Brother TC-324 CNC Drilling / Milling / Tapping Machine 1996 With Video, US $1100 – Picture 0
Brother TC-324 CNC Drilling / Milling / Tapping Machine 1996 With Video, US $1100 – Picture 0

Brother Tc-324 Cnc Drilling / Milling / Tapping Machine 1996 With Video

US $1100

  • Lake Saint Louis, Missouri, United States
  • Jun 23rd
Open on mobile:
QR code
Brother TC-324 CNC Drilling / Milling / Tapping Machine 1996 With Video Specification: Description: PALLET SIZE (2): 19.69" X 11.81" TRAVEL: X- AXIS: 16.5 IN. TRAVEL: Y-AXIS: 12.6 IN. TRAVEL: Z- AXIS: 10.6 IN. SPINDLE SPEEDS (10): 10,000 RPM MAX TAPPING SPEED: 6,000 RPM SPINDLE TAPER: BT-30 # OF TOOL POSITIONS: 14 SPINDLE NOSE TO TABLE: MIN: 7.48 IN. SPINDLE NOSE TO TABLE: MAX: 17.71 IN. TABLE LOAD CAPACITY: 388 LBS. RAPID TRAVERSE RATES: 1,181 IPM PALLET CHSNGE TIME: 2.8 SEC. MAX TOOL DIAMETER: 3.1 IN. MAX TOOL LENGTH: 3.15 IN. MAX TOOL WEIGHT: 7.87 LBS. APPROX, DIMENSIONS: 55.12 IN X 120.79 IN. APPROX. HEIGHT: 94 IN. APPROX. WEIGHT: 6,173 LBS Equipped With: BROTHER CNC CONTROL AUTO 180 DEGREE PALLET CHANGER RIGID TAPPING 14 STATION FAST ATC G CODE AND CONVERSATIONAL PROGRAMMING FULL SET MANUALS USB MEMORY STICK READER DUAL PUMP FLUSH AND FLOOD COOLANT SYSTEM Link to YouTube video of machine running: https://youtu.be/_-Cqm_j9Ipg Machine Is Available For Inspection Under Power By Appointment. For Questions Call John 314-398-7414. Buyer Is Responsible For All Freight Arrangements And Cost. ALL ITEMS ARE SOLD AS IS, WHERE IS Stock 8363
