Cnc 1.5kw Spindle Motor + Frequency Inverter +mount+ 13pc Er11 Collet+water-pump

US $359.00

Hong Kong, China
Jan 30th

Open on mobile:
QR code

g # B075 CNC 1.5KW Water-Cooled Spindle Motor + 1.5KW Inverter VFD+ Mount + 13pcs ER11 collet water-pump + Pipes full kit Product description Item Description: 1.5KW Spindle Motor Specification: Specification: Φ80mm x Length:188mm (including air interface: Φ80mm X 203mm) Power: 1.5 KW Voltage: AC220V Frequency: 0-400 Hz Max Rotation speed: 24000 R/min Chuck: ER11 collet chuck Cooling mode: water cooling mode Coaxiality: 0.025mm Radial runout: 0.01mm The speed of adjustment: 0-24000 stepless speed control can be achieved through the inverter to adjust the output voltage and operating frequency, Lubrication: high temperature grease lubrication Power Interface: Selection of the GX16 Waterproof interface, within the 1,2,3,4 label, 1,2,3 respectively connected to the drive power supply (U, V, W), 4 connected to the inverter ground 1.5KW Inverter Specification: Series 1.5KW/220V Inpute Specification Phase 1 or 3 phase as you like Voltage (V) 220V±15% Frequency (HZ) 47-63Hz Output Specification Phase 3 phase Voltage (V) 208-240V AC (analogous to Input Voltage) current(A) 7.0A Frequency (HZ) 0.1-400HZ Capacity(KVA) 2.8KVA Control Mode SPWM Input Power 220V class:220±15%(we also provide 380V item, if you need,please contact us) 5-Digits Display & Status Indicator Lamp Displaying frequency, current, revolution, voltage, counter, temperature, FOR or REV rotation, and fault, etc. Communication Control RS-485 Working Temperature -10~45℃ Frequency Control Accuracy Setting Resolution General Control Output Resolution Digital: 0.1%(-10~40℃); Analog: 0.1% (25±10℃) Operator Setting Method Digital: 0.1Hz; Analog: 1‰ of max. Operating frequency Analog Setting Method 0.1Hz Other Functions Press directly ←∧∨ to set. Ramp Control External Voltage 0-5V,0-10V,4-20mA,0-20mA. V/F Curve Frequency lower limit, starting frequency, stopping frequency, three skip frequencies can be respectively set. Torque Control Selectable 4-speed steps ramp-up and -down time (0.1-6500s). Protection Functions Multi-Inputs Set V/F curve at will. Multi-Outputs Torque increase settable by max. 10.0%. The starting torque can reach 150% at 1.0Hz. Other Functions 6 multi-function input terminals for 8–speed steps control, program operation, switching of 4-speed Ramp, UP/DOWN function, counter, external emergency stop and other functions. Overload Protection 5 multi-output for displaying of running, zero speed, counter, external abnormity, program operation and other information and warnings. FuseProtection Auto Voltage Regulation(AVR), Decelerating Stop or Coasting Stop, DC Braking, Auto Reset and Restart, Frequency Track, PLC Program Control, Traverse Control, Drawing Control?Auto Energy Saving, Carrier Adjustable (Up to 20KHz), etc. Over-voltage Electronic relay protection motor drive Drive(for constant torque150%/1 min. for the kinds of fan 120%/1min.) Under-voltage When the fuse breaks , the motor will stop. Restart After Instant Stop 220V class:DC Voltage >400V We also stock 380V item, contact us about stock 380V class:DC Voltage >800V Stall Protection 220V class:DC Voltage
