Clifton Synchro Control Transformer Nsn:5990-00-725-7812 P/n 11-ndt-24e/a018

US $39.00

Farmingdale, New York, United States
Jan 29th

Open on mobile:
QR code

CLIFTON DIV OF LITTON INDUSTRIES SYNCHRO CONTROL TRANSFORMER, Model: 11-NDT-24E/A018, NSN; 5990-00-725-7812, US ARMY P/N: 10033258-1 Alternate P/N: CT11N2 MOOG INC NOS CONDITION. NEVER USED. ORIGINAL PACKAGING AS SHOWN, PACK DATE 6/80 OPENED FOR PHOTO. TRACEABLE GOVT CONTRACT # 14 DAY WARRANTY FOR COMPLETE REFUND. US GOVT PRICE 2006 $175.00/EA Value BODY MATERIAL STEEL, STAINLESS BODY STYLE STANDARD ROUND C SHOULDER DIAMETER 0.9995 INCHES MINIMUM AND 1.0000 INCHES MAXIMUM PILOT DIAMETER 0.4995 INCHES MINIMUM AND 0.5000 INCHES MAXIMUM OVERALL LENGTH 1.9750 INCHES NOMINAL FLANGE DIAMETER 1.0610 INCHES MINIMUM AND 1.0620 INCHES MAXIMUM FLANGE THICKNESS 0.0620 INCHES NOMINAL UNDERCUT DIAMETER 0.9750 INCHES NOMINAL UNDERCUT WIDTH 0.0810 INCHES NOMINAL SHAFT DIAMETER 0.1195 INCHES MINIMUM SINGLE SHAFT AND 0.1200 INCHES MAXIMUM SINGLE SHAFT SHAFT LENGTH 0.3750 INCHES NOMINAL SINGLE SHAFT BODY SIZE 11 STATOR INPUT VOLTAGE RATING IN VOLTS 90.0 NOMINAL STATOR INPUT CURRENT RATING 17.0 MILLIAMPERES NOMINAL STATOR INPUT ELECTRICAL POWER RATING 310.0 MILLIWATTS NOMINAL FREQUENCY IN HERTZ 400.0 NOMINAL ZRO RESISTANCE IN OHMS 680.00 NOMINAL ZSO RESISTANCE IN OHMS 1050.00 NOMINAL STATOR DC RESISTANCE IN OHMS 645.00 NOMINAL PHASE SHIFT ANGLE IN DEG 6.000 INPUT TO OUTPUT NOMINAL MAXIMUM TOTAL NULL VOLTAGE OUTPUT IN MILLIVOLTS PER VOLT 100.00 ELECTRICAL ERROR ANGULAR RANGE IN MINUTES -12.0/+12.0 ACTUATOR FRICTION TORQUE AT MINUS 55 DEG CELSIUS 6.0 CENTIMETER-GRAMS NOMINAL ACTUATOR FRICTION TORQUE AT PLUS 25 DEG CELSIUS 3.0 CENTIMETER-GRAMS NOMINAL PILOT LENGTH 0.0620 INCHES NOMINAL SHOULDER LENGTH 0.0620 INCHES NOMINAL MOUNTING SURFACE TO TERMINAL END DISTANCE 1.6000 INCHES MAXIMUM TERMINAL LOCATION REAR PLUS J ZRO REACTANCE IN OHMS 2670.00 NOMINAL SHAFT SLOT DEPTH 0.0220 INCHES MINIMUM SINGLE SHAFT AND 0.0320 INCHES MAXIMUM SINGLE SHAFT

Condition:	New other (see details): A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections. ...	Brand	CLIFTON DIV OF LITTON INDUSTRIES
MPN	5990-00-725-7812
Model	P/N 11-NDT-24E/A018
Country of Manufacture	United States
