Bull Nose - Bullnose Live Center For Unimat 3 Lathes - M14 - From Lathecity

US $97

Fargo, North Dakota, United States
Jun 9th

Open on mobile:
QR code

Bullnose Live Center for UNIMAT 3 Lathes - from LatheCity Purpose of that tool Live center for model work. In contrast to dead centers, live centers don’t need cutting oil and rotate with the work piece in order to machine delicate parts. The steel live center has one bearing. The center is tool steel. The live center with M14-1.0 threads fits to the UNIMAT 3 tailstock. Ideal to work on delicate parts, wood, or plastics since little friction is generated. In particular a bull nose live center is used to work on tubing or all parts that cannot be turned by a standard pin end live center. Size and details The bearings we use have an outer diameter (O.D.) of 5/8” and an inner shaft diameter of 3/8”. A tool steel bull nose shaped pin is pressed in the bearings. The front end is flat and has a diameter of 1/4" the back end diameter of the nose is 3/4", taper angle approx. 60 deg. The bearing is mounted in a steel adapter that has metric M124threads to fit an UNIMAT 3. The entire accessory has a total length of only ~1.8" and is machined from a 3/4" hex bar. The body is 1.3" long + the bull nose end. The live center was tested up to 2800 RPM on an UNIMAT mini lathe. The bearing is self-lubricated and sealed. All dimensions are approximately. Bearing R1038-2RS 3/8"x5/8"x5/32" inch Miniature Bearings, R1038-2RS Sealed Ball Bearings, the inner diameter is 3/8", outer diameter is 5/8" and the width is 5/32" inch, each bearing has 2 Rubber Sealed to protect the bearing from dust or any possible contamination, also bearings are pre-lubricated with grease. •Item: R1038-2RS Ball Bearings •Type: Deep Groove Ball Bearings •Closures: 2 Rubber Seals •Lubrication: Self Lubricated (Grease) •Dimensions: 3/8" x 5/8" x 5/32" English Size •ID (inner diameter)/Bore: 3/8" inch •OD (outer diameter): 5/8" inch •Width/Height/thickness: 5/32" inch Safety Notes: This is a miniature watch makers live center. Therefore, don’t overdo it with the loads and RPM. Load ratings of the bearings are given below. Maximum RPM is 2800. However, extensive use at the highest RPM is not recommended. It will be your responsibility to make sure that your lathe is running properly. Alignment problems can cause vibrations which can lead to unstable working conditions. First test Use a #1 center drill and center drill a work piece. Mount the small live center in tailstock and push towards the center drilled work piece. The live center will start to rotate which is best seen at low RPM. Use a marker pin and place a dot on the pin end of the live center. You will need to center drill the work piece or the live center has not enough attachment to the workpiece to turn. If you prefer not to center drill the work pieces, then use a different center such as a revolving adapter. Included: One M14-1.0 bull nose live center, this manual, and a safety booklet. Further Safety Notes, Trouble Shooting, and Disclaimer: General safety rules for machine/power tools are in place. For an extended list of safety notes, consult the literature or go to our website. You can download free of charge a safety booklet, which is also typically included (free of charge) for first-time customers. Use protective closing including, most importantly, safety glasses for metal work. Use accessory for light lathe work on miniatures. Max RPM 2800 Broken bearing may result in the front pin getting stuck in the work piece which can in turn over heat. In that case, switch off the lathe, cool down work piece, and replace cooled down bearing. Note that bearings are not designed to take large side forces. Note also that no life center will be as ridged as a dead center pin. We do not warrant that any accessories can be used for any particular application. Usage of accessories or damage caused by unprofessional use is at the risk of the customer. Neither LatheCity nor its owner shall be liable for damage arising from unprofessional use or misuse of LatheCity accessories. Any legal action brought against LatheCity/Uwe Burghaus shall be tried in the State of North Dakota in Fargo, USA. WARRANTY: we do not provide any warranty for our products. In no event shall LatheCity's liability exceed the purchase price paid for the product. We shall in no event be liable for death, injuries to persons or property or incidental, contingent, special or consequential damage arising from the use of our products. Returns in resalable condition accepted within 14 calendar days (eBay sales) or 4 weeks (factory direct) after shipment day, no questions asked. However, we do NOT reimburse shipping costs (e.g. Priority mail ~$5.20), credit card fees, broker fees, currency exchange fees, taxes, whatever fee, etc. We will charge the respective shipping costs to customers for products that were offered as free shipping when returned. We charge up to $5 for manuals and booklet that may need to be reprinted. Note that the return rate of LatheCity products is below 1% (see eBay rating). Uwe Burghaus (LatheCity) Fargo, North Dakota, USA ©, 2015, LatheCity
