Clamp-on Meter Ac/dc600v 600a Ohm Cap. Temp. -20-1000c Freq. Duty Cycle Ms2008b

US $34.00

Shenzhen, China
Jan 29th

Open on mobile:
QR code

Features: 3999 counts. Jaw size: Diameter 26mm/1’’. DCV/ACV, ACA, Resistance, , Capacitance, frequency, Temperature, Duty cycle, Diode and Continuity test with Buzzer. Conform to IEC-61010-1, CAT III 600V. Double Molded Rubber Case. Auto/Manual Range. Power off automatically. Max/Min values . Data hold. Clamp light. Back light. Specifications: DC Voltage Range Resolution Accuracy 400mV 0.1mV ±(0.8% reading + 2digits) 4V 1mV 40V 10mV 400V 0.1V 600V 1V ±(1.0% reading +2 digits) Input impedance: 10MW. Max input Voltage: 600V DC or 600V AC Peak. AC Voltage Range Resolution Accuracy 400mv 0.1mV ±(1.0% reading + 10digits) 4V 1mV 40V 10mV 400V 0.1V 600V 1V ±(1.2% reading + 10digits) Input impedance : 10MW. Frequency response: 40Hz-400Hz Max input Voltage : 600V DC or 600V AC Peak. AC Current Range Resolution Accuracy 4A 0.001A ±(3.5% reading + 20digits) =<0.5A ±(3.0% reading +10 digits) 40A 0.01A ±(3.0 % reading +10 digits) =<5A ±(2.5% reading + 10 digits) 400A 0.1A ±(2.5% reading + 10 digits) 600A 1A ±(1.5% reading + 5 digits) Frequency response: 50Hz-60Hz Max Input Current: Full Range x120% and measuring time less than 60 seconds. Resistance Range Resolution Accuracy 400W 0.1W ±(1.2% reading+ 2digits) 4kW 0.001kW 40kW 0.01kW 400kW 0.1kW 4MW 0.001MW 40MW 0.01MW ±(2.0%reading+ 5digits) Overloading protection: 600V DC or 600V AC peak Capacitance: 50n/500n/5?/50?/100?F±4.0% Frequency: 0-100KHz±(0.1%+3) Temperature: -20C to 400C, ±(2%+2),+-(2%+2C), resolution 0.1C; 401C to 1000C, +-2%readings, resolution 1C. Duty cycle: 0.1% to 99.9%, ±(3%), resolution 0.1%. Diode Resolution Accuracy 1mV Display forward Voltage (Open circuit voltage approximate 1.5V) Overloading protection: 600V DC or 600V AC peak Continuity Resolution Accuracy 100mW Less than about =<60? will beep(Open circuit voltage approximate 0.45V) (Warning: the buzzer may or may not sounds if the resistance of a circuit under test is between 60 ohm to 120 ohm. The buzzer does not sound if the resistance of a circuit under test is higher than 120 ohm) Overloading protection: 600V DC or 600V AC peak Power: AAA (1.5V) x 3 Size: 208mm x 78mm x 35mm Accessories: Test leads, temperature probe, bag. Note: we'll ship this item via epacket to USA, usually the delivery time is about 2-3 weeks; For other countries, usually we will ship it via registered air mail of China Post, usually the delivery time is about 30-40 days. If you want express mail service, pls contact us for extra postage in advance.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	MS2008B
Country of Manufacture	China
MPN	MS2008B
Country/Region of Manufacture	China
