Build Your Own Plans-2" Turret Tool Post Fits Atlas,south Bend,7 X 16 Mini Lathe

US $210

  • Buffalo, Minnesota, United States
  • May 24th
Open on mobile:
QR code
BUILD YOUR OWN PLANS--2" TURRET TOOL POST fits 7 X 12 MINI LATHE, ATLAS, SOUTH BEND, LOGAN LATHES, UNIMAT, & All lathes up to 9" SWING 2" square turret block holds (4) 1/4" tools (tool slot size is 5/16")  24 position positive indexing with detents every 15 degrees Robust construction Customizable to fit any lathe (.472") minimum vertical distance required from the centerline of spindle to the top of cross slide or compound) Repeatable Rigid Smooth and positive operation. The turret block is raised up and off the detents while turning the handle and locks down solidly. There are no springs to fail. Saves set up time on the lathe. Design lends itself to construction methods that are within the reach of the home shop machinist possessing a lathe with milling attachment. Clear fully detailed CAD drawings(8) 8-1/2" X 11" pages (printed both sides) and construction notes (5) 8-1/2' X 11" pages (printed both sides). Build Your Own Plans Only -ACTUAL ITEM IS NOT FOR SALE - Requires Machining.
