Charmilles Robofil 690 Wire Edm

US $5400

  • Auckland, default, New Zealand
  • May 28th
Open on mobile:
QR code
Charmilles Robofil 690 EDM  2001 with the following specs,MAXIMUM PART SIZE .................... 54.3" X 39.4" x 15.7" MAXIMUM WEIGHT OF WORKPIECE........... 5,071 LBS. TABLE DIMENSIONS...................... 48" x 35.8" X-AXIS TRAVEL......................... 31.5" Y-AXIS TRAVEL......................... 23.6" Z-AXIS TRAVEL......................... 15.7" U/V-AXIS TRAVEL....................... +/- 1.2" MAX. TAPER ........................... +/- 15 DEG./4.3" TOTAL VOLUME OF DIELECTRIC ........... 66 GALLONS   APPROX. DIMENSIONS, L-R x F-B X H   .................................... 92.5" x 100.4" x 86.6" APPROX. WEIGHT ....................... 10,672 LBS. This machine is in working condition but has the following defects, it had suffered a stress crack through the base of the machine which I believe is not uncommon with this model. It was professionally  repaired in 2012 with some kind of resin and an steel brace plate. We believe it is no longer 100% accurate and maybe the table needs attention to make it flat.There is no chiller or resin bottle also. The machine could be brought back to life maybe? Or parted out for spares as parts alone would make it valuable. I have a video taken 2nd April 2016 to view as we still use this machine . view on youtube search for "charmilles robofil 690"  It is sold strictly on an as is where is bases and make absolutely no promises as to its function, it is therefore assumed as parts only merchandise. Buyer must arrange all shipping and removal, selling world wide
