Cmos Camera Module Ov7670 Display Active 640x480 Sccb Compatible I2c 3.6?m New

US $7.43

Shenzhen, China
Jan 29th

Open on mobile:
QR code

Recommendations For You 20% Off, $10.94 Now 50% Off, $2.70 Now 20% Off, $8.48 Now 20% Off, $1.47 Now 19% Off, $2.01 Now Visit my eBay Store:ChipWorld Product Name: CMOS Camera Module OV7670 Display Active 640X480 SCCB Compatible I2C 3.6 NEW More Items In Our Store,Click Here! SKU: 1679 Parsts No. : Package: Brand: Quantity: 1 Photographic array 640X480 IO voltage of 2.5V to 3.0V (internal LDO for nuclear power 1.8V) Power work 60mW/15fpsVGAYUV Sleep <20?A Operating temperature -30 *C to 70 *C Stable operation 0 *C to 50 *C Output format (8-bit)? YUV/YCbCr4: 2:2 RGB565/555/444 GRB4: 2:2 Raw RGB Data Optical size of 1 / 6 " 25 ° field of view The maximum rate of 30fps VGA Chen Sensitivity 1.3V / (Lux-sec) 46 dB SNR 52 dB dynamic range View Mode Progressive E-1 line to 510 line exposure 3.6?m x 3.6?m pixel size Dark Current 12 mV / s at 60 *C 3V3 ----- input supply voltage (recommended 3.3,5 V can also be, but is not recommended) The GDN ----- ground point SIO_C --- SCCB interface control clock (Note: some of the low-level microcontroller needs pull-up control, and the I2C interface similar) SIO_D --- SCCB interface serial data input (output) end (Note: some of the low-level microcontroller needs pull-up control, and the I2C interface similar) VSYNC --- frame synchronizing signal (output signal) HREF ---- line synchronizing signal (output signal) The PCLK ---- pixel clock (output signals) D0-D7 --- data port (output signal) RESTE --- reset port (normal use pulled) PWDN ---- power selection mode (normal use pull down) OV7670 image sensor, small size, low operating voltage, and provides all the features of the single-chip VGA camera and image processor. SCCB bus control, you can output the entire frame, sub-sampled, take the window way affect data resolution 8. VGA image of the product is up to 30 frames / sec. Users can fully control the image quality, data format and transmission mode. The process of image processing functions including gamma curves, white balance, saturation, chroma, and so can be programmed through the SCCB interface. ? High sensitivity for low-light applications ? Low voltage suitable for embedded applications ? standard SCCB interface compatible with I2C interface ? RawRGB RGB (GRB4: 2:2, RGB565/555/444), YUV (4:2:2) and YCbCr (4:2:2) output format ? Support VGA, CIF, and from CIF to 40x30 of various sizes ? VarioPixel subsampling ? automatically affect the control functions include: automatic exposure control, automatic gain control, automatic white balance, automatic eliminate light stripes, automatic black level calibration image quality control including color saturation, hue, gamma, sharpness ANTI_BLOOM ? ISP has to eliminate noise and dead pixel compensation function ? support for image scaling ? The lens is the loss of light compensation ? 50/60Hz automatic detection ? saturation automatically adjust (UV adjustment) ? edge enhancement automatically adjust ? Noise Reduction automatically adjust Files For more quantity, please contact me.(My skype: ada-yu2013) The Standard shipping we provide is non-regiested mail without a tracking. We provide free shipping with tracking number when your order is over $50. If your oder is below $50 and you need tracking, please contact me. Maybe you request CMOS Camera Module OV7670 Display Active 640X480 SCCB Compatible I2C 3.6 NEW 1pc AT24CXX I2C Interface EEPROM Memory Module(no chips) good ISD1820 voice board voice module sound recording module on-board microphone new VS1053 module MP3 development board (on-board recording function) 1 ISD4004 Speech module voice module Speech development Kit NewWay third version $ 7.72 + free shipping $ 2.96 + free shipping $ 4.65 + free shipping $ 11.3 +free shipping $18.53 + free shipping Any problem, please contact us freely 1) We accept PayPal payment ONLY. inkFrog Analytics On Mar-21-14 at 01:44:07 PDT, seller added the following information:
