Capacitor/capacitance Esr In-circuit Inductance Resistance Meter Lc Meter

US $570

Shen Zhen, China
Jan 29th

Open on mobile:
QR code

Capacitor/Capacitance ESR IN-Circuit Inductance Resistance Meter LC Meter Capacitor ESR IN-Circuit Inductance Resistor Meter LC meter Specification: Measurment Range: Resistor: 0.01?-18? Error:0.9% Capacitor: 0.15uf-1000uF Working power: DC-9V Standby current: 0.02uA Operating current: 25mA How to use: The first row shows the ESR screen, the display character "R". The second line screen display auxiliary parameter of the measured element, the display character has 6 kinds, respectively is C, D, X, Y, Z, Vc, J0. Use the K key to switch the menu, in the "ESR", "Vc" J0 calibration calibration "," the three menu to switch between. Boot into the "ESR" menu, use the K key to switch auxiliary parameters, can be switched in C, D, X, Y, Z among the 5 parameters. The C parameter is the capacity of the capacitors, a total of two, first is 72kHz square wave measured, second is 3kHz square wave measured The D parameter is zero DC, with two parameters, first are zero zero time values, second is the zero drift zero moment to moment.Debugging ESR table. The X parameter is 72kHz under X axis measuring value, there are two parameters, first are zero time values, second is the measurement of relative value (i.e. deducted zero value and DC drift).Debugging ESR table. The Y parameter is 72kHz under y axis measuring value, there are two parameters, first are zero time values, second is the measurement of relative value (i.e. deducted zero value and DC drift).Debugging ESR table. The Z parameter is 3kHz under y axis measuring value, there are two parameters, first are zero time values, second is the measurement of relative value (i.e. deducted zero value and DC drift).Debugging ESR table. Measurements should be carried out before the short circuit reset.3 cm long thick copper wire short circuit, and then press the C key.Reset the data will be stored to the MCU internal EEPROM.There may be zero drift, use short time review recommendations, if not zero should be clear treatment Calibration Set two parameters, Vc and J0.The Vc parameter should be about 525, J0 is about 13.Before calibration, if J0 is more than 40 of the values or -30 values below, please J0 set to 0, then the following calibration. 1, use 3cm thick copper wire for short circuit to clear, this is the first step, is the premise. 2, amplitude calibration: access to a 15 to 20 ohm resistor color ring.Press the Menu button, switch to the Vc calibration menu, use "C" and "K" or Vc value, the R value displayed as close as possible and the resistance being measured. 3, phase calibration: 0.47uF/630V CBB capacitor to known ESR (ESR is in commonly 20 to 30 MOhm).Press the M button, switch to the J0 calibration menu, use "C" and "K" or J0 value, the R value displayed as close as possible to the ESR and capacitor. 4, hold down the M key for 3 seconds, then release, will automatically save parameters, prompt on the screen. 5, and then press the M key, return to the ESR state measurement Package : 1 Meter(without the battery and clip) Our Working Time is as below (GMT+8): 9:30AM -- 6:00PM (Monday to Friday) Please allow us at least 24 hours to reply you when in the office, thanks! Shipping If you intend to bid for more than 1 item, then we can ship them together. The total shipping fee will be the sum of individual shipping fees. There is no further discount. We only ship to ebay registered address. So please be assure your address in ebay is Correct and Valid. Item will be shipped within 24 hours on payment received from Hong Kong using Airmail. Delivery time depends on destination and other factors, it may takes up to 30 business days. Optionally, Express Shipments with tracking service via EMS/DHL/UPS with a quoted delivery time of 5 to 7 business days is also available Here is the estimated time for your reference only: The delivery time may vary due to public holidays, countries, and customs etc. Thanks for your understanding! We ship item promptly and please rate us 5 star on shipping time according to ebay rules. http://pages.ebay.com/help/feedback/detailed-seller-ratings.html Feedback The delivery time may vary due to public holidays, countries, and customs etc. Thanks for your understanding! If you are considering giving a neutral or negative or a low DSR(4 star or below), do write to us and give us an opportunity to address your concerns first. We are always stand-by to help for any questions or concerns. Positive feedback is automatically left for you after you left to us positive feedback. Return Returns: We stand behind every product we sell. If you're not pleased with your purchase, please kindly contact our customer service representatives via email or ebay "Contact seller" for an authorized RMA number. Your returned product(s) will not be processed without a RMA. Buyer is responsible for return costs. Payment PayPal payment only. Any VAT or TAX are not counted. If buyer required to cancel bid for their mistake or any other personal reasons, 5% of the total price is charged for relisting and restocking fee. We didn't ship to Africa, Italy, China,HongKong, Macau,Taiwan due to cross-border express delivery and customs issue ,pls understand and pay your attention to it before bidding or buying. On Sep-21-14 at 18:18:47 PDT, seller added the following information:
