Brooktrout Dialogic D/41jct-ls 4-port Voice Fax Board Card Pci D41 D41jct Pbx

US $970

San Diego, California, United States
May 28th

Open on mobile:
QR code

Brooktrout Dialogic D/41JCT-LS 4-Port Voice Fax Board Card PCI D41 D41JCT PBX We gladly ship Worldwide* Scroll down for more Photos and details Brooktrout/Intel/Dialogic Intel Dialogic D/41JCT-LS - Voice/fax board Intel Dialogic D 41JCT-LS - Voice/fax board Sprachschnittstellenkarte - PCI D/41JCT-LS International 4-port PCI voice processing with CT Bus. P/N 96-0642-011 Item is in good condition. D/41JCT-LS 4-Port PCI Voice Processing Board The D/41JCT-LS board is a four-port analog converged communications voice processing board ideal for developers building enterprise unified messaging and interactive voice response (IVR) applications for the global market. The D/41JCT-LS provides four telephone line interface circuits for direct connection to analog loop start lines. A unique, dual-processor architecture, comprising a digital signal processor (DSP) and a general-purpose microprocessor, handles all telephony signaling and performs DTMF (touchtone) and audio/voice signal processing tasks. The D/41JCT-LS board, a part of the Dialogic PCI product family, conforms to the H.100 CT BusTM standard. The open architecture enables developers to build converged communications solutions using products from multiple vendors. And since you can install multiple D/41JCT-LS boards in a single PC chassis, you can build systems scaling up to 32 ports. Downloaded SpringWareTM firmware algorithms, executed by the onboard DSP, provide variable voice coding at 24 and 32 Kb/s ADPCM, and 48 and 64 Kb/s or A-law PCM, as well as to A-law conversion. Sampling rates and coding methods are selectable on a channel-by-channel basis. Applications may dynamically switch sampling rate and coding method to optimize data storage or voice quality as the need arises. Additional coding algorithms such as GSM and G.726 are available for use in applications that support the Voice Profile for Internet Mail (VPIM) standard. SpringWare firmware also provides reliable DTMF detection, DTMF cut-through, and talk off/play off suppression over a wide variety of telephone line conditions. Dialogic Global Dial Pulse DetectionTM (Global DPDTM) algorithm, available as a software option for the D/41JCT-LS board, lets you use the board in countries that have limited touchtone telephone service. The Global DPD product can be optimized on a country-by-country basis to provide superior dial pulse detection. Dialogic voice products offer a rich set of advanced features, including state-of-the-art DSP technology and signal processing algorithms, for building the core of any converged communications system. With industry-standard PCI bus expansion boards you can integrate Dialogic voice products easily and cost effectively into exactly the type of system you require, with superior performance. Features and Benefits Four independent voice processing ports in a single PCI slot for low- to medium-density enterprise CT applications With approvals in North America, Europe, and Japan, the D/41JCT-LSTM board cost effectively expands an application's ability to serve several global markets (other international approvals pending) CT BusTM connector increases the board's capacity to interoperate with other CT Bus/SCbusTM compatible boards SCSATM SCbusTM connectivity through a simple cable adapter enables applications to access additional resources such as text-to-speech (TTS) and automatic speech recognition (ASR) Universal PCI edge-connector for compatibility with 3.3 volt and 5.0 volt bus signals, enables deployment in a wide variety of PCI chassis from popular manufacturers Plug and Play ready. Simplifies hardware installation by eliminating DIP switches and jumper settings and enabling software controlled configuration. Configure multiple boards in a single chassis, PCI bus or mixed PCI/ISA bus, for easy and cost-effective system expansion up to 32 analog ports Dialogic SpringWareTM firmware, downloadable signal and call processing firmware, provides field-proven performance based on over three million installed ports with access to future feature enhancements PerfectDigitTM DTMF (touchtone) provides reliable detection during voice playback - lets callers "type-ahead" through menus A-law or voice coding at dynamically selectable data rates, 24 Kb/s to 64 Kb/s, selectable on a channel-by-channel basis for optimal tradeoff between disk storage and voice quality International Caller ID capability via on-hook audio path. Supports Bellcore CLASSTM, UK CLI, Japanese Caller ID, and other international protocols. Patented outbound call progress analysis monitors outgoing call status quickly and accurately C language application program interfaces (API) for Windows NT/Windows 2000 and UNIX/Linux shorten the development cycle for faster time to market Supports the PBXpert32TM tool, a free software utility that simplifies switch integration Optional onboard Global Dial Pulse DetectionTM (Global DPDTM) feature enables callers with non-touchtone phones to access applications without additional "pulse-to-tone conversion" equipment Applications Voice messaging Interactive voice response Call center Audiotex Operator services Dictation Auto dialers Notification systems Online data entry/query Technical Specifications Number of ports4 Maximum boards/system8 Analog network interfaceOnboard loop start interface circuits Resource sharing busCT Bus, SCbus compatible with bus adapter Control microprocessor80C186 @ 34.8 MHz Digital signal processorMotorola DSP56303 @100 MHz, with 128Kx24 private SRAM HOST INTERFACE: Bus compatibilityPCI. Complies with PCISIG Bus Specification, Rev. 2.1. Bus speed33 MHz max. Bus modeTarget mode operation only Shared memory32 KB page I/O portsNone TELEPHONE INTERFACE Trunk typeLoop start Loop current range20 to 120 mA Impedance600 Ohms nominal Ring detection15 Vrms min., 13 to 68 Hz (configurable by parameter) Echo return lossConfigurable by software parameter Crosstalk couplingLess than -70 dB at 1 KHz channel to channel Receive signal/noise ratio70 dB referenced to -15 dBm Frequency response200 Hz to 3400 Hz dB (transmit and receive) ConnectorFour RJ-11 type POWER REQUIREMENTS: +5 VDC750 mA max. +12 VDC200 mA max. -12 VDC100 mA max. Operating temperature0C to +50C Storage temperature-20C to +70C Humidity8% to 80% non-condensing Form factorUniversal slot (5 V or 3.3 V) PCI long card, 12.3 in. long (without edge retainer) or 13.3 in. long (with edge retainer), 0.79 in. wide (total envelope), 3.87 in. high (excluding edge connector) SAFETY & EMI CERTIFICATIONS: United StatesFCC Part 15 class A; FCC Part 68 EBZUSA-75385-VM-T UL: E96804 UL1950 CanadaDOC: 885-5542A Don't forget to place your bid. More photos down below By bidding on this auction you agree to the following terms: Shipping Terms: Buyer pays all shipping costs. Let us know if there is an issue with the shipping costs, as they are automatically calculated by ebay. Shipments made to California must include 8.00% sales tax unless we are provided with a valid resale certificate. We reserve the right to ship with Fedex , USPS, UPS and any other carrier in the best interests of both the buyer and seller. If the shipping cost quoted is over $150, that means it will be shipped freight, and the price quoted is for pickup at a freight terminal nearby your location (usually within 25 mi if you are in a major metro US city). if you need residential delivery, or if you don't have a forklift/loading dock the price will be higher in some cases. Payment Terms: Payment is to be made by PayPal Please contact us if you have any payment questions. Payment is to be received within ten days of close of auction. Should payment not be received within ten days the item will be re-listed and high bidder will forfeit. International Terms: (These terms only apply to international shipments.) Buyer is responsible for all brokerage, customs, and or duty charges. *Not all items are available for international shipment due to import/export regulations. In the event that we are unable to ship to buyers country, buyer will receive a full refund. Payment must be made in US Dollars. Warranty Terms: Returns are available up to 14-days from receipt. What you see in the picture(s) is what you get nothing more nothing less. Test results of item(s) in auction are described to the best of our ability in the ad. The results of all tests that are performed are disclosed in the ad. Items sold as "Untested" are simply that we have been unable to fully test the item(s) due to missing cables/adapters/toner cartridge/ksu/etc, lack of time, or other restrictions. We guarantee that you will receive the make and model listed in the ad. The maximum liability of Best Stuff To You is the high bid +shipping cost of the auction listing. Return Terms: Returns are allowed and must be filed within 14 days of receipt of shipment. Item should be returned in the original box and packaging . Bidder must request a RMA number and return address before returning item(s). All new/sealed toner cartridges are sold as-is with No returns unless returned unopened. As a company policy, we do not cancel transactions through ebay. send a message if you have any questions. We wont leave you stuck without a solution Medical Device Terms: The following terms apply to any and all medical items or any item offered for sale in any medical category or any item that eBay deems these terms are applicable to: The sale of this item may be subject to regulation by the U.S. Food and Drug Administration and state and local regulatory agencies. If so, you should not bid on this item unless you are an authorized purchaser. If the item is subject to FDA regulation, I will verify your status as an authorized purchaser of this item before shipping of the item. The buyer will not hold the seller, eBay or the item's manufacturer responsible for the appropriate or inappropriate use of this device either by the user or a third party. Once purchased, it is the sole responsibility of the purchaser to assume any and all liability from the use of this device. Please note before bidding that any medical equipment purchased should be completely tested by a qualified biomedical technician prior to being put into service Contact Information Dan Rydell in San Diego, CA, USA Phone: 619-519-0869 ebay name: untested_condition Item Condition Terms: On these listings, our company's condition "used" does NOT necessarily mean "fully operational and functions as intended". If fact it may have unknown flaws and deficiencies. the item has only been tested to the extent described in the item condition/testing notes. Additional testing may be performed upon request of the buyer before shipment to ensure a satisfactory transaction for both parties. If any provision of this Auction Contract is held unenforceable, All remaining provisions of this Contract shall remain in full force and effect. Copyright 2015 untested_condition- All Rights Reserved. Auction Wizard 2000 - The Complete Auction Management Software Solution
