Close Loop Stepper Motor Driver Kits 8n.m Servo Driver+close Loop Stepper Motor

US $392.66

Shenzhen, China
Jul 25th

Open on mobile:
QR code

Close Loop Stepper Motor Driver Kits 8N.m Servo Driver+Close Loop Stepper Motor The HSS86 is a new hybrid stepper motor servo drive with communication capabilities. It use a new generation of 32-bit Digital Signal Process control technology and vector control technology, it can prevent losing step and ensure the accuracy ; high-speed moment of force attenuation is much lower than that of ordinary open-loop drivers, which can greatly improve the high-speed performance and moment of force of stepper motors; The current control technology effectively reduces the temperature rise of the motor and prolongs the service life of the motor; the position error alarm function ensures the safe operation of the processing equipment. It is an ideal upgrade for traditional open-loop stepper drives and can replace some traditional AC servo systems. Features: 1. The RS232 interface is open, and the user can change the internal data of the drive through the host computer software according to the requirements. 2. Advanced 32-bit motor control dedicated Digital Signal Process chip and vector close loop control technology. 3. Stepping close loop circuit system, no loss of movement synchronization. 4. Increase the output moment of force and running speed of the motor. 5. Current is adjusted depending on the load, reducing motor temperature rise. 6. Fit for all kinds of machinery load conditions (including low rigidity belt wheel and pulley) without adjusting the gain parameters. 7. Motor runs smoothly, vibrates mildly, and improves acceleration and deceleration dynamic performance. 8. Zero-speed static capability without vibration after positioning is completed. 9. Impulse response frequency is up to 200kHz. 10. Maximum 51200 steps/rotation, 16 kinds of optional segment. 11. With over-current, over-voltage, position tolerance and other protection. Specification: Condition: 100% Brand New Item Type: Close Loop Stepper Motor Driver Kits Model: 86HSE12N-BC38 Voltage: AC20V~80V / DC30~110V Number of Poles: Double Motor power: 250W Motor rated speed: 0~3000rpm Peak output current: 8.0A (current varies with load) Logic input current: 7~20mA Pulse frequency: 0~200KHz Encoder line: 1000 Insulation resistance: >=500M Motor moment of force : 12N.m Package List: 1 * Driver 1 * Motor 2 * Cable 1 * Instruction Manual Terminal and Wiring: 1. Motor and Power Input Terminal Connection color A+ A phase motor coil+ red A- A phase motor coil- green B+ B phase motor coil+ yellow B- B phase motor coil- blue AC1 Input power supply AC20V~80V AC2 2. Encoder Input Terminal Connection Color EB+ Encoder B phase input + yellow EB- Encoder B phase input - green EA+ Encoder A phase input + black EA- Encoder A phase input - blue VCC Encoder power supply ++5V) red EGND Encoder power supply GND0V) white (Incorrect encoder wiring will cause driver or encoder damage) 3.Control Signal Terminal Connection Function PUL+ Pulse input + If control signal level is 5V, no need to connect resistor to signal input; If control signal level is 12V, a 1K resistor need to be connected to signal input in series; If control signal level is 24V, a 2K resistor need to be connected to signal input in series. PUL- Pulse input- DIR+ Direction input + DIR- Direction input - ENA+ Enable input + ENA- Enable input - Pend+ Pend output+ OC door output, close indication location is complete, open indication location is incomplete. Pend- Pend output - ALM+ Alarm output + OC door output, close indication has alarm signal, open indication has no alarm signal Indicator Light: PWR: Power supply indicator. Green light is on when power on. ALM: Malfunction indicator. Red light flashing once within 3 seconds indicates over-current or interphase short circuit; red light flashing twice within 3 seconds indicates over-voltage; red light flashing three times within 3 seconds indicates position out-of-tolerance protection. Note: 1. Please allow slight error due to manual measurement. Thanks for your understanding. 2. Monitors are not calibrated same, item color displayed in photos may be showing slightly different from the real object. Please take the real one as standard. We accept PayPal . We ship item to your PayPal verified address. Payment must be received within 3 days from the date of purchase. All the items will be dispatched within one business day by Airmail after the payment is clear. Most times you will receive your order within 10-30 business days after we transfer your package to the delivery company. We cannot guarantee the delivery timeframe if the post office has any unexpected delays due to holiday, weather, customs, or other conditions. Some countries like Russia, Brazil, or some European countries may take up to 50 days or longer for delivery. We appreciate your patience if you haven't received items in 30 days(Russian customers may need more patience by reason of the local delivery system and/or customs). If you are concerned in any way, please feel free to contact us via ebay message instead of leaving negative/neutral feedback or opening a dispute. We will make every effort to fix any problem(resend or refund any missing item). Customs duty is obligation and liability of citizens in your country, so buyer should be responsible for any tax and custom duty incurred. Generally, the delay or failure delivery is sometimes caused by the policy of different customs. 1. Our listing price includes the value of goods,packaging cost,and export taxes,not including international duties. 2. duties,taxes,and charges are not included in the item price or shipping fee. 3. The duties are buyers' responsibility.Please check with your country's customs office determine what these additional costs will be prior to your purchase. 4. All disputes arising from the duties will be submitted to ebay for solution. 1. Any questions, pls. contact us via ebay message or email us.We will reply your message within 48 hours. If you do not receive our reply within 48 hours, pls. post a message again because sometimes our message system may block some emails. 2. If you are satisfied with our service, pls. kindly leave us a positive feedback and give us the Detailed Seller Rating with all "5 " in very area 3. Our aim is to provide Level Customer Service, your recognition will encourage us greatly and serve you better. We strive to keep all our customers satisfy. We will do our up most to exceed your expectations in customer service, communication and dispatching of your orders.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Unbranded
MPN	Does not apply
UPC	Does Not Apply
ISBN	Does Not Apply
EAN	Does Not Apply
