Clausing 22" Model 2284 Dual Head Vari Speed Drill Press W/ 2217 Power Feed Unit

US $6,950.00

Fountain Valley, California, United States
Jan 30th

Open on mobile:
QR code

CLAUSING 22" MODEL 2284 DUAL HEAD VARIABLE SPEED DRILL BANK / DRILL PRESS 20aЂ? Drill Press Superior Features... aЂ? Heavy-duty precision head... all bearing surfaces are precision bored simultaneously for exact alignment aЂ? Eight ball bearings support drive and spindle aЂ? 3MT spindle with 6A?a?„a‚‚aЂ? travel and 2A?a?„a‚‚aЂ? diameter quill... micrometer depth stop aЂ? 4aЂ? Turned and ground steel column with A?a?„a‚‚aЂ? thick wall for greater rigidity and accuracy aЂ? Precision ground oil trough tables...handle big workpieces easier aЂ? 150 to 2000 rpm, select the right speed to drill, spot face, counterbore or ream Handle more jobs... better and Infinitely Variable Speed Countershaft Drive... Dial to the best rpm for the tool and material while the job is running, with a Clausing Two Speed Variable Speed Drill Press. oЂЂЂ 150 to 2000 rpm... speeds to drill large holes, small holes to spot face, counterbore and ream. oЂЂЂ A flip of the switch changes from low range to high range, perfect for production applications with quick change tooling. oЂЂЂ Greater capacity, too, with Clausing Two Speed, production rated 1" in cast iron, 3/4" in steel with optional power feed. Handle more jobs ... better, faster with a Clausing 20" Two Speed drill press. More features for superior performance... oЂЂЂ Heavy-duty precision head... all bearing surfaces are precision bored simultaneously for exact alignment. Eight ball bearings support the drive and spindle, lower spindle bearing has a double row to absorb both radial and thrust loads. oЂЂЂ 3 MT spindle... with 6-1/2" travel, 2-1/2" diameter quill and micrometer depth stop. oЂЂЂ 4" column with 3/16" thick wall for great rigidity and accuracy. oЂЂЂ Precision ground 22" x 19" oil through table, handles large parts and fixtures. Capacity, hand feed 1.25" (31.75mm) dia. Production rated, with optional power feed, 11/2 hp motor 1" (25.4mm) in cast iron 3/4" (19mm) in mild steel Drill to center of circle 20" (508mm) dia. Spindle nose No. 3MT, 1.74" (44.2mm) OD Spindle travel 6.5" (165mm) Column ground steel, 4" (102mm) dia., 3/8" (9.5mm) thick wall Quill (ground steel) 2.5" (63.5mm) dia. Quill return spring, capacity 40 lbs (18kg) TABLE, DRILL PRESS Style A Working surface 22" x 19.5" (559 x 495mm) Table slots two, 15.5" (394mm) long, for .5" (12.7mm) T-bolt Table travel, one setting 20" (508mm) Spindle to table, maximum 33.125" (841mm) BASE, DRILL PRESS Style A Working surface, ground 15.5" x 13" (394 x 330mm) Base T-slots two, 13" (330mm) long, for .5" T-bolt Spindle to Base, maximum 43.375" (1102mm) DRILL PRESS Style B Column bracket to center of spindle 9.25" (235mm) Column to center of spindle 10" (254mm) Spindle to table, max. distance 25.437" (646mm) Column length 43" (1092mm) Min. center to center distance 20" (508mm) Motor ... NEMA Frame Sizes 182 and 184 Shipping weights, approximate, with motors Drill press Style A 630 lbs. (286kg) Drill press Style B 390 lbs. (177kg)

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Brand	CLAUSING
Country/Region of Manufacture	United States
Model	2284
