Cellflex Superflexible Cable Scf12-50j 40" Male Type

US $400

Tempe, Arizona, United States
Mar 14th

Open on mobile:
QR code

You are bidding on 1 WORKING RFS CELLFLEX SCF12-50J D 32669 1104 40" LENGTH 1/2" CABLE LIKE NEW male to male diffierent N Male Coupler's Technical Features Cable Type Foam-Dielectric, Superflexible Size 1/2" Jacket Standard Return Loss (VSWR) Performance Standard Maximum Return Loss, dB (VSWR) Contact RFS for your VSWR performance specification for your required frequency band. Impedance, Ohm 50 +/- 1 Maximum Frequency, GHz 11.7 Velocity, percent 82 Peak Power Rating, kW 20.5 Inner Conductor dc Resistance, ohm/1000 m (ohm/1000 ft) 2.9 (0.88) Outer Conductor dc Resistance, ohm/1000 m (Ohm/1000 ft) 3.4 (1.04) RF Peak Voltage, Volts 1430 Jacket Spark, Volt RMS 5000 Capacitance, pF/m (pF/ft) 82.0 (25.0) Inductance, µH/m (µH/ft) 0.207 (0.063) Outer Conductor Material Corrugated Copper Inner Conductor Material Copper-Clad Aluminum Wire Diameter over Jacket Nominal, mm (in) 13.7 (0.54) Diameter Outer Conductor, mm (in) 12.3 (0.48) Diameter Inner Conductor, mm (in) 3.6 (0.14) Diameter Dielectric, mm (in) 8.3 (0.33) Minimum Bending Radius, Repeated Bends, mm (in) 32 (1.25) Bending Moment, N•m (lb-ft) 1.8 (1.3) Cable Weight, kg/m (lb/ft) 0.21 (0.14) Tensile Strength, N (lb) 650 (146) Flat Plate Crush Strength, N/mm (lb/in) 20.4 (110) Recommended / Maximum Clamp Spacing, m (ft) 0.30 / 0.30 (1.00 / 1.00) Installation Temperature, °C(°F) -40 to +60 (-40 to +140) Storage Temperature, °C (°F) -70 to +85 (-94 to +185) Operation Temperature, °C(°F) -50 to +85 (-58 to +185) WITH 7/16" MALE TO MALE THE PRODUCT IS USED AND TAKEN FROM A WORKING ENVIROMENT. 10 DAY WARRANTY Technical Features Cable Type Foam-Dielectric, Superflexible Size 1/2" Jacket Standard Return Loss (VSWR) Performance Standard Maximum Return Loss, dB (VSWR) Contact RFS for your VSWR performance specification for your required frequency band. Impedance, Ohm 50 +/- 1 Maximum Frequency, GHz 11.7 Velocity, percent 82 Peak Power Rating, kW 20.5 Inner Conductor dc Resistance, ohm/1000 m (ohm/1000 ft) 2.9 (0.88) Outer Conductor dc Resistance, ohm/1000 m (Ohm/1000 ft) 3.4 (1.04) RF Peak Voltage, Volts 1430 Jacket Spark, Volt RMS 5000 Capacitance, pF/m (pF/ft) 82.0 (25.0) Inductance, µH/m (µH/ft) 0.207 (0.063) Outer Conductor Material Corrugated Copper Inner Conductor Material Copper-Clad Aluminum Wire Diameter over Jacket Nominal, mm (in) 13.7 (0.54) Diameter Outer Conductor, mm (in) 12.3 (0.48) Diameter Inner Conductor, mm (in) 3.6 (0.14) Diameter Dielectric, mm (in) 8.3 (0.33) Minimum Bending Radius, Repeated Bends, mm (in) 32 (1.25) Bending Moment, N•m (lb-ft) 1.8 (1.3) Cable Weight, kg/m (lb/ft) 0.21 (0.14) Tensile Strength, N (lb) 650 (146) Flat Plate Crush Strength, N/mm (lb/in) 20.4 (110) Recommended / Maximum Clamp Spacing, m (ft) 0.30 / 0.30 (1.00 / 1.00) Installation Temperature, °C(°F) -40 to +60 (-40 to +140) Storage Temperature, °C (°F) -70 to +85 (-94 to +185) Operation Temperature, °C(°F) -50 to +85 (-58 to +185)

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Type	Cables
Exact Type	Standards
Manufacturer	sma
