Cannon Mil-c-5015 Connector With Gold Plated Contacts P/n Ms3456w28-2pw

US $140

Naperville, Illinois, United States
Jan 29th

Open on mobile:
QR code

Cannon MIL-C-5015 Connector With Gold Plated Contacts P/N MS3456W28-2PW New in original packaging, old stock. Used in many Boeing aircrafts Specs: Technical Characteristics ( ILs ) 5935-01-261-8800 MRC Requirement Reply FEAT SPECIAL FEATURES IN ORDER TO COMPLETE THE CONNECTOR ASSEMBLY,THE USER MUST OBTAIN/PROVIDE THE BACKSHELL; STANDARD VERSIONS MAY BE ORDERED AS NSN 5935-01-189-3225,P/N M85049/52-1-28W FOR THE STRAIGHT STYLE,OR NSN 5935-01-174-3672,P/N M85049/51-1-28W FOR THE RIGHT ANGLE TEST TEST DATA DOCUMENT 81349-MIL-C-5015 SPECIFICATION (INCLUDES ENGINEERING TYPE BULLETINS, BROCHURES,ETC., THAT REFLECT SPECIFICATION TYPE DATA IN SPECIFICATION FORMAT; EXCLUDES COMMERCIAL CATALOGS, INDUSTRY DIRECTORIES, AND SIMILAR TRADE PUBLICATIONS, REFLECTING GENERAL TYPE FEAT ~1 STYLE TEST ~1 DATA ON CERTAIN ENVIRONMENTAL AND PERFORMANCE REQUIREMENTS AND TEST CONDITIONS THAT ARE SHOWN AS "TYPICAL", "AVERAGE", "NOMINAL", ETC.). AFQX CONTACT POSITION ARRANGEMENT STYLE 28-2 SINGLE MATING END AFRC CONTACT MAXIMUM CURRENT RATING IN AMPS 41.0 SINGLE MATING END 1ST CONTACT GROUPING AAQL BODY STYLE STRAIGHT SHAPE, INTERNAL COUPLING CXCL INCLUDED CONTACT TYPE ROUND PIN SINGLE MATING END ALL CONTACT GROUPINGS AFRP INSERT POSITION IN DEG 35.0 CQTZ CONTACT MATERIAL COPPER ALLOY SINGLE MATING END ALL CONTACT GROUPINGS CQYH CONTACT SURFACE TREATMENT GOLD SINGLE MATING END ALL CONTACT GROUPINGS PMWT PRECIOUS MATERIAL AND WEIGHT 0.022 GOLD GRAINS, TROY CTBC SHELL SURFACE TREATMENT DOCUMENT AND CLASSIFICATION QQ-P-416,TY 2,CL 3 FED SPEC ALL TREATMENT RESPONSES AAJF THREAD DIRECTION RIGHT-HAND AND RIGHT-HAND ADZC ENVIRONMENTAL PROTECTION MOISTURE PROOF AND SALT WATER RESISTANT AND VIBRATION PROOF ADAV OVERALL DIAMETER 1.969 INCHES MAXIMUM ABHP OVERALL LENGTH 2.125 INCHES MAXIMUM AFQR THREADED DEVICE TYPE BACK SHELL AND COUPLING FACILITY ZZZK SPECIFICATION/STANDARD DATA 96906-MS3456 GOVERNMENT STANDARD CXCG INCLUDED CONTACT QUANTITY 2 SINGLE MATING END 1ST CONTACT GROUPING AFQW MATING END QUANTITY 1 AFRE CONTACT MAXIMUM DC VOLTAGE RATING IN VOLTS 1250.0 SINGLE MATING END ALL CONTACT GROUPINGS AAJD THREAD CLASS 2A AND 2B CSWM SHELL SURFACE TREATMENT CADMIUM AND CHROMATE CXCG INCLUDED CONTACT QUANTITY 12 SINGLE MATING END 2ND CONTACT GROUPING CQTM TERMINAL LOCATION BACK SINGLE MATING END ALL CONTACT GROUPINGS CQZG INSERT MATERIAL RUBBER SILICONE CLASS Q SINGLE MATING END AFRN POLARIZATION METHOD KEYWAY OR MULTIPLE KEYWAY AKMG NOMINAL THREAD LENGTH 0.467 INCHES AND 0.664 INCHES AFRD CONTACT MAXIMUM AC VOLTAGE RATING IN VOLTS 900.0 SINGLE MATING END ALL CONTACT GROUPINGS AFQZ CONTACT REMOVABILITY REMOVABLE SINGLE MATING END ALL CONTACT GROUPINGS CQJX NOMINAL THREAD SIZE 1.750 INCHES AND 1.750 INCHES CSPT SHELL MATERIAL ALUMINUM ALLOY CSCF TERMINAL TYPE CRIMP SINGLE MATING END ALL CONTACT GROUPINGS THSD THREAD SERIES DESIGNATOR UNS AND UNS AFRT SHELL TYPE SOLID CMLP THREAD QUANTITY PER INCH 18 AND 18 PMLC PRECIOUS MATERIAL AND LOCATION CONTACT SURFACES GOLD AFRV CONNECTOR LOCKING METHOD INTERNALLY THREADED COUPLING RING PRMT PRECIOUS MATERIAL GOLD AFRC CONTACT MAXIMUM CURRENT RATING IN AMPS 22.0 SINGLE MATING END 2ND CONTACT GROUPING CRBJ CONTACT SURFACE TREATMENT DOCUMENT AND CLASSIFICATION MIL-G-45204 MIL SPEC SINGLE TREATMENT RESPONSE SINGLE MATING END ALL CONTACT GROUPINGS For more info please look at this catalog: http://www.aero-electric.com/PDF/Aero-Electric_Connector.pdf QUALITY GUARANTEE: We inspect and test all items that come into our shop. However, we deal with a large variety of items and our knowledge of some items is quite limited. Because of this we offer a 48 hour inspection period on all items that we sell. If you happen to find a problem with your item that we missed, please let us know within 48 hours of delivery. We will repair the item or refund your money if there is a problem that we cannot fix. Good customer service is our only goal. Please let us know immediately if there is a problem with your item. International Buyers – Please Note: Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer’s responsibility. Please check with your country’s customs office to determine what these additional costs will be prior to bidding/buying. Froo www.froo.com | Froo Cross Sell, Free Cross Sell, Cross promote, eBay Marketing, eBay listing Apps, eBay Apps, eBay Application On Feb-02-13 at 06:35:22 PST, seller added the following information: Every buyer gets a MyStoreRewards invitation for cash back On Feb-02-13 at 18:23:16 PST, seller added the following information: FREE! Sellers: Add a FREE map to your listings. FREE!

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Cannon
MPN	MS3456W28-2PW
