CARROLL DIVIDING HEAD 7 DISC SET. See details below., US $164.99 – Picture 0
CARROLL DIVIDING HEAD 7 DISC SET. See details below., US $164.99 – Picture 0

Carroll Dividing Head 7 Disc Set. See Details Below.

US $164.99

  • Lake Zurich, Illinois, United States
  • Jul 6th
Open on mobile:
QR code
This is a complete standard set of dividing head discs for a Carroll head WITH 40 TO 1 GEAR RATIO. The 3 screw holes are on a 1-5/8" screw circle.  Note:  If your head uses a 1-3/4" screw circle see my other discs that fit Ellis & other dividing heads (1-3/4" screw circle) in my other items for sale. Contains the following:Disc #1; 15, 16, 17, 18, 19, & 20 holes Disc #2; 21, 23, 27, 29, 31, & 33 holes Disc #3; 37, 39, 41, 43, 47, & 49 holes high indexing discs Disc #4; 25, 61, 71, 83, 91, & 93 holes Disc #5; 51, 53, 63, 73, 81, & 96 holes Disc #6; 22, 57, 67, 77, 87, & 97 holes Disc #7; 28, 59, 69, 79, 89, & 99 holes Discs are 5 inches in diameter +/- .010,  1/4"+/-004 thick, made of A36 steel hot plate. Has 1-1/8" diameter center hole.   All pin holes are 1/8 inch in diameter & do not go all the way through the discs. Note:  This disc may fit other dividing head manufacturers, contact me if you need more information. Need only some of these discs, contact me. Need a special disc, contact me for with your needs. Ships only to USA Sold as is. No returns accepted
Condition:
New – Open box: An item in excellent, new condition with no functional defects. The item may be missing original packaging and may have been used for testing or demo purposes. The item includes accessories found with the original product and may include a warranty. See the seller's listing for full details and description. ...
Modified Item No
MPN Does Not Apply
Custom Bundle No
Brand Unbranded
Non-Domestic Product No
