Carr Lane Roemheld Clr-1914-720 Swiftsure Workhold Clr-420-ws

US $122

  • Lake Geneva, Wisconsin, United States
  • Jun 24th
Carr Lane Roemheld CLR-1914-720 / CLR-720-WS Work Support 7500 psi max Single Acting FEATURES: Work Supports automatically adjust to the proper height for supporting a workpiece, then lock securely to become fixed rests. Support plunger is held by a precision sliding-fit pressure sleeve that provides incredible accuracy and repeatability. Fluid-advanced Work Supports provide extra loading clearance and are ideal for workpieces that are too light to depress a spring-loaded plunger. The low-profile version shown here has a very low height, and provides many plumbing options, including manifold mounting. SUPPORT ACTION (FLUID ADVANCED): Plunger is normally retracted for clear workpiece loading and unloading. Applying fluid pressure gently advances the plunger to the workpiece, where it contacts with light spring force. As fluid pressure increases, the precision sleeve grips the plunger, locking it securely. The plunger retracts again when pressure is released. ACCURACY: Height repeatability within +/-.0002". Such excellent repeatability is possible because of two design features: 1) the sliding-fit pressure sleeve holds the plunger absolutely vertical even while unlocked, avoiding any inaccuracy due to locking a tilted plunger, and 2) locking force is entirely radial, so the plunger remains absolutely stationary during the locking process. Elastic deflection of the plunger is only .00007" per 100 lbs machining load. DESIGN CONSIDERATIONS: If the workpiece is light enough that plunger contact could lift it, use a Sequence Valve to delay advancing the work support until after the workpiece is clamped. Do not exceed maximum fluid flow rate in table; otherwise the support could lock prematurely before the plunger is fully extended. Do not use the plunger to lift loads. The support plunger must always be protected against penetration of contaminants by the plastic plug furnished, or a contact bolt (order separately) When supporting underneath a clamp, use a Sequence Valve to delay clamping until the Work Support has reached sufficient load capacity to resist the clamping force. Support load capacity should be at least 2 times clamping force at all times, to resist not only static clamping force, but also dynamic forces due to clamping-arm momentum and machining forces. MOUNTING: Several possible mounting methods: 1) fasten to fixture with two socket-head cap screws; 2) mount through a tapped hole in the fixture plate, securing with a lock ring; 3) mount through a bored hole in the fixture plate, securing with two lock rings. The manifold-mounted version can also be embedded in a bored hole and fastened with two socket-head cap screws, with fluid supplied through a drilled passage underneath (provide sufficient clearance for the Port Plug). FLUID CONNECTION: Choice of two Work Support types: 1) side 1/4" BSPP port and bottom O-ring port; 2) bottom 1/4" BSPP port only. For optional manifold mounting, order type 1 and use the O-ring port underneath instead of the standard port. Unscrew the sealing plug in the O-ring port and install a CLR-3000-347 O-ring (also install a CLR-810-F Port Plug in the 1/4" BSPP port). Do not use NPT fittings. CONSTRUCTION: Plunger > Steel, case hardened. Body > Steel, black oxide finish. See the Product Sheet at > Carr Lane Catalog New. Terms and Conditions of Sale Payment Payment shall be made within three days of the close of the auction. We accept all major credit cards through PayPal. If you can not complete the payment within three days, please send an email detailing your expected payment date. Shipping The buyer is responsible for the shipping and handling costs of all purchases. Local pick-up always welcome. Local pick-up requires the addition of 5.5% Wisconsin Sales Tax.  International buyers, please include a telephone number for shipping contact. Return Policy We strive to describe the condition of all items in our listings. If an error has been made, an email must be sent within fourteen days of receipt of the item describing the error. No item may be returned without prior written authorization. Return shipping charges are the responsibility of the party returning the item. Warranty  Except as expressly set forth in the item description, Seller makes NO EXPRESS OR IMPLIED warranties of any kind whatsoever about this merchandise. Seller is not responsible for consequential, incidental or punitive damages of any kind whatsoever. Seller's liability is limited to the amount paid by the Buyer including shipping/handling charges.
