Cheshire Videojet Mail Tabber

US $9949

Lexington, Kentucky, United States
Nov 5th

Open on mobile:
QR code

Cheshire Videojet TLS 2" Mail Tabber for sale. Was $22,000 brand new. Used in a professional mail house, includes a Straight Shooter C12 feeder as well. ($3,200 new) Tabber is in very good condition, can demo if you'd like. Also includes 500,000 tabs! Any questions please text or call (859) 948-3171 Thanks, Jason Here are the specs: Product Size Minimum: 3" x 5" (7.6 x 10 cm) Maximum: 13.5" x 17" (34 x 43 cm) long Min. Thickness: Folded 20# single sheet Max. Thickness: 5/8 (1.6 cm) Tabs/Labels/Stamps Self-adhesive on roll with 3" (7.6 cm) core with min. 1/16" (1.66 mm) gap between tabs, labels, stamps Min. Width: 3/4 " (1.9 cm) backer width Max. Width: 2" (5 cm) backer width with 2" system; 4.5" (11 cm) backer width with 4.0" (10 cm) system Minimum Pitch: 3/4" (1.9 cm) Maximum Pitch: 7" (17 cm) Types: machine grade paper, clear, and translucent. Note: clear and translucent require an "engineered backer" with registration marks for indexing Roll Size: up to 19 1/2" (49.5 cm) diameter mounted on 3" (7.6 cm) diameter core. Approx. Roll Capacity: 50,000 ea. 3/4" (1.9 cm) or 40,000 ea. 1" (2.5 cm) tabs Speeds Transport Belt Speed: 0 to 600 fpm (182 m/min.) Tabbing Head Speed: 0 to 375 fmp (114 m/min.) Production Rate: Up to 30,000 pieces per hour (single tab on 8 1/2" (21 cm) length product); up to 30,000 pieces per hour (double tab on 8 1/2" (21 cm) length product) Application Speeds: Transport belt speeds of 0 to 600 fpm (182 m/min.) for tabs < 2" (<5 cm) in pitch. Transport belt speeds of 0 to 375 fpm (0 to 114 m/min.) for tabs > 2" tabs (>5 cm) in pitch Accuracy Tab placement: +/- 1/8" (+/- 3 mm) repeatability Automatic placement according to USPS specifications for tab placement and application Interconnect Cables Emergency Stop – Cabling available to permit easy interconnection between emergency stop circuits of the TLS system and Cheshire 7000 Series Bases Dimensions System Length: 37" (94 cm) System Width: 33" (84 cm) System Height: 71" (180 cm) Tabletop Height: 34 3/4" to 37 3/4" (88 cm to 96 cm) Weight Approx. 450 lbs. (204 kg) Electrical Requirements 115 VAC @ 10 amps
