KT88-2400 Digital Brain Electric Activity Mapping This product is registeared on the Australian Register of Therapeutic Goods (ARTG) with the code 136606, and certified by FDA of United States and CE &TUV of Europe Introduction KT88-2400 Digital Brain Electric Activity Mapping is an equipment for checking 19 channels of EEG and optional 5 channels of multi-parameter(one channel of ECG, one channel of EMG, one channel of respiration and two channels of EOG), it collects EEG signal with electrodes, via integrated amplification, A/D transformation, PC auto-analysis, FFT, to form electroencephalogram which displays with color depth. The product is applicable for checking such diseases as epilepsy, intracranial inflammation, cerebrovascular diseases and brain tumors. Performance Parameter Channel: 19 channels of EEG+5 channels of multi-parameter (1channel of ECG+ 1channel of EMG+ 2 channels of EOG +1channel of Breath)(multi-parameter are optional) Sampling rate: 200 Hz A/D transformation: 12 bits Input impedance: >=10M? Patient leak current: < 10µA Noise level: =90dB Magnification multiple: 10000 Filter constant: all digital and free enactment Display speed(paper speed): 5, 10, 15, 30, 60, 120 mm/s Amplitude: 1, 1.5, 2, 3, 5, 7.5, 10, 12, 15, 20, 30, 50 mm/50µV Playback speed:1 time, 2 times, 3 times, 10 times, 20 times, 40 times, 60 times 50Hz interference suppression: >=30dB Safety type:Class II, type BF applied part Function Features Standard 24 channels(19 channels of EEG + 5 channels of multi-parameter). Method of 10/20 electrodes placement under international standard system, montages can be changed during collecting or replaying(such as monopolar, bipolar or user-defined montages). Support different inactive electrode during collecting(such as A1,A2,AA,AV,Bn,Cz). Adopt bioelectricity amplifier for distilling brainwave, continuous record time can be up to 24 hours, integrated full-automatic calibration system. Powerful playback function: two playback modes(continuous and rolling) are optional, amplitude and display speed are adjustable. The special subdividing time line divides the waveform in one second into 5 parts, which is easy for doctors to look over the waveform. Multifunctional digital filter system provide different filter methods and window types, and user can freely set low-pass, high-pass, band pass and band stop filter. EEG signal clipping function, analyze and store any section of EEG wave, and select several segments waveforms for automatically analyzing and distilling to different parameters. Electronic frequency ruler, convenient to measure the basic information of any appointed EEG waveforms. With partial enlarging window, to accurately measure EEG period, amplitude and frequency, and which can be adjusted according to personnel judgment. Mark EEG wave under the events of opening eyes, closing eyes and flashing with different colors, and user-defined events can be added, waveform color for evoked event can also be set freely, ensures that the waveform in corresponding time can be rapidly found by event name during case playback. Powerful automatic analysis function, can carry through the power spectrum analysis and pathologic wave detection for appointed waveform. Many graphs can be displayed in the same screen, including kinds of BEAM, numerical BEAM, compressed spectrum graph, trend graph, and so on. Professional isolation transformer, dual power supply isolation system and optoelectronic data transmission to ensure security. Use USB interface to transmit data which just need to be inserted. Multifunctional flash stimulator of USB interface, and frequency can be controlled manually or automatically. A flash stimulation scheme can be set and performed in the process of collection. Perfect case management function, provides many means for research and quick statistic information; convenient case export and import function, and stores with CD-RW disk, which is easy for data research. Integrative image and character report, report can be edited in mode and switched to Word document. Case files can be transformed into EDF and BDF data format, convenient for data exchange, academic exchange and further analysis. System parameters and display modes can be set as required, which meets different user’s requirements. Add marks and annotations to the waveform designated, which can rapidly find the waveform in that time by marks. Optional video function: USB camera is easy to install, convenient to use and exact to record. With flexible playback function, which can browse the waveform of any time along with the corresponding isochronous collected image. SpO2 function which can view SpO2 value, pulse rate and SpO2 trend graph is optional. Accessories Standard accessories: Thirty EEG leads Two EEG leads(ear electrode) Two data lines Twenty-five EEG electrodes Two headgears One flashlight One flashlight power supply One disk One User Manual One earth wire Two aluminum blocks EEG bracket(tripod) Optional accessories: ECG lead, ECG electrode(for optional ECG, EOG, EMG function) Disposable respiration probe(for optional respiration function) SpO2 module (one CMS-P SpO2 probe, one disk with software) Video module(one softdog, one camera, one video software disk) Qualification Certificate SFDA, CMC, CE Qualification Certificate Internal registration Qualification Passed FDA/CE Shipment ? 1. For your earlier and safer to receive the item, please leave us your detailed address and telephone number for posting the item. ? 2. Your item will be sent via small parcel within 48 hours after payment is received. The shipping time may is around 5-15days. ? 3. As the usual way, the buyers are responsible for the duties, taxes or other VAT or extro charges from the import countries. ? 4. All items will be shipped to buyer's PayPal address. Please confirm your PayPal address is correct before purchase. ? 5.It's international shipping andAirmail is cheapest post way, so it will take a long time for delivery. If you don't want to wait so long time, please pay the Express fee or don't buy it. Taxes, Customs & Duties There are not extra taxes, VAT or other unmentioned payment. You pay us with goods subtotal + shipping cost (not include duties). But you need to pay for the import duties in case that occurred for certain goods, or you may kindly give us some suggestions about that, we promise to do our best to help you! Feedback Feedback:please leave me a positive feedback if you are satisfied with our products, Your positive feedback will be appreciated very much,thank you very much! If you have any problems, please contact us as soon as possibel before you open a case and leave a negative feedback or ship the item back, we promise we will give you a satisfied answer, thank you for your understanding! Return - After service We offer 14 days return policy. 100% satisfaction is our goal! 1.All items are brand new ,with 1years warranty. 2.If you have a defective item, you want to return or discount. Please contact us within 2 days from you receive the shipment. 3.We will refund the money to you when we get the return items or replace item for you. 4. All return items must be returned with it's original packaging and accessories. Customer is responsible for shipping charges on returned items. International Buyers - Please Note: ? Import duties, taxes and charges are not included in the item price or shippingcharges. These charges are the buyer's responsibility. ? Please check with your country's customs office to determine what these additional costs will be prior to bidding/buying." Payment Terms: 1. Paypal, paypal account: contec9821@gmail.com 2.The payment are expected within 7 business days after the last winning auction is closed. Contact us Contact Person:Liya Tian MSN:contecliya@hotmail.com Tel: 86-335-8015561 Contec Medical Systems Co.,Ltd, Manufacturer, Qinhuangdao, China Address: No.112 Qinhuang West Avenue, Qinhuangdao Economic and Technical Development Zone, Hebei Province, China About us Contec Medical Systems focusing on research, manufacture and distribution of medical instruments,was founded in 1992 as a high-tech company. At present there are more than 1200 employees in our company.Our product line covers a wide range of 13 categories. Most of the domestic hospitals are our customers. Contec hopes to cooperate with international companies to supply more innovative design and advanced technology products We sincerely welcome you to become one of our global partners.We are looking forward to establishing a successful business relationship with you. Buy Safe Product! The following FDA Disclaimer is required for all eBay listing in Healthcare category and is included for REFERENCE: The sale of this item may be subject to regulation by the U.S. Food and Drug Administration and state and local regulatory agencies. If the item is subject to FDA regulation, We will verify your status as an authorized purchaser of this item before shipping of the item.
