Burndy Yaz8c2tc14fx Straight Tongue Compression Lug; 2 Hole, 8 Awg Copper

US $7.99

Pompano Beach, Florida, United States
Jun 9th

Open on mobile:
QR code

Hubbell Electrical / Burndy YAZ8C2TC14FX Hylug™ YAZ-FX Series Straight Tongue Compression Lug; 2 Hole, 8 AWG Flexible Copper, Red FREE SHIPPING AND NO ADDITIONAL TAXES AT CHECKOUT WE SELL THESE BY THE PIECE PRODUCT DETAILS • Size: 0.440 Inch Width x 2.330 Inch Overall Length • Zero crossing circuitry provides increased durability • 49 die index number • Tools, die set catalog number and (number of crimps) - Mechanical: MD6, OUR840, MD7-34R tool, W8CVT, W8CRT, X8CRT die (2); Hydraulic: BCT500HS, Y500CTHS tool, W8CVT, W8CRT, X8CRT die (2); Y35, Y39, Y750, PAT750 tool, U8CRT die (2); Y46 tool, U8CRT die (2) With PUADP-1 Adapter • Dieless tools (number of crimps) - Y81KFT, Y81KFTMBH, PAT81KFT-18V tool (1), Y8MRB-1, MY29-11, Y1MRTC tool (2) Hubbell Electrical / Burndy Hylug™ YAZ-FX Series 2-Hole Copper compression 3 flex terminal lug in red color is rated up to maximum of 600 Volts - 35 kilo-Volts. The 8 AWG copper tubing terminal with inspection window is made of electrolytic tin-plated seamless copper that provides good conductivity and has long barrel in chamfered skived style. The 0.08-Inch thick terminal lug features two stud holes of size 1/4 Inch that have 0.625-Inch spacing between them. Lug measures 0.440 Inch x 2.330 Inch and comes with a straight tongue angle for convenient usage. Terminal lug is UL listed and CSA certified. PRODUCT SPECIFICATIONS AttachmentURL http://ecat.burndy.com/Comergent/burndy/drawing/10072660.pdf Barrel Size 0.810 Inch Length Barrel Type Chamfered, Skived, Long Cable Size 3 AWG, 8 AWG Weld, 37/24, 10 SQ-MM For Class 2 And Class 5 Conductors Catalog Description BURNDY; Compression Terminal; HYLUG; YAZ-FX, Long Barrel; Number Of Holes: 2; Stud Size: 1/4 IN Hole; Cable Size: 3 AWG, 8 AWG Weld, 37/24, 10 SQ-MM For Class 2 And Class 5 Conductors; Voltage Rating: 600 - 35000 V; Mounting: 5/8 IN Stud Hole Spacing; Material: Copper; Wire Strip Length: 1 IN; Tongue Angle: Straight; Finish: Electro-Tin Plated; Die Index: 49; Temperature Rating: 90 DEG C; Tools, Die Set Catalog Number, And (number Of Crimps): Mechanical: MD6, OUR840, MD7-34R Tool, W8CVT, W8CRT, X8CRT Die, (2); Hydraulic: BCT500HS, Y500CTHS Tool, W8CVT, W8CRT, X8CRT Die, (2); Y35, Y39, Y750, PAT750 Tool, U8CRT Die, (2); Y46 Tool, U8CRT Die With PUADP-1 Adapter, (2); Color Code: Red; Conductor Type: Flexible; Dieless Tools (number Of Crimps): Y81KFT, Y81KFTMBH, Y8MRB-1, PAT81KFT-18V Tool, (1); Y1MRTC, MY29-11 Tool, (2) Catalog Number YAZ8C2TC14FX Color Red Conductor Size 3 AWG Flexible, 8 AWG Stranded Country of Origin US Finish Electro-Plated Tin GTIN 00781810324363 In Stock Yes Invoice Description English CULUG-8FLEX-LONG W/PORT Item Compression Lug Material Seamless Copper Mfr/Vendor Hubbell Electrical / Burndy Mounting 5/8 IN Stud Hole Spacing Number Of Holes 2 Number of Holes 2 Overall Length 2.330 Inch ShortDescriptionStripped Hubbell-Electrical-Burndy-YAZ8C2TC14FX-Hylug Special Features Features: UL Listed 90 DEG C, 600 V - 35 KV; 45 DEG And 90 DEG Angles Are Available; With Inspection Window; Finish: Electro-Tin Plated; Tongue Angle: Straight; Temperature Rating: 90 DEG C; Die Index: 49; Wire Strip Length: 1 IN; Tools, Die Set Catalog Number, And (number Of Crimps): Mechanical: MD6, OUR840, MD7-34R Tool, W8CVT, W8CRT, X8CRT Die, (2); Hydraulic: BCT500HS, Y500CTHS Tool, W8CVT, W8CRT, X8CRT Die, (2); Y35, Y39, Y750, PAT750 Tool, U8CRT Die, (2); Y46 Tool, U8CRT Die With PUADP-1 Adapter, (2); Color Code: Red; Conductor Type: Flexible; Dieless Tools (number Of Crimps): Y81KFT, Y81KFTMBH, Y8MRB-1, PAT81KFT-18V Tool, (1); Y1MRTC, MY29-11 Tool, (2) Standard UL Listed At 90 DEG C, 600 V To 35 KV, CSA Certified Standards UL Listed, CSA Certified, RoHS Compliant Strip Length 1.000 Inch Stud Hole Spacing 0.625 Inch Stud Size 1/4 Inch Sub Brand Hylug™ Temperature Rating 90 deg C Tongue Size 0.440 Inch Width x 0.080 Inch Thickness Type YAZ-FX Series, Straight Tongue UPC 781810324363 Voltage Rating 600 - 35000 Volt description BUR YAZ8C2TC14FX CULUG-#8FLEX-LONG feature#1 Size: 0.440 Inch Width x 2.330 Inch Overall Length feature#2 Zero crossing circuitry provides increased durability feature#3 49 die index number feature#4 Tools, die set catalog number and (number of crimps) - Mechanical: MD6, OUR840, MD7-34R tool, W8CVT, W8CRT, X8CRT die (2); Hydraulic: BCT500HS, Y500CTHS tool, W8CVT, W8CRT, X8CRT die (2); Y35, Y39, Y750, PAT750 tool, U8CRT die (2); Y46 tool, U8CRT die (2) With PUADP-1 Adapter feature#5 Dieless tools (number of crimps) - Y81KFT, Y81KFTMBH, PAT81KFT-18V tool (1), Y8MRB-1, MY29-11, Y1MRTC tool (2) View Product Catalog View Brochure Technical Diagram

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Burndy
Model	YAZ8C2TC14FX
MPN	YAZ8C2TC14FX
