HP 1 Phase 1 Voltage 115/230 Inlet (In.) 1-1/4 Outlet (In.) 1 Motor Enclosure ODP NEMA/IEC Frame 56C Motor Type Cap-Start, ODP Wetted Materials Cast Iron, Bronze Fitted Impeller Material Bronze Housing Material Cast Iron Volute Material Cast-Iron, Bronze Fitted Screw Material Steel Seal Type Type 21 Seal Material Carbon, Ceramic, Buna Seal Application Low Flow, High Head Max. Liquid Temp. (F) -20 to 230 GPM @ 10 PSI 11.1 GPM @ 20 PSI 10.8 GPM @ 30 PSI 10.6 GPM @ 50 PSI 10.2 GPM @ 60 PSI 10 GPM @ 75 PSI 9.4 GPM @ 100 PSI 9.0 Max. Pressure (PSI) 300 Best Efficiency GPM @ Head (Ft.) 8.4 GPM @ 130 PSI Best Efficiency Range GPM @ Head (Ft.) 7.0-10.0 GPM @ 190-60 PSI Max. Specific Gravity 1.00 SP Max. Case Pressure (PSI) 300 Max. Fluid Viscosity 250 SSU Inlet Pressure (PSI) 200 Impeller Type Regenerative Turbine Bearing Type Sealed Ball Bearing (Motor Bearing) Duty Continuous Max. Dia. Solids (In.) 25 Microns Port Rotation 90 Increments Drain Plug 180 From Inlet Port Agency Compliance UL and CSA on Motor Only Application For Boiler Feed and Condensate Return Service, Low Flow, Pumping Clean Fluids, Nonflammable Liquids Compatible with Pump Component Materials Length (In.) 16-1/4 Height (In.) 8-1/16 Width (In.) 6-3/4 Includes Cast Casing with Bronze Impeller UNSPSC 40151526 Weight 43.500000

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Dayton
Power Source	Electric
Model	4P916
Type	Industrial
MPN	4P916
Country/Region of Manufacture	United States
Application	Industrial
