Challenge MS 10A Paper Drill, US $2700 – Picture 0
Challenge MS 10A Paper Drill, US $2700 – Picture 0

Challenge Ms 10a Paper Drill

US $2700

  • Ottawa, Illinois, United States
  • Jul 5th
Open on mobile:
QR code
FEATURES - High Production Multi-Hole Drilling - Drills Up To 10 Holes in One Stroke - Maximum Drill Bit Diameter 1/2" - 2-1/2" Drilling Capacity - Powerful Hydraulic Operation - Easy Head Adjustment - Variable Speed Stroke Control - Automatic Paper Chip Removal - Rugged Cast Iron Construction - Flexible Side Guide Adjustments - Multi-Splined Drive Shaft - Backgauge Adjustments - Lighted Work Surface SPECIFICATIONS Maximum Number of Drill Heads 10 Heads Drill Sizes Available** (2" capacity) 1/8" to 1/2" / 3 to 13 mm Drill Sizes Available (2-1/2" capacity) 1/4" to 1/2" / 6 to 13 mm Center to Center Distance Maximum 21" / 53 cm Center to Center Distance Minimum*** 1-1/4" / 3.2 cm Minimum Distance Between Holes w/ Adj. Stops 3/8" / 9.5 cm Minimum Distance Between Holes w/ Fixed Gauges 1/4" / 6 mm Maximum Drilling Capacity 2-1/2" / 6.35 cm Strokes per Minute (adjustable) 18 to 26 Backgauge Adjustment 0 to 9" / 0 to 23 cm Vertical Adjustment of Individual Heads 1/4" / 6 mm DIMENSIONS Table Size 24" x 36" / 61 x 91 cm Table Height 38" / 96.5 cm Overall Height 60" / 152 cm Floor Space Needed 35" x 40" / 89 x 102 cm Net Weight (approximate) 1350 lbs / 675 kg Shipping Weight (approximate) 1660 lbs / 830 kg ELECTRICAL Standard -3 Phase, 60 Hz, AC.   Pump: 3/4 HP.  Spindle Motor: 3 HP. 208 Volts, 14 Amps (service size 20 Amps) or 230 Volts, 12.8 Amps (service size 20 Amps) or 460 Volts, 6.6 Amps (service size 15 Amps) Optional -1 Phase, 60 Hz, AC.   Pump: 3/4 HP.  Spindle Motor: 3 HP 208 Volts, 26.5 Amps (service size 40 Amps) or 230 Volts, 24.2 Amps (service size 40 Amps)
“Drill has had light use over the last 10 years. It functions as designed. A few additional safety features have been added. See pics.”
Model Challenge MS 10A
Brand Challenge

Directions
