Cmm Fixture Plate 24 X 24 W/ Fixture Kit Inch Version By Fixlogix Free Shipping

US $11000

Charlotte, Michigan, United States
Jun 9th

Open on mobile:
QR code

FREE SHIPPING TO THE LOWER 48! Fixture Plates: All plates are 1.375" thick, dual layer aluminum fabrications, anodized for surface toughness. Laser engraved reference scales provide 1/8" increments for easy repeat setups The FixLogix standard plates feature a reference scale along the t-slots with 1/8" increments for easy repeat setups. Kit Includes the following components: Standoffs: (4) #CS75-1: 1” length x .75” dia. standoff (4) #CS75-1.5: 1.5” length x .75” dia. standoff (4) #CS75-2: 2” length x .75” dia. standoff (4) #CS75-3: 3” length x .75” dia. standoff (4) #CS75-4: 4” length x .75” dia. Standoff (Standoffs have 1/4 -20 threaded stainless screw on bottom and threaded hole on top) Fasteners (30) #C3125-5: 5/16ths long x 1/4 -20 set screw SS, with nylon tips (Used in T-nuts and right angle 2-way T-nuts) (2) #C05025TS: 1/2 ” x 1/4 -20 stainless thumbscrew with black knurled top (For use with cross-slide) (12) #CTN1: T-nuts, 1.5” long with (2) 1/4 -20 threaded holes (Used in T-slots of fixture plate or vertical riser) (10) #CLN025: locknut with 1/4 -20 threaded ID (For use with clamp rods, thumbscrew, and spherical locator pin) Clamps and Rods (6) #CTSC01: “Soft-touch” self-wedging tail-spring clamp (Patent pending self-wedging clamp works with clamp rods) (3) #CR4025T: Stainless clamp rod, 4” long x .250 dia. with 1/4 -20 threaded end (3) #CR8025T: Stainless clamp rod, 8.5” long x .250 dia. with 1/4 -20 threaded end (Use with locknut to attach rods to plate or standoffs) Locating accessories (2) #CMJS01: Mini jack-screw (Jackscrew and locknut are attached to standoff to create a mini jack-stand.) (4) #CCLL75: Conical locator, .750” base dia. x 35° taper (For locating in holes .08”- .700”, and to create simulated Vees) (1) #CSWS: Swivel head assembly for horizontal or angular clamping setups (For multi-angle clamping or basing points) (1) #STB-1: Sliding tool block provides threaded holes perpendicular to t-slots (1) #CCSA12: 12” Cross-slide assembly, with clamps. (Provides infinite adjustment between t-slots, and can be rotated). (4) #CAR0251: Adjustable rest button, stainless, spherical top, 1/4 -20 thread (Used with standoff, creates a 2-way locator or mini jack-stand w/ spherical tip) Risers and Accessories (2) #CLR6: 6” (150mm actual) vertical linear riser, six t-slots: 2 x 2 + 1 x 1. (Provides vertical setup functionality) (4) #CAC-901 Right-angle connectors for risers, with 6 1/4 -20 threaded holes (Provides flush mounting for risers….is a 2-way t-nut, with extra hole for components) Component Case (1) #CKCC: Component case with compartments, 18-1/2” x 12” x 3”
