Bs-0 Semi-universal Quick Dividing Indexing Head With Tail Stock For Cnc Milling

US $16000

ShenZhen, China
May 31st

Open on mobile:
QR code

Semi-Universal dividing head with a tail stock Description 1.Dividing Head can divide in any angle by the direct,indirect,or diffrenet methods.Th ratio between the warm and the warm gear is 40:1. 2.Hardened and ground spindle is rigidly held in a taper roller bearings.Worm is hardened and ground also. 3.The swivel head can be locked of any angle from 10X below horizontal to 90X vertical-precision fitting to base assures smooth rotation. 4.All models have threaded spindle nose and 24 hole dividing plate with easy conversion to fast direct indexing on numbers 2,3,4,6,8,12 and 24. 5.Easy indexing of all numbers from 2 to 50 and many numbers from 52 of 380. 6.Accurate precision,little backlash,fine appearance and strong structure so can assure smooth rotation. 7.The center cutting/milling can be implemented with the help of the optional 3-jaw chuck. Specifications Semi-universal dividing head (head stock) Unit: mm A B H h a b g Center taper Diameter of spindle hole N.W(kg) 189 140 173 100 160 91 16 No. 7 18 24 Semi-universal dividing head (tail stock) Unit: mm A1 B1 H1 h a1 b1 g1 167 80 107.5 100 130 92 13 Holes Numbers of the dividing plate (worm gear reduction ratio 1:40,) Plate A 15 16 17 18 19 20 Plate B 21 23 27 29 31 33 Plate C 37 39 41 43 47 49 It includes such parts: 1pcs head stock; 1pcs tail stock; 1pcs 3-Jaw chuck(standard 4" 3-jaw chuck and optional 5" 3-jaw chuck); 2pcs dividing plate. There is a 4" 3-jaw chuck coming with the dividing head. There is also 5" 3-jaw chuck optional,it's 48USD more than that 4" 3-jaw chuck. Before pay,please tell us the size of the 3-jaw chuck you want,then we can send you the suitable one.
