Char-lynn 101-1004-009 / Eaton 101-1004 Motor

US $100.00

Irmo, South Carolina, United States
Jun 9th

Open on mobile:
QR code

101-1004-009 Manufactured by EATON CORPORATION CHAR LYNN HYDRAULIC MOTOR 353RPM 1650PSI 1/2IN PIPE PORTS Standard Seals, Painted Low Gloss Black 2 Mils Min Thick 1ST PRIMARY PARAMETER: Geometric Displacement (Cu. In./Rev.) 2ND PRIMARY PARAMETER: Output Shaft Size 3RD PRIMARY PARAMETER: Inlet And Outlet Ports Size ACTUAL CASE DRAIN: No Case Drain ACTUAL MOUNTING FLANGE: 4 Bolt Std: 44.4 .75 Dia. X 3.0 12 Pilot, .375-16 Mounting Holes On 82.6 .25 Dia. B.C. ACTUAL OUTPUT SHAFT: 25.4 .00 Dia. Straight With Woodruff Key And 1/4-20 Threaded Hole ACTUAL PORT TYPE: .500-14 Nptf Dryseal Pipe thread Accepts Dryseal Fittings Per Sae J476A Additional Detail: To Assure Best Motor Life, Run Motor For Approximately One Hour At 30 Percent Of Rated Pressure Before Application To Full Load. Be Sure Motor Is Filled With Fluid Prior To Any Load Applications. B&W IMAGE: bwEaton_HSeries_4Bolt.tif Case Drain: No Case Drain Color Image: Eaton_HSeries_4Bolt.tif DESIGN CODE: Nine - 009 DUP: DUP Electronic Catalog: Click here ELECTRONIC PARTS DRAWING: Click here ELECTRONIC REPAIR MANUAL: Click here Feature: ############################################################################################################################################################################################################################################################### FLOW (GPM): Continuous: 15 gpm / Intermittent: 20 gpm Geometric Displacement (cu-iIn./rev): 9.70 GROUP: Hydraulic INDEX: Motors Inlet And Outlet Ports Size: 1/2"-14 NPTF Ports Size 8MP ITEM SEQUENCE: 28 Manufacturer Series: H Series MANUFACTURER'S ACTUAL DISPLACEMENT: 159 Cm3/R, 9.7 In3/R MINIMUM STARTING TORQUE (LB-IN.): Continuous: 1,650 Lb-In. / Intermittent: 2,320 Lb-In. Operation Rating Description: Continuous Rating - Motor May Be Run Continuously At These Ratings. / Intermittent Operation - 10 Percent Of Every Minute / Peak Operation - 1 Percent Of Every Minute Output Shaft Size: 1" Straight With Woodruff Key PACKAGE QUANTITY: 1 Each PAINT / SPECIAL PACKAGING: Painted Low Gloss Black, 2 Mils Min Thick PAPER CATALOG: 11-885 PRESSURE (PSI): Continuous: 1,650 psi / Intermittent 2,250 psi PRODUCT NO.: CN060205002 PRODUCT NO. DESCRIPTION: 060205 - 00162 - Hydraulic Spool Valve Gerotor Motor - H Series RECOMMENDED FILTRATION: Per Iso Cleanliness Code. Level 18/13 RECOMMENDED FLUIDS: Premium Quality, Anti-Wear Type Hydraulic Oil With A Viscosity Of Not Less Than 701 Sus Or 13Cst With Best Range Of 100 - 200 Sus Or 20 - 43 Cst At Operating Temperature, RECOMMENDED MAXIMUM SYSTEM OPERATING TEMPERATURE: 82C Or 180F REPAIR MANUAL: 7-117 REPAIR PARTS DRAWING: 6-121 REPLACEMENT BEARING, THRUST NEEDLE - SOLD SEPARATELY: 009, 008 & 007 Design - 7537-000 - 1 Required Replacement Buna Seal Kit - Sold Separately: 009 & 008 Design - 60540-000; 007 Design - 60023-000 - 1 Required Replacement Drive - Sold Separately: 009 Design - 8664-000 - 1 Required REPLACEMENT GEROTOR - SOLD SEPARATELY: 009 Design - 8277-004 - 1 Required REPLACEMENT LONG CAP SCREW (CAP END) - SOLD SEPARATELY: 009 Design - 16294-212 - 7 Required Replacement Mounting Flange - Sold Separately: 009 & 008 Design 22000-002, 007 Design 7464-000 - 1 Required Replacement Output Shaft - Sold Separately: 009, 008 & 007 Design - 7360-001 - 1 Required REPLACEMENT PLATE, SPACER - SOLD SEPARATELY: 009, 008 & 007 Design - 7358-000 - 1 Required REPLACEMENT RACE, THRUST BEARING - SOLD SEPARATELY: 009, 008 & 007 Design - 7462-000 - 1 Required Replacement Rear Housing - Sold Separately: 009 Design - 22230-002, 008 & 007 Design - 7359-002 - 1 Required Replacement Short Cap Screw (Mounting End) - Sold Separately: 009, 008 & 007 Design - 16292-088 - 4 Required Replacement Viton Seal Kit - Sold Separately: 009 & 008 Design - 60544-000; 007 Design - 60032-000 - 1 Required SEALS: Standard Seals Series: H Series Gerotor Motor SPECIAL FEATURES: Not Listed SPECIAL FEATURES - ASSEMBLY: None SPECIAL FEATURES - HARDWARE: None SPEED (RPM): Continuous: 353 rpm SUB HEADING: H Series - 4 Bolt Flange Mount TORQUE (LB-IN.): Continuous: 2,059 Lb-In. / Intermittent: 2,824 Lb-In. Type Of Mount: 4 Bolt - 1-3/4" Pilot Dia. With 3/8"-16 UNC-2B Mtg Holes Weight Ea.: 12.5 Lbs ALTERNATE PART NUMBER: CHA101-1004, 101-1004

“never been used just showing slight wear from storage”

Brand	Eaton
MPN	101-1004-009
Model	101-1004-009, 00768045
