Bth Industrial Pellet Bagging Line: Bth-pcd-1500, Bth-vvf-1600-nn, Rainbow, 2007

US $475,000.00

Toledo, Ohio, United States
Jan 30th

Open on mobile:
QR code

All sales "Where Is, As Is." Please contact us at 647-864-9341 for convenient domestic, continental and worldwide shipping options and other important details. Thank you kindly. BayShore Groups. This used Bag Treatment / Bulk Bag Filling line last ran wood pellets and is located in West Monroe, Louisiana. It is manufactured by Bag Treatment Holland BV. The line consists of the BTH-VVF-1600-NN vertical form fill seal bagger, the BTH-PCD-1500 palletizer and the BTH-Rainbow stretch hooder. It was purchased in 2007, installed in 2008, and ran for approximately 2 years bagging close to 60,000 short tons. It has not been used in some time but is in good condition and should run without any issues. It bags at a rate of 18-20 tons per hour stacking 1 ton per pallet, equating to 15-17 bags per minute. It was sized for a production facility of 60,000 short tons of annual production. Last ran 40 x 48 pallets. Manuals for all three components are available in PDF. All parts are still professionally serviceable: “If you own BTH BV equipment, Premier Tech's Industrial Equipment Group offers complete aftersales service and parts for this brand. As a result, BTH BV equipment users now have access to a specialized after-sales team with a global reach.” – direct quote off of Premier Tech’s website. Specification Description BTH-PCD-1500 Max Capacity 1200 Bags/Hr 3 bags per layer 1500 Bags/Hr 5 Bags per layer Length Filled bag (min. - max) 595-595 mm Width Filled bag (min. - max) 400-400 mm Thickness Filled bag (min. - max) 140-140 mm Surround temperature (min - max) 5-40* C Electrical 480, 3 Phase 60 HZ PLC Voltage 24 DC Pneumatic - Min. Pressure 6 bar Pneumatic - Max. Pressure 7 bar Controller - Type of PLC Sigmatek Type of control panel Sigmatek ET 243 BTH-VVF-1600-NN Capacity 1200-1300 Bags/Hr Type of product Granulate Specific Gravity 0.65-0.70 kg/dm3 Weighing/Volume range 10-25 Kg/l Foil type Flat Foil Foil Material PE Min. bag length (empty) 400 mm Max. bag length (empty) 1000 mm Min. Bag width (empty) 190 mm Max. Foil Width 1400 mm Max. bag Width (empty) 580 mm Max. Gusset depth 5-40 mm Temp. of surroundings (min - max) 5-40' C BTH-Rainbow Min. Capacity 20 pallets/hr Max. Pallet Load (L x W) Max. 50 mm Ambient Temp (min - max) 5*-40* C Type of foil lay flat tube w/side fold Hood Material PE Stretch foil Max Loading Height (incl. pallet) 2200 mm Min. Loading Height (incl. pallet) 500 mm Max. Loading Weight 1500 Kg Foil Dimensions (max) 1100 + 2x425 mm (min) 820 + 2x260 mm Foil Window Width 300 mm Weight of foil roll (max) 1000 mm Weight of foil Roll 800 kg Core Diameter of foil roll 76 & 152 mm Type of PLC Siemens S7 Type of Control Panel Siemens TP 177

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Brand	Bag Treatment Holland BV \| Premier Tech
MPN	BTH-VVF-1600-NN \| BTH-PCD-1500 \| BTH-Rainbow
Model	BTH-VVF-1600-NN \| BTH-PCD-1500 \| BTH-Rainbow
Country/Region of Manufacture	Netherlands
