Caddx Ge Networx Security Nx-2192e Pinpoint Interface Module For Nx8e

US $260

Hoolehua, Hawaii, United States
Nov 5th

Open on mobile:
QR code

GE Security Networx - Interlogix GE NX-2192E the Pinpoint Interface Card Attaches to the NX-8E Control Panel. Supports Up to 192 Addressable Devices On a Two-Mile Loop. Supports Two Class B Loops and One Class A Loop. GE Security is a part of UTC Fire & Security, which provides fire safety and security solutions to more than 1 million customers worldwide. GE Security has operations in more than 30 countries and is represented by some of the best-known brand names for intrusion and fire detection, access and building control, video surveillance, explosive and drug detection, Security Management, and structured wiring. The PinPoint addressable solutions bring together NetworX NX-8E functionality with the reliability of GE Security sensors. Supporting up to 192 devices on a single 2-wire loop up to two miles, the PinPoint point ID solution can be installed fast in new construction or retrofit applications. The system is scalable to adjust to changing requirements. PinPoint identifies the exact location of an alarm or trouble event, which saves time for emergency personnel or service technicians. Standard Features Single two-wire loop up to two miles means fast and easy installation for new construction or retrofit applications Addressable sensors indicates exact location of alarm or trouble event Supports up to 192 devices Advanced digital communication from the sensors to the panel 1. GENERAL DESCRIPTION The NX-2192E is a microprocessor-controlled point ID bus interface module for the NX-8E control panel. The PinPoint System provides two-wire bidirectional communications with up to 255 individually addressed devices. The total number of devices in a system is limited by the I/O capability of the panel. The NX-8E can support a maximum of 192 zones mapped to 192 input device addresses and an additional 48 addresses for output devices. Warranty information is provided in the Interlogix product catalog. 2. INSTALLATION The NX-2192E is installed in the NX-8E control panel enclosure. Three loop outputs are provided for interface with the point ID devices. A single loop output can support the full 255 point ID devices as long as the wire run limits are not exceeded. The total number of devices can be distributed across the three loop outputs to meet wire run limit requirements. · 3. DEVICE ADDRESS CONFIGURATION · Each device on the PinPoint System must be configured for a unique address with the range of 0 through 254. Address 255 is reserved. · Setting the address switches at the time that each device is installed will determine the address selection. Please refer to the worksheet in Appendix1 on page 40. · For UL certified installations, the NX-2192E must be powered by the NX-8E control panel. The NX-2192E is listed for the following UL standards: · UL365 Police Station Connected Burglar Alarm Units and · Systems · UL609 Local Grade A Mercantile, Police Station Connect · with Basic Line Security · (* requires #NX-003-C enclosure) · UL864 Control Units for Fire-Protective Signaling Systems · UL985 Household Fire Warning Systems & Units · UL1023 Household Burglary Alarm Systems & Units · UL1610 Grade B & C Central Station Burglar Alarm Unit · UL1635 Digital Alarm Communicator System Units · UL1637 Home Health Care Signaling Equipment · PRODUCTS WHICH HAVE THE CE MARK ATTACHED SPECIFICATIONS · Dimensions: ..................... 2” Wide / 9” High / 1.25” Deep · Current Draw: ..................... 170 mA Standby Max. · Operating Temperature: ..................... 32 to 122 degrees F · Shipping Weight: ..................... 0.5 pounds · AUX+ using 12V transformer ..................... 600 mA each · AUX + using 12V Aux from panel ..................... 0 mA · AUX + using 24V supply ..................... 0 mA · NX2192EIC04 REV C AUG 2004
