Cheetah 8.6a Dc Motor Controller

US $29.77

Swanton, Vermont, United States
Jul 1st

Open on mobile:
QR code

Description 8.6A DC motor controller 32-bit on-board quadrature encoder Overheating and short circuit protection Enable and disable input The Cheetah 8.6A DC Motor Controller is a motor driver board which is interfaced using GPIO and SPI. The board has an L9958 DC motor driver chip, which is an SPI controlled H-Bridge designed for the control of DC motors under extreme condition. The board also has a 32-bit quadrature counter for quadrature encoder feedback. Features: On-board 32 bit quadrature encoder for speed and position feedback chip Operating frequency of L9958 is up to 20 kHz Open load detection in condition SPI for configuration X1, X2 or X4 mode of quadrature counting Specifications Interfaces: Communication interfaces: SPI Other interfaces: GPIO, PWM, ADC General specifications: Compatible controllers: Cheetah-CB On-board crystal: 20MHz Motor driver current rating: 8.6A Motor supply voltage: 4V to 28V Motor type: DC motor Number of DC motor channels: 1 Supply voltage: 5V Power supply options: External power Dimensions Size: 50.8mm x 38.74mm

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Phi Robotics
Type	Phi Robotics
MPN	H-ELC-MDR-DC-1
UPC	Does not apply
