Cnc Kit 5x Ma860h Stepper Driver 24v-110vdc + Breakout Adapter + Parts 2.6a-7.2a

US $399.69

HK, Hong Kong
Jun 9th

Open on mobile:
QR code

CNC Kit 5x MA860H Stepper Driver 24V-110VDC + Breakout Adapter + Parts 2.6A-7.2A More.. CNC Kit 5 Axis Breakout Board + 5 Axis MA860H Stepper Driver Board Controller Descriptions: The latest upgraded salable 5 axis breakout board is speacilly designed for the CNC single axis stepper driver controller, such as M542, M542H, MA560, MA860H, 2M542, 2M982 etc single axis stepper driver controller. With this 5 axis breakout board, any 1-5 single axis stepper driver controllers can be directly controlled by the PC via the MACH3, EMC2, KCAM4, etc. The MA860H Stepper Driver Board Controller is a high performance microstepping driver based on pure-sinusoidal current control technology. With this technology and the self-adjustment technology (self-adjust current control parameters) for different motors, the drive motors can run with smaller noise, lower heating, smoother movement and have better performances at higher speed than most of the drivers in the markets. It is suitable for driving 2-phase and 4-phase hybrid stepping motors, so the Nema23, Nema34 and Nema42 stepper motors with a 2.6A-7.2A current will be suitable. Click here for the specification of MA860H In short, with this CNC Kit, you will get more benefits from the Kit on CNC work. Please purchuse this kit with confidence. Features: I. 5 Axis Breakout Board Upgraded circuit, work more peacefully and steady than the previous version Maximum support 5-axis stepper motor driver controller Two types of ways to get power, 5V DC power supply or USB port to directly get power from PC Two-stage signal processing, smooth signal transmission, powerful anti-jamming 5-input interface to define the Limit, Emergence-Stop, Midpoint-Alignment, Cutter-Alignment, etc. Relay output control interface, accessed by the spindle motor or the air pump, water pump, etc. 5-axis work LED display, visually display the working condition of the stepper driver controller II. MA860H Stepper Driver Board Controller High performance, cost-effective Supply voltage from "18V AC to 80V AC" or "24V DC to 110V DC" Output current from 2.6A to 7.2A Self-adjustment technology, full to half current self-adjustment when motors from work to standstill via switching off SW4 Pure-sinusoidal current control technology Pulse input frequency up to 300 KHz TTL compatible and optically isolated input Automatic half-current reduction as long as switching off SW4 when motors stop 16 selectable resolutions in decimal and binary, up to 51,200 steps/rev Suitable for 2-phase and 4-phase motors Support PUL/DIR and CW/CCW modes Short-voltage, over-voltage, over-current and short-circuit protection, protect the PC, motors, driver etc from being damaged External Fan Design to avoid overheat Applications: Suitable for any medium-and-big size automatic equipment with CNC controller, such as X-Y tables, labeling machines, laser cutters, engraving machines, and pick-place devices Suitable for a wide range of stepping motors, from NEMA size 23 to 42 For processing various pattern mould For advising, such as brand, architechture mould, badge, nameplate, display boards, doorplate, furniture decoration, etc. For carving portrait, scenery, handwriting, sealing, etc. MA860H DIP-Switch Settings: I. DIP-Switch Instructions II. DIP-Switch Settings Diagram Power supply Recommend: 36V AC or 48V DC power supply for Nema 23/24 stepper motors 48V AC or 48~80V DC power supply for Nema 34 stepper motors 60V AC or 80~110V DC power supply for Nema 42 stepper motors Interface Instructions: (5 Axis Breakout Board) (MA860H Stepper Driver) Connection Diagrams: (Breakout-Board-Wiring) (MA860H-Wiring) I. Specifications of Breakout Board: Electrical properties (ambient temperature Tj = 25 °C pm): Input Power 5V DC power supply or USB port to directly get power from PC Compatible Stepper Motor Driver Max 5 single axis stepper motor driver controller Drive type Pulse + Direction + Enable Signal Control Net/Total Weight Approx 80g/300g Dimensions 90 * 82 * 15mm (L*W*H) II. Specifications of MA860H Stepper Driver: 1 x 5 Axis Breakout Board 5 x CNC Stepper Motor Driver Board Controller MA860H (2.6A-7.2A) 1 x DB25 Parallel Cable 1 x USB Power Cable 1 x CD Click here for the Mach3 software Click here for the user manual of this kit We sell items to most countries of the world. For cost saving purpose, we can't keep a lot of stock for every item in every location. Your order with us may be sent from anyone of our dispatch centers that has sufficient in stock quantity. Typical delivery durations(for reference only) are: Estimated Delivery Time(Airmail Packets) UK, Australia, New Zealand, South Asia, East Asia 10-15 business days USA, Canada, other EU countries(France,Germany, etc.) 10-18 business days Italy, Spain 20-30 business days South America, Other Countries 15-20 business days Please DO CONTACT AND CONFIRM with us BEFORE you bid IF you: - need the item urgently. - require that the item should be delivered within a certain time. - have any other questions/requirements about delivery. Remarks: *Usually, your order will be dispatched before the next working day after the full payment is cleared when stock lasts. *Notification will be sent after your order is dispatched, please check you email or ebay order records for date of dispatch. *It is not guaranteed that parcel should arrive within the time stated above. However, 95%+ parcels will be delivered within the reference time. *Please contact us if you have any trouble in receiving your orders. We will help you to track them. PayPal: We accept PayPal (Allows you to pay by credit cards, debit cards or echecks securely with NO surcharge) * If you have difficulty to make payment by PalPal please contact us for alternative payment method. Remarks: *Please send payment within 5 days after auction ends. All sales are final, shipping and handling costs are also NOT negotiable. *We will use your PayPal shipping address as the delivery address. *Please make sure that your shipping address is correct. 30 Days Money Back Guarantee: If you are not satisfied with the item purchased from us. Please inform us in writing(e.g. e-mail, eBay message, fax, letter) within 30 days of receipt of goods. We will guide you to return and refund the item. Please note that the postages / custom fees(if any) spended in such an order are on the customer's cost. Free Replacement: If you receive a not-as-described (e.g. defective, incorrect, part missing) item, please contact us when you get the item. We will arrange a replacement as soon as the case is confirmed. Suppliers Warranty: We offer one year warranty on all products purchased from us. If your item has any warranty issue please contact us for a satisfying solution. Requirements: *All qualified returns/replacement must be guided by us. We may not accept your return without informing us in advance. *Customs fee, handling charge, postage and insurance are on customers cost and not refundable. We are always ready to help. Agreement: By placing an order, you acknowledge that you have accepted all the terms and conditions of sale. You are welcome to contact us with any quires.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	NBNC
UPC	190080030797
MPN	100307901
