Carl Zeiss Ff450 Plus With Leica 8 Camera

US $11,999.00

Ortonville, Michigan, United States
Jan 30th

Open on mobile:
QR code

Carl Zeiss FF450 Plus with Leica 8 Camera Excellent used condition- just removed from active service inventory. FF 450plus Fundus Camera Field angle 50° 30° 20° Observation magnification 11x 19x 29x Image scale-on 35-mm film 1.9 2.9 4.3 Frame format on 35-mm film 26 mm diameter, height limited to 24 mm Visual observation special 10x eyepiece with reticle, monocular Working distance front lens to patient's eye 42 mm Working distance observer's eye to patient's eye 470 mm Compensation for ametropia +/- 30 D, continuous Flash rate 1x per second (irrespective of flash level) Flash levels 25 Flash energy 360 Ws Filters (motorized control) green (RF), blue, red filters, FLUO filter, ICG filter (only usable in the IR version), Special features telecentric optics, electronic interface for VISUPAC digital image archiving systems, transmission of field angle, OD/OS, flash levels Panning and tilting ranges +/-45° horizontally,+15°/-10° vertically using a hand wheel Instrument table asymmetric, motorized, suitable for patients in wheelchairs, separate cable routing available for electronic sensors Dimensions/weights L x W x H in mm L x W x H in inch FF 450plus basic system 430 x 310 x 800; 21,5 kg 16.9 x 12.2 x 31.5; 47.4 lb NAG 450plus power supply unit 440 x 360 x 132; 11 kg 17.3 x 14.2 x 5.2; 24.3 lb Accessories fundus autofluorescence filter set, internal fixation, astigmatism compensator, isolation transformer with UPS backup keyboard shelf for instrument table, NAS drive, stereo viewer Capture modes color, red-free, red and blue, fundus autofluorescence pictures (with optional filter set only), fluorescein angiography, ICG angiography, pictures of the anterior segment Further information video attachment featuring 3 opto-mechanical output ports and swing-in filter; use of different camera sensors; eyepiece usable at all times; BOOST mode at 50° for FA, ICGA and fundus autofluorescence; improved light yield reduces light exposure of the patient; pre-selectable capture settings for each capture mode and sensor; all settings effective at the press of a button Sensors ZK-5 Pike 145b Pike 421b Sensor Chip Sony ICX-282AQ Sony IT CCD Kodak CCD Chip size 2/3”; 11 mm 2/3”, diag. 11.2 mm 1.2“, diag. 21.4 mm Pixel number 5.06 megapixel (2588 x 1956) 1.4 megapixel (1388 x 1038) 4.1 megapixel (2048 x 2048) Pixel size 3.4 x 3.4 µm 6.45 x 6.45 µm 7.4 x 7.4 µm File size of exported high quality jpg file ca. 1,9 MB ca. 0,8 MB ca. 2,1 MB Connection Firewire (IEEE 1394a) Firewire (IEEE 1394b) Firewire (IEEE 1394b) Terms & Conditions By completing this auction, you acknowledge and agree to the Terms & Conditions set herein. DISCLAIMERS, WAIVERS AND INDEMNITY: There are inherent risks involved in using any product, including but not limited to serious physical injury, and possibly death. Purchaser acknowledges that Seller is neither the manufacturer of this Item nor an agent of the manufacturer. Purchaser waives all liability of Seller and claims against Seller for damages, losses, costs, injuries, penalties, expenses, attorneyaЂ™s fees and all liabilities. Under no circumstances is Seller responsible for special, indirect, incidental or consequential damages. Purchaser agrees to indemnify, defend and hold Seller harmless from and against any and all specified claims. Purchaser knowingly and freely assumes all risks of ownership and use, known and unknown.If Purchaser loans, re-sells, gifts, or transfers the Item, Purchaser will obtain transfereeaЂ™s agreement of all the terms contained herein. Should any legal cause of action arise, the Purchaser agrees to defend Seller, and hold harmless, and forever release the seller, from any and all legal liability. We ship internationally; the sale of this item may be subject to the regulations by your countryaЂ™s Administration, state and local regulatory agencies. It is PurchaseraЂ™s responsibility to verify your status as an authorized purchaser of this item. Do not bid on this item unless you are an authorized purchaser. PURCHASER WARRANTS THAT THEY HAVE READ, UNDERSTOOD, AND ACKNOWLEDGE THAT THEY HAVE GIVEN UP SUBSTANTIAL RIGHTS BY THIS AGREEMENT, AND AGREE TO THESE TERMS FREELY AND VOLUNTARILY WITHOUT ANY INDUCEMENT The sale of this item may be subject to regulation by the U.S. Food and Drug Administration and state and local regulatory agencies. If so, do not bid on this item unless you are an authorized purchaser. If the item is subject to FDA regulation, we will verify your status as an authorized purchaser of this item before shipping of the item. By bidding on this item, the buyer acknowledges that there may be an inherent danger in its use, either physical or environmental, and that it is the purchaser's sole responsibility for the handling, use, disposal and appropriateness of use of a particular item, and will hold the seller harmless from any and all liability. These parts are not meant to replace your doctor's diagnostic care and treatment or for assessing medical emergencies. While these are clean, we cannot guarantee sterilization and we highly recommend cleaning before use. Email us before bidding if you have any questions. We will try to answer all your questions in 24 hours The following FDA Disclaimer is required for all eBay listing in Healthcare category and is included for REFERENCE: The sale of this item may be subject to regulation by the U.S. Food and Drug Administration and state and local regulatory agencies. Do not bid on this item unless you are an authorized purchaser. If the item is subject to FDA regulation, by bidding, you verify your status as an authorized purchaser of this item. AS ALWAYS IF YOU HAVE ANY QUESTIONS PLEASE FEEL FREE TO ASK AND I WILL DO MY BEST TO ANSWER. HAVE FUN BIDDING AND ENJOY THE AUCTION!!!!

Condition	Used : An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections.
Seller Notes	“Excellent Condition!”
