Clean Tektronix Of152 Fiber Optic Tdr 1300nm Multimode Time Domain Reflectometer

US $229.60

San Jose, California, United States
Jan 29th

Open on mobile:
QR code

Clean Tektronix OF152 Fiber Optic TDR 1300NM Multimode Time Domain Reflectometer Tektronix OF152 1300 nm Fiber Optic TDR makes quantitative, calibrated loss and distance measurements on multimode fiber at the 1300 nm wavelength. The instrument typically measures breaks through 35 dB, and splices to ±0.1 dB through 13.5 dB of one way cable loss depending on fiber characteristics. Maximum readout range is 60 km, with finely detailed resolution to one meter. The OF152 OTDR allows fast and accurate loss measurement, providing an instant, at-a-glance view of the fiber length on the built-in CRT screen. The OF152 is portable, with a single handle for carrying ease. It operates at virtually any altitude or temperature, from a 12 V vehicle system, an external battery pack or ac. No regulated power source is required. Details: Manufacturer: Tektronix Model: OF152 Specifications: Wavelength: 1300 nm (typical). Displayed Pulse Width Long Pulse: 110m, ± 6 m. Displayed Pulse Width Short Pulse: 20 m, ± 1.2 m. System Pulse Rate: 1.550 kHz ± 1.5 Hz. Optical Output Amplitude: >19 uW Time-average power coupled into test liber (50 um core, 0.20 NA) (Long Pulse mode). Absolute Maximum Optical Output Amplitude: 50 uW time average. Displayed Pulse Risetime: < 10m from - 20 dB point to - 6 dB point. Vertical Scales: 10 dB div and 2 dB div (10 div). dB Scale Accuracy: ± 0.5 dB over any 10 dB div increment from + 20 dB to + 60 dB, relative to bottom of display range. Distance Scales: 5 m/div to 5000 m/div. Display Limits: - 25 m to 60 km from front-panel connector. Distance - LCD Readout Range: 0 km to 60.0 km. Readout Resolution: 1 m. Cal Factor Range: 4.9 ns/m to 5.1 ns/m. Condition: Good cosmetic condition with some signs of previous use (See photos for more detail) Tested: This unit was removed from a working environment, but I do not have the knowledge or resources to test it fully. It has been tested for power on only, as pictured. Warranty: 14-Day Right-of-Return ________________________________________________________________________________________________________________________________________________________________ Terms and Conditions Only the items pictured will be included. If it is not pictured or mentioned in the description it is not included. If you have any questions, please contact us before bidding or buying. Payments: Payment must be received within three (3) days of the date of purchase. We currently only accept PayPal. If you are having trouble completing your purchase, please feel free to contact us. All California buyers wil be charged 8.375% sales tax. Shipping: Buyer is responsible for all shipping costs, including return shipping in the event of a return. All items will be securely packed and shipped with the buyers requested method. If you would like to add shipping insurance, please conact us for rates, and coverages. Warranty *Please see listing above for the warranty that applies to this item. As-Is, No Returns: When an item is stated as being AS-IS, the condition of the item is either unknown or has known issues (as stated in the description) and does NOT carry any warranty and NO returns will be accepted for this item. 14-Day Right-of-Return: You have fourteen (14) days to contact us for a replacement or refund. We can not warranty compatibility with your equipment, or warranty items that have been altered or damaged. We maintain the right to use our descretion when choosing between a replacement or refund. Returns: NOTE: Original shipping charges are Non-Refundable Defective/DOA: We accept returns for Defective/DOA items within 14 days of receipt by the customer. If you receive an item that is damaged or defective, please contact us as soon as possible, and we will, at our discretion, refund or replace the item. The customer is responsible for all return shipping charges. Non-DOA: If you purchase an item, and decide within 14 days, that you no longer wish to keep it, we will accept it back for a refund, less a 15% restocking fee. This includes items that end up not being compatible or are simply the wrong part. You are responsible to determine compatibility before you purchase. For Non-DOA returns, items are expected to be in the same condition they were in when they were shipped. The customer is responsible for all return shipping charges. Return Shipping: The customer is responsible for all return shipping charges. Feedback: It is our Mission to assure that all of our customers are 100% satisfied with their purchases. Should there ever be a problem, we ask that you contact us before leaving feedback, so that we can correct the problem. THANK YOU!

Condition	Used : An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections.
Seller Notes	“Unit us clean and well taken care of.”
