Factory direct sale! We are CONTEC medical systems! CE 24 channel(19EEG 5multi) EEG machine Digital Brain Mapping systems+tripods+CD Introduction KT88-2400 Digital Brain Electric Activity Mapping is an equipment for checking 19 channels of EEG and optional 5 channels of multi-parameter(one channel of ECG, one channel of EMG, one channel of respiration and two channels of EOG), it collects EEG signal with electrodes, via integrated amplification, A/D transformation, PC auto-analysis, FFT, to form electroencephalogram which displays with color depth. The product is applicable for checking such diseases as epilepsy, intracranial inflammation, cerebrovascular diseases and brain tumors. Performance Parameter Channel: 19 channels of EEG+5 channels of multi-parameter (1channel of ECG+ 1channel of EMG+ 2 channels of EOG +1channel of Breath)(multi-parameter are optional) Sampling rate: 200 Hz A/D transformation: 12 bits Input impedance: >=10M? Patient leak current: < 10µA Noise level: =90dB Magnification multiple: 10000 Filter constant: all digital and free enactment Display speed(paper speed): 5, 10, 15, 30, 60, 120 mm/s Amplitude: 1, 1.5, 2, 3, 5, 7.5, 10, 12, 15, 20, 30, 50 mm/50µV Playback speed:1 time, 2 times, 3 times, 10 times, 20 times, 40 times, 60 times 50Hz interference suppression: >=30dB Safety type:Class II, type BF applied part Function Features Standard 24 channels(19 channels of EEG + 5 channels of multi-parameter). Method of 10/20 electrodes placement under international standard system, montages can be changed during collecting or replaying(such as monopolar, bipolar or user-defined montages). Support different inactive electrode during collecting(such as A1,A2,AA,AV,Bn,Cz). Adopt bioelectricity amplifier for distilling brainwave, continuous record time can be up to 24 hours, integrated full-automatic calibration system. Powerful playback function: two playback modes(continuous and rolling) are optional, amplitude and display speed are adjustable. The special subdividing time line divides the waveform in one second into 5 parts, which is easy for doctors to look over the waveform. Multifunctional digital filter system provide different filter methods and window types, and user can freely set low-pass, high-pass, band pass and band stop filter. EEG signal clipping function, analyze and store any section of EEG wave, and select several segments waveforms for automatically analyzing and distilling to different parameters. Electronic frequency ruler, convenient to measure the basic information of any appointed EEG waveforms. With partial enlarging window, to accurately measure EEG period, amplitude and frequency, and which can be adjusted according to personnel judgment. Mark EEG wave under the events of opening eyes, closing eyes and flashing with different colors, and user-defined events can be added, waveform color for evoked event can also be set freely, ensures that the waveform in corresponding time can be rapidly found by event name during case playback. Powerful automatic analysis function, can carry through the power spectrum analysis and pathologic wave detection for appointed waveform. Many graphs can be displayed in the same screen, including kinds of BEAM, numerical BEAM, compressed spectrum graph, trend graph, and so on. Professional isolation transformer, dual power supply isolation system and optoelectronic data transmission to ensure security. Use USB interface to transmit data which just need to be inserted. Multifunctional flash stimulator of USB interface, and frequency can be controlled manually or automatically. A flash stimulation scheme can be set and performed in the process of collection. Perfect case management function, provides many means for research and quick statistic information; convenient case export and import function, and stores with CD-RW disk, which is easy for data research. Integrative image and character report, report can be edited in mode and switched to Word document. Case files can be transformed into EDF and BDF data format, convenient for data exchange, academic exchange and further analysis. System parameters and display modes can be set as required, which meets different user’s requirements. Add marks and annotations to the waveform designated, which can rapidly find the waveform in that time by marks. Optional video function: USB camera is easy to install, convenient to use and exact to record. With flexible playback function, which can browse the waveform of any time along with the corresponding isochronous collected image. SpO2 function which can view SpO2 value, pulse rate and SpO2 trend graph is optional. Accessories Standard accessories: Thirty EEG leads Two EEG leads(ear electrode) Two data lines Twenty-five EEG electrodes Two headgears One flashlight One flashlight power supply One disk One User Manual One earth wire Two aluminum blocks Optional accessories: ECG lead, ECG electrode(for optional ECG, EOG, EMG function) Disposable respiration probe(for optional respiration function) SpO2 module (one CMS-P SpO2 probe, one disk with software) Video module(one softdog, one camera, one video software disk) EEG bracket(tripod) * We accept payment from PAYPAL contec001@gmail.com, Bank transfer and West Union. * All payments are expected within 7 days after the last winning auction is closed. After purchasing multiple items from me, you could send one payment together for all the items instead of paying for each of them individually. When you click the Pay Now button, eBay will automatically determine if there are other items you have won or purchased from this store and will combine them for your review. * Clearance: we will ship your item(s) to your PayPal confirmed address. Please leave me your clear address, telephone, postal code / house number etc . * It is the buyers' responsibility to consider duties, taxes and other extra charges by the government in your respective country. * All items will be dispatched within 2 bussiness day from China warehouse by EUB(US), Airmail ( to other country). It take 20-30 bussiness days to arrive you. EMS, UPS, TNT and DHL could be used for specail requirment if you agree to pay more. * The item will be declared as lower value for shipping only.We'd like to cooperate with you and declare the value of it as you want us to, so that it is more easier for you to clear the custom. WaWarranty: 24 Months, you could trust in us. * If merchandise is found defective, please contact us in two days after you received it. The Fingertip Pulse Oximeter is registered on the Australian Register of Therapeutic Goods (ARTG) with the code 197923, and certified by FDA of United States and CE,TUV of Europe. The Fingertip Pulse Oximeter that is FDA 510K Approved Welcome to be our distributer! We, CONTEC Medical Systems is an original equipment manufacturer ( OEM ) in China. Focusing on research, manufacture and distribution of medical equipments since 1992, Contec Medical Systems is capable of producing large quantity medical equipment in its newly built 32,000 M2 factory. The product of Contec have been distributed all over the world. Our main products: ECG / ECG holter, EEG / EEG Holter, B-ultrosound, Patient Monitor, Fetal doppler, Fetal Monitor, Spo2 Monitor, Stethoscope, Medical Image... MSN&EMAIL: contecmxf@gmail.com Tel: 86-335-8015594(CN) Address: No.24 Huanghe West Road,Economic&Technical Development Zone,Qinhuangdao,Hebei Province,066004,P.R.China The difference of Working Time between ours and the Pacific time Beijing time ( Chinese time ) pacific time ( USA ) Start End Start End Monday AM 9:00 PM 18:00 Sunday PM 17:00 Monday AM 2:OO Tuesday AM 9:00 PM 18:00 Monday PM17:00 Tuesday AM2:OO Wednesday AM 9:00 PM 18:00 Tuesday PM17:00 Wednesday AM2:OO Thursday AM 9:00 PM 18:00 Wednesday PM17:00 Thursday AM2:OO Friday AM 9:00 PM 18:00 Thursday PM17:00 Friday AM2:OO Saturday Out of Duty Friday Saturday Sunday Out of Duty On Jul-01-14 at 00:42:23 PDT, seller added the following information:
