Calibration Fixture--constant Amplitude Signal Generator-- Tektronix 65-500 Mhz

US $220

Lewisville, Texas, United States
Jul 16th

Open on mobile:
QR code

"The Tektronix 067-0532-00 Constant Amplitude Signal Generator produces sinewaves whose amplidude remains constant as the frequency is varied. Output frequency is continuously variable from 65 to 500 Mhz. The amplitude of the above mentioned sinewaves is referenced to the amplitude of 3 MHz sinewave also available at the ouput connector. Output amplitude is continuously variable from 0.5 volt to 2.5 volts peak to peak into 50 ohms. The output amplitude is in 0.5 volt steps from 0.5 to 5.0 volts into 50 ohms. It is also contnuously variable from 0.5 volt to 5.5 volts. The output remains constant amplitude from 0.5 volt to 5.5 volts from 65 MHz to 300 MHz, and constant amplitude from 0.5 volt to 2.5 volts from 300 MHz to 500 MHz. Cable loss and standing wave errors are essentially eliminated. The amplitude is regulated at the generator end of a 50 ohm resistor physically adjacent to the output connector. The output connector, 50 ohm resistor, and amplitude detector are at the end of an attached 42 inch cable." Manual is included The pots are scratchy and the frequency calibration is off so unit will need some repair and calibrating. The electrolytic capacitors have been replaced. Unit is sold AS-IS ------------------------------------------------------------------------------------------------------------------ Payment Policy: We accept PayPal (via Ebay) Shipping: USA: We use UPS or FedEx Ground as standard shipping method for all 48 States. Ebay GSP is used for limited international shipping. See below. International Shipping: LIMITED INTERNATIONAL SHIPPING INCLUDES: Canada, United Kingdom, Denmark, Finland, Greece, Japan, Sweden, Belgium, France, Ireland, Netherlands, Spain, Italy, Germany, Austria, Israel, Mexico, Switzerland, Norway, Bermuda, South Korea, Taiwan Returns Policy: Our goal is to ensure you are completely satisfied with your purchase. Please Read carefully the description of the item listed for full details before bidding. No returns or exchanges are accepted. -------------------------------------------------------------------------------------------------------------------

“Seems to work. Check photos. - - Manual is included if repairs are needed.”

Country/Region of Manufacture

United States

Product Type

067-0532-00

Brand

Tektronix
