Char-lynn (eaton) - 101-1022-009 - Hydraulic Motor

US $2600

West Chicago, Illinois, United States
Feb 22nd

Open on mobile:
QR code

This is off a machine that never did get used. It's inlet is 1/2" Female NPT and the outlet is a 1/4" male NPT. General Information Case Drain: No Case Drain Inlet And Outlet Ports Size: Manifold Ports 5/16"-18 UNC Thread Geometric Displacement (cu-iIn./rev): 14.10 Output Shaft Size: 1" Straight With Woodruff Key Series: H Series Gerotor Motor SPECIAL FEATURES: Not Listed Type Of Mount: 4 Bolt - 1-3/4" Pilot Dia. With 3/8"-16 UNC-2B Mtg Holes ACTUAL CASE DRAIN: No Case Drain ACTUAL MOUNTING FLANGE: 4 Bolt Std: 44.4 .75 Dia. X 3.0 12 Pilot, .375-16 Mounting Holes On 82.6 .25 Dia. B.C. ACTUAL OUTPUT SHAFT: 25.4 .00 Dia. Straight With Woodruff Key And 1/4-20 Threaded Hole ACTUAL PORT TYPE: Manifold (.3125-18 Unc Thd.) Additional Detail: To Assure Best Motor Life, Run Motor For Approximately One Hour At 30 Percent Of Rated Pressure Before Application To Full Load. Be Sure Motor Is Filled With Fluid Prior To Any Load Applications. DESIGN CODE: Nine - 009 Electronic Catalog: Click here ELECTRONIC PARTS DRAWING: Click here ELECTRONIC REPAIR MANUAL: Click here FLOW (GPM): Continuous: 15 gpm / Intermittent: 20 gpm Manufacturer Series: H Series MANUFACTURER'S ACTUAL DISPLACEMENT: 231 Cm3/R, 14.1 In3/R MINIMUM STARTING TORQUE (LB-IN.): Continuous: 2,110 Lb-In. / Intermittent: 3,000 Lb-In. Operation Rating Description: Continuous Rating - Motor May Be Run Continuously At These Ratings. / Intermittent Operation - 10 Percent Of Every Minute / Peak Operation - 1 Percent Of Every Minute PACKAGE QUANTITY: 1 Each PAINT / SPECIAL PACKAGING: Painted Low Gloss Black PAPER CATALOG: 11-885 PRESSURE (PSI): Continuous: 1,450 psi / Intermittent 2,000 psi RECOMMENDED FILTRATION: Per Iso Cleanliness Code. Level 18/13 RECOMMENDED FLUIDS: Premium Quality, Anti-Wear Type Hydraulic Oil With A Viscosity Of Not Less Than 701 Sus Or 13Cst With Best Range Of 100 - 200 Sus Or 20 - 43 Cst At Operating Temperature, RECOMMENDED MAXIMUM SYSTEM OPERATING TEMPERATURE: 82C Or 180F REPAIR MANUAL: 7-117 REPAIR PARTS DRAWING: 6-121 REPLACEMENT BEARING, THRUST NEEDLE - SOLD SEPARATELY: 009, 008 & 007 Design - 7537-000 - 1 Required Replacement Buna Seal Kit - Sold Separately: 009 & 008 Design - 60540-000; 007 Design - 60023-000 - 1 Required Replacement Drive - Sold Separately: 009 Design - 22190-000 - 1 Required REPLACEMENT GEROTOR - SOLD SEPARATELY: 009 Design - 8277-025 - 1 Required REPLACEMENT LONG CAP SCREW (CAP END) - SOLD SEPARATELY: 009 Design - 16294-250 - 7 Required Replacement Mounting Flange - Sold Separately: 009 & 008 Design 22000-002, 007 Design 7464-000 - 1 Required Replacement Output Shaft - Sold Separately: 009, 008 & 007 Design - 7360-001 - 1 Required REPLACEMENT PLATE, SPACER - SOLD SEPARATELY: 009, 008 & 007 Design - 7358-000 - 1 Required REPLACEMENT RACE, THRUST BEARING - SOLD SEPARATELY: 009, 008 & 007 Design - 7462-000 - 1 Required Replacement Rear Housing - Sold Separately: 009 Design - 22230-003, 008 & 007 Design - 7359-003 - 1 Required Replacement Short Cap Screw (Mounting End) - Sold Separately: 009, 008 & 007 Design - 16292-088 - 4 Required Replacement Viton Seal Kit - Sold Separately: 009 & 008 Design - 60544-000; 007 Design - 60032-000 - 1 Required SEALS: Standard Seals SPECIAL FEATURES - ASSEMBLY: None SPECIAL FEATURES - HARDWARE: None SPEED (RPM): Continuous: 243 rpm TORQUE (LB-IN.): Continuous: 2,669 Lb-In. / Intermittent: 3,671 Lb-In.
